Audiovox Platinum+ APS 687C Manuale utente

128-8782b

1 of 12

Page1

Model APS-687C

Owners Guide

Deluxe 7 Channel

Remote Start System

With Keyless Entry

PATENTED: www.voxxintlcorp.com/company/patents

RevbNewFormat5/13

Table Of Contents:

Features and Options Page 2

Your "Code Hopping" Transmitters Page 3

Keyless Entry Page 3 - 4

Optional Remote Function Channels Page 4

Optional Additional Remote Channel 4 Page 4

Optional Additional Remote Channel 5, 6, 7 Page 5

Valet Override, Programming & Safety Control Switch Page 6

Vehicle Service / Remote Start Override Mode Page 6

Turbo Timer Operation Page 6 - 7

Remote Starting The Vehicle Page 7 - 8

Automatic Start Timer Operation Page 9 - 10

Telematic Upgrade Page 10

Programmed Transmitter Notification (PTN) Page 10

Programming New or Replacement Transmitters Page 11

Features And Function Setting Chart Page 12

128-8782b

2 of 12

Page2

Deluxe 7 Channel Remote Start System With Keyless Entry

FEATURES:

2 Five Button Programmable RF Transmitters

Seven Channel Receiver (capable of accepting 4 transmitters)

Code Hopping Technology

External Superheterodyne Antenna w/PushButton Switch and LED

Safe Start RF Control (Double Push Of RF Transmitter)

Selectable Automatic Timed Start Mode

( + ) and ( - ) Keyless Entry Outputs

On-Board Start Relay

On-Board Accessory Relay

3 On-Board Ignition Relays

On-Board Parking Light Relay

Ignition 2 and 3 Relay Selectable On or Off During Cranking

Ground Output While Running / Shock By-Pass / GM VAT Output

Tach Signal Learning Circuit

Two ( + ) and Two ( - ) Safety Shutdown Circuits

Alarm By-Pass Output

Channel 3 Output for Remote Trunk Release (relay required)

Channel 4, 5, 6, and 7 Output to Control Optional Accessories

Selectable Steady or Flashing Parking Lights for Run Indication

Selectable Run Times

Selectable Door Lock Output Pulse Timing

Optional Illuminated Entry Output (Relay Required)

Vehicle Horn Activation Output For R/SAnnunciation

ExternalActivation Control Input

Turbo Timer Mode

OPTIONS:

Telematic Upgrade Ready

Plug In Flash Logic By-Pass Capable

Remote Power Window Control

Remote Garage Door Interface

Multiple Vehicle Capable

WARNING! Be certain that the vehicle is outdoors before using this or any remote

vehicle starting device. A running engine produces dangerous

carbon monoxide fumes which can be harmful or fatal if prolonged

exposure occurs. DO NOT remote start the vehicle if the car is

garaged.

128-8782b

3 of 12

Page3

YOUR"CODE HOPPING"TRANSMITTERS

Thetransmittersincluded withyour newremote startsystem

use the most advanced and secure form of radio frequency

transmissionavailable onanycurrent automotiveremotesys-

tem.Some oftoday’s sophisticatedauto thievesuseadevice

known as a code grabber, which will receive and store the

signal from your keychain transmitter, and re-transmit at a

later time to unlock your system.

Yourcode hoppingtransmitters willchange theirsignal every

time the button is pressed, so when a thief grabs then re-transmits your

signal, the system will not respond.

If your transmitter button is pressed more than fifty times while it is out of

range of the vehicle (children playing with your keys), the transmitter will

not operate when you return to the vehicle, and will need to be re-aligned

to the receiver. To do this, simply press the lock/unlock button two times

within a one second time period. The system will now respond to that

transmitter each time a button is pressed.

Forreferencethe transmitterpackaged withyour systemmaynot appear

exactly as shown below. This depiction is for reference only.

NOTE: As an option, this system has the ability to operate the vehicles

horn which may require some additional parts. If this feature is

installed, the vehicle's horn will beep once when you lock the

doors,twice whenyou unlockthe doors,twice whenthe Remote

Start feature is activated, and will beep during the car finder

mode to allow you to find the vehicle more easily in a crowded

parking lot.

KEYLESSENTRY

1. To lock your vehicle, exit the vehicle, close all doors, hood and trunk,

then simply press the lock button of your keychain transmitter. To unlock

your vehicle, simply press the unlock button of your keychain transmitter.

As a keyless entry unit, for your convenience, the parking lights will flash

oncewhenthedoorsarelockedand twicewhen thedoor areunlocked. If

theoptional illuminatedentry featurehas beenadded, theinterior lightwill

turnon whenthe doorsareunlockedandremain onfor 30secondsoruntil

the ignition is turned on.

