Automotive Data Solutions TR2650A Manuale utente

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 1/21

OWNER’S MANUAL

INSTALLER TERMS OF USE

Automotive Data Solutions Inc. (“ADS”) products are strictly intended for installation by Certiﬁed Technicians

who are employed by a registered business specialized in the installation of automotive aftermarket electronics

products. Prior to beginning installation of an ADS product in a vehicle, it is the Certiﬁed Technician’s

responsibility to review the most current Product Guide, Install Guide and vehicle-speciﬁc notes available in

Weblink®. ADS is not responsible for any damages whatsoever, including but not limited to any consequential

damages, incidental damages, damages for loss of time, loss of earnings, loss of proﬁt, commercial loss, loss of

economic opportunity and the like that may or may not have resulted from the use, misuse, improper

installation or operation of its products. Purchasers sole contractual remedy is refund of the purchase price of

the ADS product(s). ADS reserves itself the right to suspend any Weblink® account without notice and decline

to oﬀer technical support to non-Certiﬁed Technicians, non-compliant Certiﬁed Technicians or end users.

END USER TERMS OF USE

ADS products are designed to remote start vehicles from a distance. In order to ensure your iDatastart system

meets all safety regulations and operates as intended by the manufacturer, please follow the usage

recommendations below:

• DO NOT use this product for any purpose other than its intended usage.

• DO NOT remote start a vehicle in an indoor or enclosed area (i.e. garage). Exhaust fumes are extremely

dangerous and can cause personal injury or death. Install carbon monoxide detectors in every living area that

can be exposed to vehicle exhaust fumes.

• DO NOT remote start a vehicle while it is being serviced. Follow the Valet Mode procedure as outlined in your

Owner’s Manual.

• DO NOT remote start a vehicle in gear.

• DO NOT remote start a vehicle with the key in the ignition.

• DO NOT remote start a vehicle left unattended with open windows, unlocked doors or open convertible top.

• DO NOT allow children handle or operate long range remotes.

• ALWAYS engage your emergency brake prior to exiting your vehicle. This may limit motion if the vehicle is

accidentally started in gear.

• AVOID remote starting your vehicle while passengers or pets are on board. This may increase the risk of

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 2/21

shifter being put in gear after vehicle has been remote started.

• AVOID parking your vehicle on an inclined surface or an area surrounded by obstacles. For manual vehicles,

ALWAYS ensure the Reservation Mode sequence, as outlined in your Owner’s Manual, is correctly engaged prior

to the next remote start.

• AVOID delaying the inspection of your iDatastart system in the event of malfunction. Immediately contact a

Certiﬁed Technician to ensure that installation or defective equipment is properly addressed.

REMOTE OVERVIEW

Your iDatastart remote start system may include one or both long-range remotes listed below.

Please take a moment to familiarize yourself with their general features.

REMOTE MODEL TR2650A

Technology LORA 2-WAY

Max. Range 1 mile

Buttons 5

Transmit Conﬁrmation (TX) Chime

Receive Conﬁrmation (RX) LCD icon + Chime + Vibration

Batteries Required 1 x CR2450

Avg. Battery Life 8-15 months

Warranty 1 year

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 3/21

Your iDatastart TR2650A LCD remote can display several icons following a command (button press) or

command notiﬁcation. Please take a moment to familiarize yourself with their descriptions below:

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 4/21

ICON DESCRIPTION

Lock

Unlock

Alarm Armed

Engine Key Started / Remote Started

Ignition On

Shock Sensor Disabled

Shock Sensor Triggered

Shock Sensor Warn Away

Valet Mode

Turbo Mode

Vibration Mode

Mute Mode

Battery Level

Time or Engine Runtime, or Temperature or Error Codes or Other

Door Open

Trunk Open

Hood Open

Transmitting

Timer Alarm

AUX 2

AUX 3

AUX 4

Parking Light / Car Finder

Car Call

Time Start

Shift

Keypad Lock

Pit Stop

Save

REMOTE COMMANDS & CONFIRMATIONS

In order to get the most out of your iDatastart remote, please take a moment to get acquainted with the

following commands and conﬁrmations below:

NOTES:

1. All functions must be enabled by an Authorized Dealer during installation to be functional on remote

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 5/21

2. Non-highlighted icons = Press & release button

3. Highlighted (grey) icons = Press & hold button for 2.5 seconds

4. Coma (,) between icons = Press buttons one after the other

5. Plus (+) between icons = Press buttons together

6. Timeout between each button press = 3 seconds

7. Function* = Available in 2nd Car Mode

8. 3 chirps following a remote command = Option not available. Contact your Authorized Dealer.

COMMAND Power ON Remote

BUTTON

DESCRIPTION Turns remote on.

COMMAND Power OFF Remote

BUTTON

DESCRIPTION Turns remote oﬀ to save battery life.

