Audioplex RC-5 Manuale utente

The RC-5 Interface allows easy integration of conventional infrared systems with stereo systems using the RC-5

infrared protocol.

TECHNOLOGY

INSTALLATION MANUAL

RC-5 Interface

INSTALLATION

WARRANTY

With the power off to both the infrared connector block and the receiver, connect the RC-5 interface following the

wiring diagram below. Once all connections are made. Power can be restored to all the units.

Your AUDIOPLEX TECHNOLOGY RC-5 Interface is covered by a Lifetime Warranty against defects in

workmanship and materials. Any defects will be remedied without charge for labor or parts.

Damage incurred by shipping or accident is not considered to be a defect, and not covered by this warranty.

AUDIOPLEX TECHNOLOGY is not responsible for defective operation caused by abuse or by modification or

service by an unauthorized person or agency.

The unit must be properly installed and operated according to instructions for the warranty to apply. Any necessary

servicing must be done by AUDIOPLEX TECHNOLOGY. The products must be returned expenses prepaid, with

written authorization from the company. The unit must be shipped with the proof of purchase and in original carton

and packing material to avoid damage.

2004 - 11/23/04

WIRING DIAGRAM

AUDIOPLEX TECHNOLOGY

404 GWH PO BOX 440 MELVIN VILLAGE, NH 03850 800-257-2077 FAX: 603-544-8901

12V POWER SUPPLY

FROM IR CONNECTOR BLOCK

TO RC-5 JACK ON RECEIVER