Holding the lock/unlock transmitter button for 3 seconds will activate the

carfinder modecausing theparking lightsto flashand theoptional hornto

128-8782b

4 of 12

Page4

beepfor30secondsor untilthe buttonis activatedagain for3seconds or

anyotherbutton isoperated.

NOTE: Thissystemhastheability tounlock thedrivers doorwith thefirst

press of the unlock transmitter button and then unlock all other

doors when the unlock button is pressed a second time. This op-

tional feature may require additional components. Consult your

installation center to determine if this feature has been added to

yourvehicle. Additionally thissystemcanbeprogrammedtoauto-

matically lock and unlock the doors with the turning on and off of

the ignition key.

ADDITIONALREMOTEFUNCTION (CHANNEL3)

Thissystemhas anadditional featurethat canbeconnected toa number

ofdifferentoptionalaccessories.Some ofthe morecommon usesfor this

channelare: RemoteTrunkRelease

Remote Window Closure

RemoteGarageDoorInterface

To activatethe optionalaccessory,press andhold thetrunk/key buttonon

thekeychaintransmitter forfour seconds.

NOTE: Thefeaturethat hasbeen addedto channel3 willalwaysbe acti-

vated using the same transmitter button that remotely starts the

vehicle.There isnowaytomovethechannel3functiontoa differ-

enttransmitterbutton.

ADDITIONALREMOTEFUNCTION (CHANNEL4)

Thissystemhas anadditional featurethat canbeconnected toa number

ofdifferentoptionalaccessories.Some ofthe morecommon usesfor this

channelare: Can BeSet UpToActivate RearWindowDefogger

During Remote Start If Vehicle Is So Equipped

RemoteWindow Closure

RearHatch Release

Right Or Left Slider Doors inAn Equipped Van

To activate the optional accessory, press the option button on the

keychain transmitter. The optional accessory will immediately engage.

128-8782b

5 of 12

Page5

ADDITIONALREMOTEFUNCTION (CHANNEL5)

Thissystem hasanadditional featurethatcanbeconnected toanumberof

different optional accessories. Some of the more common uses for this

channelare: Remote TrunkRelease

RemoteWindow Closure

RearHatch Release

Right Or Left Slider Doors inAn Equipped Van

To activate the optional accessory, press the option button on the

keychain transmitter. The optional accessory will immediately engage.

ADDITIONALREMOTEFUNCTION (CHANNEL6)

Thissystem hasanadditional featurethatcanbeconnected toanumberof

different optional accessories. Some of the more common uses for this

channelare: Rear HatchRelease

Right Or Left Slider Doors inAn Equipped Van

DriverPrioritySettings InVehicles SoEquipped

To activate the optional accessory, press the option button on the

keychain transmitter. The optional accessory will immediately engage.

ADDITIONALREMOTEFUNCTION (CHANNEL7)

Thissystem hasanadditional featurethatcanbeconnected toanumberof

different optional accessories. Some of the more common uses for this

channelare: Rear HatchRelease

Right Or Left Slider Doors inAn Equipped Van

DriverPrioritySettings InVehicles SoEquipped

SecondDriverPrioritySettingsInVehiclesSoEquipped

To activate the optional accessory, press the option button on the

keychain transmitter. The optional accessory will immediately engage.

NOTE: If your system utilizes the transmitter shown, the second option

buttonmaybeconfigured to operateadditional accessories.

128-8782b

6 of 12

Page6

Please consult your installing retailer formore informationconcerning the

optionsavailable.

PUSH-BUTTONLEDRECEIVER

VALET/OVERRIDE/SAFETYCONTROLSWITCH

The Push-Button LED switch located in the receiver allows you to

temporarily disable the remote starting function of the system. This IS

recommendedwhenever thevehicleis beingserviced.

To place the system in the service mode:

1) With the system disarmed/unlocked, and the ignition switch off, Press

andHold thePush-Button,foundonthewindsheildreceiver, in.

2) Turn the ignition switch on, off, on, off, on, off.

3)TheLED beginstoflash twoshort flashes followedby one longflashes

andcontinuesthis patternuntil returnedto normalmode ofoperation.

This puts the unit into the R/S Override mode indicating that the remote

start is in the service mode and will not start from RF or any other input

Posseorotherwise.

To exit the service mode:

1) With the system disarmed, Press and Hold the Push-Button, found on

thewindsheild receiver,in.

2) Turn the ignition switch on, off, on, off, on, off.

3) The LED turns off indicating that the R/S unit is fully functional one

again.

