Aurora AU125MA Manuale utente

AU125MA

Model No. Please read these operating instructions before using the unit.

Shredder User Manual

1-800-327-8508

USA Only

1-310-793-5650

International

Email: [email protected]

For more information, please visit us at:

www.auroracorp.com

3ENGLISH

WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!

DO NOT SHREDS:

Note: Do not open lid once shred cycle has started CONTINUED NEXT PAGE

”

(

)

Keep away from moving parts.

Read instructions before use.

Avoid touching the document

feed opening with hands.

Product is not intended for use by

children (product is not a toy).

Do not insert foreign objects into

the paper entry slot.

Do not spray or keep any

aerosol products in or around the

shredder.

Keep loose clothing or jewelry

away from the paper entry slot.

Avoid getting hair near the

paper entry slot.

Sharp blade edges!

Do not touch!

4ENGLISH

WARNING:SAFETY INSTRUCTIONS, READ BEFORE USING!

•AlwaysturntheshredderoffandunplugthepowercordfromtheACoutletwhen

notinuse,beforecleaning,moving,oremptyingthewastebasket.

•RISKOFFIRE.Neveruseanypetroleumbasedorflammableoilsorlubricantsin or

around the machine as some oils can combust causing serious injury.

•NEVER dispose of flammable chemicals or materials that have come into contact with flammable

chemicals (for example, nail polish, acetone and gasoline) in the shredder basket.

•Nevershredmetalcreditcards,largepaperclips,windoworinsulatedenvelopes,

continuousforms,newsprint,boundpages(forexample:notepads,checkbooks,

magazines,etc...),transparencies,laminateddocuments,cardboard,anyitemswith

adhesives,hardmaterialsorplastic(exceptCreditCards).

•A socket-outlet should be near the equipment and be easily accessible.

•Never let the wastebasket become full. This will lead to shredded material being pulled back up into

the shredder and cause jams.

•Never place the shredder near water or any heat source.

•Do not use the shredder if the power cord is damaged in any way.

•Do not attempt to service this product yourself as doing so may expose you to sharp cutting blades

and/or electricity and will void the manufacturer's warranty.

•Never try to clean or clear the shredder blade.

•Never shred beyond the specified sheet capacity. This may result in extensive damage to the machine.

5ENGLISH

PaperShredderOperatingInstructions

• Warning • Installation • Operation • Maintenance • Troubleshooting

*ManualFeed:

• Shreds credit cards, small paper clips, staples

• One folded sheet of paper equates to 2 sheets of paper

• Heavier paper, humidity or electrical voltage other than the rated voltage may reduce shredding capacity

Sheet Capacity

Paper Shred Size

Paper Tray Size:

Paper Entry Width

Credit Card Capacity

Duty Cycle

Voltage

120 Sheets of 20 lb. letter size bond paper

5/64 in. x 15/32 in. pieces

(2.0 mm x 12 mm pieces)

Letter size- 8.5” x 11”

8.7 in / 220 mm

N/A

60 min. on / 45 min. off

120-V~60Hz / 3.5 A

10 Sheets of 20 lb. bond paper*

5/64 in. x 15/32 in. pieces

(2.0 mm x 12 mm pieces)

N/A

8.7 in / 220 mm

Only one per pass

10 min. on / 45 min. off

120-V~60Hz / 3.5 A

AutoFeedTray: ManualFeedSlot:

INSTALLATION

1. Make sure the basket door is securely closed shut. This shredder features a safety power cut off and

will not operate if door is open. Shredders with pull-out wastebaskets will also cut power upon bin

removal. The supplied wastebasket activates a safety switch, which allows the shredder to be operable.

2. Attach all 4 caster wheels to the bottom of the wastebasket. (FIGURE 1)

3. A socket-outlet should be near the equipment and be easily accessible.

4. Connect the power cord to any standard 120 volt AC outlet.

Microcut shredders have very sharp exposed blades on the underside. Do not touch. Unplug the

shredder before clearing paper jams.

Use care when mounting the shredder on the wastebasket. PUSH

DOWN

PUSH

DOWN

!Caution:

CORRECT FIT

FIGURE1

6ENGLISH

Control

Button

TopLidButtonManual-FeedSlot

MainPowerSwitch

The Main Power Switch must be “ON” to operate.

In an emergency, stop the shredder immediately and

turn switch to “OFF” mode. This completely discon-

nects all power to the machine.

ControlButton:

ONOFF

–O

CONTINUED NEXT PAGE

OPERATION

MainPowerOn/OffSwitch

(atbackofmachine)

•Auto-On(Green):

This setting automatically starts the shredder by loading paper into the paper tray or

inserting paper into the manual-feed slot. When the paper has passed through, the

shredder automatically stops.

7ENGLISH

OPERATION

•Off:

This setting turns off all features of the shredder. For safety reasons, we recommend that

you leave shredder in the OFF position when it is unattended or not in use.