TURBOTIMER MODE

Thissystem providesameans tocooldown thevehiclesturbo charger, ifso

equipped,by allowingthe vehicleto continueto runfor aprescribed period

of time every time the vehicle's engine is turned off. This feature requires

the system to be set up for turbo timer during installation. Consult with

your installation center to be certain this feature was activated and how

long the vehicle will continue to run, 3, 5, or 10 minutes after the ignition

switch is turned off.

128-8782b

7 of 12

Page7

TO ACTIVATE THE TURBO TIMER

Anytime the ignition key is in the on position for more than 15 seconds:

1) Place the gear selector in park.

2)Setthe parking,(hand), brake.

3) Be certain your foot is off the brake pedal.

4) Press the receiver's program/Push-Button switch 2 times within 5

seconds. The parking lights will flash two times indicating the mode was

successfullyentered.

If your parking lights flashed four times, this indicates the turbo mode was

onandis nowturned off.

Withtheturbo timermode selectedon, afteryou'vearrived atyour

destination,whilethe engineis stillrunning,set theparking brake,pause 2

seconds, then turn the ignition switch to the off position. The engine will

continue to run the allotted time according to the selection during

installation.

Ifyou donot wantthevehicle tocontinue torunforonecycle, simplystep on

the vehicle's brake, release the parking brake, or activate the transmitter's

start button two times in succession.

Any of these will cause the engine to turn off.

REMOTESTARTINGTHE VEHICLE

Thesystem WILLNOTstart thevehicleifanyone ofthefollowing conditions

exists:

1.TheVehicleHoodIsOpened.

2. The Gear Selector Is InAny Gear Other Then Park.

3.TheBrakeIsDepressed.

4. The System is in the remote start override mode.

128-8782b

8 of 12

Page8

WARNING! Be certainthat thevehicle isoutdoorsbeforeusingthisor any

remote vehiclestartingdevice.Arunning engineproduces

dangerous carbon monoxide fumes which can be harmful or

fatalifprolongedexposure occurs.

DO NOT remote start the vehicle if the car is garaged.

TOREMOTESTART THE VEHICLE

Press and release the trunk/key button of your keychain transmitter two

times within 2 seconds.

Thevehicle willstart andremain runningforthepre-programmedtime

selected.

As a visual indication, the parking lights will flash or turn on dependent on

the programming set up by your installation center.

When you arrive at your vehicle, unlock it with the key or by pressing and

releasing the unlock button of your keychain transmitter.

Enter the vehicle and turn the ignition key to the on position.

CAUTION! Do not turn the key to the start position. This will cause the

startermotor toengage withthe alreadyrunning enginewhich

couldresult indamage. Steponthebrakepedaltodisengage

the remote start unit. The vehicle will continue to run but now

onit's ownpower.

NOTE: The engine will stop running before the expiration of the

pre-programmed run timer or if you complete any of the

following:

1. Press and release the trunk/key button of your keychain transmitter two

times within 2 seconds.

2.Depressthe brakepedal.

3.Openthe hood.

4. Place the system in Remote Start Override Mode

5.Racetheengineto above4000 RPM.

128-8782b

9 of 12

Page9

128-8782b

OPERATING ON AUTOMATIC START UP TIMER MODE

The system has the ability to automatically start the vehicle every 2 or 4

hoursovera 48hour period.This featureisespecially usefulin cold

climateswhere theonly meansto keepthe engineand enginefluids warm

is to periodically start the engine.

WARNING! Be certain that the vehicle is outdoors before using this

or any remote vehicle starting device.Arunning engine

produces dangerous carbon monoxide gases which can be

harmfulor fatalif prolongedexposure occurs.

DO NOT remote start the vehicle if the car is garaged.

TO BEGIN THEAUTOMATIC START UP TIMER

1. Turn the ignition key on then off.

2. Within 10 seconds, activate the RF start command two times.

(Push the second channel button of your keychain transmitter 4 times).

The parking lights will flash 4 times indicating the timed start mode is

activated.

Thevehicle,on a2 or 4hour intervalbasis,will automaticallystart, run for

thepre-programmed runtime, thenshut off.

Thiswillcontinue for48 hours.

NOTE: Theautomaticstartuptimercan alsobeinitiatedfromthekeychain

transmitter.

To do this:

1. Start the vehicle using the keychain transmitter by pressing and

releasing the trunk/key button transmitter button 2 times.

2. Shut off the vehicle using the keychain transmitter by pressing and

releasing the trunk/key transmitter button 2 times.

3. Within 10 seconds of step 2, activate the RF start command two

times.

(Push the trunk/key button of your keychain transmitter 4 times).

128-8782b

10 of 12

Page10

The parking lights will flash and the siren will chirp 4 times indicating the

timed start mode is activated.

CANCELINGTHEAUTOMATIC START UPTIMER

To cancel the automatic start up timer do one of the following;

1. Start the vehicle manually with the use of the ignition key and depress

thebrake pedal.

2. Remote start the vehicle using your keychain RF transmitter.

3. Shut off the vehicle using the keychain transmitter by pressing and re-

leasing the trunk/key transmitter button 2 times.

TELEMATICUPGRADE:

Thissystem hasthe abilityto havea telematicupgrade moduleconnected

toit. Thisisan upgradethatcangiveyou controlofcertain functionsofyour

vehicle from aTelephone, or in some cases a computer interface. Please

check with your installation center for most recentTelematic Upgrades. If

you had a Telematic Upgrade installed, the manual supplied with the up-

grade unit will provide a operators manual advising of the features of the

systemandmeans availableto controlthese featuresof yourvehicle.

PROGRAMMEDTRANSMITTER NOTIFICATION (PTN)

Every time after Disarm when the ignition key is turned on, the unit's LED

will report the number of transmitters programmed into the system. This

safetyfeaturewill alertyou ifan unauthorizedtransmitterhas been

programmedintoyourvehicle'ssecurity systemwithout yourknowledge.

Typical from the factory, there will be a 2 flash, pause, repeated 3 times

indicating that two transmitters are programmed into the system. If you

noteadditional flashes,theremayhevebeenanadditional transmitter

addedwithoutyour knowledgeor authorization. Ifyou noticeachange in

the transmitter LED report pattern, you can correct this by looking up

howtoerase andreprogram yourtransmitters foundin thetransmitter

programmingguide. Thisreprogramoperationwillerase allunauthorized

orunwanted transmitters.

Altri manuali per Platinum+ APS 687C

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Audiovox Avviamento remoto

Audiovox

Audiovox Prestige Platinum+ APS 686 Manuale utente

Audiovox

Audiovox PRO-9276C Manuale utente

Audiovox

Audiovox Prestige Platinum APS 686T Manuale utente

Audiovox

Audiovox Prestige APS-55 Manuale utente

Audiovox

Audiovox PurSuit PRO-9056TW Manuale utente

Audiovox

Audiovox Pursuit PRO-9776 Manuale utente

Audiovox

Audiovox PRO-9175FT4 Manuale utente

Audiovox

Audiovox AS 9075a Manuale utente

Audiovox

Audiovox CA440SS Manuale utente

Audiovox

Audiovox Prestige APS-55TWT Manuale utente

Audiovox

Audiovox APS620 - Prestige Remote Start Manuale utente

Audiovox

Audiovox Prestige APS-45 Manuale utente

Audiovox

Audiovox Pursuit PRO-9051 Manuale utente

Audiovox

Audiovox Prestige Platinum+ APS 675 Manuale utente

Audiovox

Audiovox Prestige APS-57 Manuale utente

Audiovox

Audiovox Prestige APS-905 Manuale utente

Audiovox

Audiovox AS-9055 Manuale utente

Audiovox

Audiovox Prestige Platinum APS-51 Manuale utente

Audiovox

Audiovox APS687 - Car Prestige Remote Start Manuale utente

Audiovox

Audiovox Auto Security AS-9151N Manuale utente

Audiovox

Audiovox PURSUIT PRO-9056i Manuale utente

Audiovox

Audiovox Pursuit PRO 9232 Manuale utente

Audiovox

Audiovox AA-RS10CS Manuale utente

Audiovox

Audiovox Prestige Platinum APS-57N Manuale utente

Manuali Avviamento remoto popolari di altre marche

AstroStart

AstroStart 803U Manuale utente

Durite

Durite 0-649-20 Manuale

EINHELL

EINHELL BT-PS 1000 Manuale

Linear

Linear ACCESS AK-21 Specifiche tecniche

Soundstream

Soundstream TARANTULA RS.2 Manuale utente

Jaycar Electronics

Jaycar Electronics MB3752 Manuale utente

Ultra Start

Ultra Start 72 Series Manuale utente

ADS

ADS FLASHLOGIC FLRSVW1 Manuale utente

Selecta

Selecta JS012 Manuale utente

Black Widow Security

Black Widow Security BW RAS 400 Manuale utente

Vector

Vector Power City DK080706 Supplemento

Code Alarm

Code Alarm CA-535 Manuale utente

Ozito

Ozito OJS-800 Manuale utente

Profi-Partner

Profi-Partner 46387 Manuale utente

EZ STARTER

EZ STARTER EZ-45 Manuale utente

Viper

Viper 4204 Manuale utente

Essex Electronics

Essex Electronics KE-1701 Manuale utente

EINHELL

EINHELL EGS 3600 Manuale