•Reverse:

In the unlikely event of a paper jam, use the reverse setting to help clear the cutters of

paper that did not pass through. IMPORTANT: Never attempt to clear a jam using the

reverse function until you have emptied the wastebasket.

•Forward:

The forward setting can also be used to help clear the cutters in the event of a paper

jam. This allows you to manually activate the shredder into cutting mode.

LEDStatusIndicators:

•Overheat:

Red LED light indicates the shredder has shredded continuously beyond the maximum

running time, has overheated, and will automatically shut off. If this happens, switch the

shredder to Off for 45 minutes or longer before resuming normal operation.

•Overload:

Red LED light indicates when too much paper is inserted. Use the "Reverse" mode to

back up and reduce number of sheets.

•DoorOpen:

Red LED light indicates the shredder basket or top lid is not closed properly. Shredders

with pullout wastebaskets feature a safety power cut off upon bin removal. Make sure

the pull-out wastebasket is properly set back into place and the blue “Power On” indica-

tor is lit.

•BinFull:

When basket is full, RED light will indicate it needs to be emptied. While lit, the shred-

der will not operate until the wastebasket is cleared.

•FeedError:

RED light indicates paper in the paper tray cannot be grabbed by the feeders, Open

lid to make sure papers are unfolded and positioned properly.

CONTINUED NEXT PAGE

8ENGLISH

OPERATION

Auto-FeedShreddingOperation:

Put main power switch

in ON (–) position.

Turn power on.

Plug into ground standard US

household power outlet (120-V).

•Poweronshredder

•Openlidandloadpaper*

*Papershouldbeflatandalignedwith

papertray.

Features:

•Auto-ReverseTechnology:

When shredder detects over-capacity shredding, the motor will immediately stop and

reject paper before actual shredding begins.

Shreds:

• Maximum 120 sheets of letter size (8-1/2” x 11”) 20 lb bond paper per load

• Up to 10 sheets stapled paper stacks

• Up to 10 sheet clipped paper stacks

•Auto-FeedShreddingCapacity:

CONTINUED NEXT PAGE

9ENGLISH

OPERATION

Make sure you do not exceed sheet count per

pass (10 sheets max). Insertpaperas

straightaspossibleintofeedslotand

release.

Insert one credit card at a time into

the middle of the feed slot.

•Poweronshredder

•Closelid:

Put main power switch

in ON (–) position.

Turn power on.

Plug into ground standard

US household power outlet

(120-V).

The shredder automatically starts when you

close the lid.

Manual-FeedShreddingOperation:

NOTE:

• Always turn off and unplug the shredder when not in use.

• This shredder will shred staples and small paper clips. It is recommended that you remove paper clips

whenever possible to extend the lifespan of your shredder.

• Only shred credit cards by feeding them vertically i nto the middle of the entry, releasing when

shredding begins. Never feed more than one credit card at a time.

• Overfeeding the shredder: Shredding beyond the specified sheet capacity can result in extensive

damage to the shredder. Overfeeding will strain the machine and quickly wear and break the cutting

blades and internal components.

• Overheating with extended use: In the event that the shredder has shred continuously beyond the

maximum running time and overheating, the unit will automatically shut off. If this happens, switch the

shredder off for 45 minutes or longer before resuming normal operation.

10 ENGLISH

Warning:Failuretoproperlymaintainyourshredderwillvoidthewarranty.

Tomaintainwithshredderoil(shredderoilnotincluded):Oil the shredder blades every

month with basic vegetable, cooking oil or shredder oil. Follow oiling procedure below. It helps to

keep the shredder blades operating well over many years of use.

Oilingprocedure:

1. Open lid.

2. Carefully apply shredder oil across feed slot.

Tomaintainwithashreddersheet(shredder

sheetnotincluded):

• Simply insert shredder sheet into the manual-feed

slot the same way you would a piece of paper.

• Turn shredder in reverse mode for 3-5 seconds.

3. Close lid and turn shredder in reverse

mode for 3-5 seconds.

Note:Shredder oil and lubricant sheet are not included.

!Caution:

Shredder

Oil

DO NOT USE

AEROSOL PRODUCTS!

CONTINUED NEXT PAGE



MAINTENANCE

• Donotsprayorkeepanyaerosolproducts

inoraroundshredder.

• DONOTUSECANNEDAIRONSHREDDER.

CLEANING:

• ALWAYS UNPLUG THE SHREDDER BEFORE CLEANING!

• Only clean the shredder by carefully wiping the unit with a dry soft cloth or towel.

• Do not clean or immerse shredder in water. Having the unit wet may result in damage or malfunction to

the electrical components. If the shredder happens to get wet, be sure to completely dry the unit immedi-

ately with a cloth or towel.

• Never use anything flammable to clean the shredder. This may result in serious injury or damage to the product.