COMMAND Lock & Arm

BUTTON

DESCRIPTION Secures your vehicle by locking the doors and arming

the alarm.

CONFIRMATION • 1 chirp, display and

COMMAND Unlock & Disarm

BUTTON

DESCRIPTION Accesses your vehicle by unlocking the doors and disarming the alarm.

CONFIRMATION • 2 chirps, display and

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 6/21

COMMAND Query*

BUTTON

DESCRIPTION Queries vehicle and vehicle battery voltage and

interior temperature.

CONFIRMATION

• Query voltage: 1 chirp, display voltage ex:

for 3 seconds.

• Query temperature: 1chirp, display temperature ex:

for 3 seconds.

• Query shut down error: 3 chirps, display error ex:

for 3 seconds.

COMMAND Panic*

BUTTON

DESCRIPTION Triggers the panic siren.

CONFIRMATION • 1 chirp, and ﬂash 5 times.

COMMAND AUX 5*

BUTTON

DESCRIPTION To be completed by Authorized Dealer if applicable

CONFIRMATION • 1 chirp, display

COMMAND Trunk Release*

BUTTON

DESCRIPTION Releases the trunk or hatch.

CONFIRMATION • 1 chirp, display

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 7/21

COMMAND Engine Start/Stop*

BUTTON

DESCRIPTION Starts and stops the engine.

CONFIRMATION

• Engine start: 1 chirp.

• Engine run: 4 chirps, display and remaining

runtime.

• Start error: 1 long chirp, display start error ex:

+ for 3 seconds.

• Engine stop: 2 chirps.

COMMAND AUX 1

BUTTON

DESCRIPTION To be completed by Authorized Dealer if applicable

CONFIRMATION • 1 chirp, display

COMMAND AUX 2

BUTTON

DESCRIPTION To be completed by Authorized Dealer if applicable

CONFIRMATION • 1 chirp, display

COMMAND AUX 3

BUTTON

DESCRIPTION To be completed by Authorized Dealer if applicable

CONFIRMATION • 1 chirp, display

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 8/21

COMMAND AUX 4

BUTTON

DESCRIPTION To be completed by Authorized Dealer if applicable

CONFIRMATION • 1 chirp, display

COMMAND 2nd Car Mode

BUTTON *

DESCRIPTION

Controls two iDatastart-equipped vehicles using one

remote. Works with all functions marked with an

asterisk (*).

CONFIRMATION • Same as 1st car.

COMMAND Silent Lock*

BUTTON

DESCRIPTION Disables the vehicle’s horn and alarm siren.

CONFIRMATION • 1 chirp, display and

COMMAND Silent Unlock*

BUTTON

DESCRIPTION Disables the vehicle’s horn and alarm siren.

CONFIRMATION • 2 chirps, display and

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 9/21

COMMAND Valet Mode ON/OFF

BUTTON

DESCRIPTION

Turns oﬀ remote start and security features when

servicing your vehicle or valet parking. Keyless entry

features remains functional.

CONFIRMATION • ON: 1 chirp, display

• OFF: 2 chirps, disappears.

COMMAND Runtime Extend

BUTTON

DESCRIPTION Seamlessly extends your engine runtime without

restarting your vehicle.

CONFIRMATION • 4 chirps, display runtime minutes ex:

COMMAND Mute ON/OFF

BUTTON

DESCRIPTION

Disables the vehicle’s horn and alarm siren even

when alarm is triggered. Remote will still receive

alarm notiﬁcation.

CONFIRMATION

• ON: 1 chirp.

• OFF: 2 chirps, display

COMMAND Ignition Lock ON/OFF

BUTTON

DESCRIPTION Automatically locks doors when engine is running.

CONFIRMATION • ON: 1 chirp, display for 3 seconds.

• OFF: 2 chirps, display for 3 seconds.

TR2650A

2022-02-7 © Automotive Data Solutions Inc. 10/21

COMMAND Passive Lock & Arm ON/OFF

BUTTON

DESCRIPTION Automatically locks and arms your vehicle 60 seconds

after you unlock it.

CONFIRMATION • ON: 1 chirp, display for 3 seconds.

• OFF: 2 chirps, display for 3 seconds.

COMMAND Turbo ON/OFF

BUTTON

DESCRIPTION Cools down your turbo before turning the engine oﬀ.

Programmable runtime from 30 seconds to 4 minutes.

CONFIRMATION • ON: 1 chirp, display

• OFF: 2 chirps, disappears.

COMMAND Weather Start ON/OFF

BUTTON

DESCRIPTION

Sets your vehicle to automatically remote start every

2, 3 or 4 hours (programmable) or from a temperature

sensor sold separately.

CONFIRMATION • ON: 1 chirp, display

• OFF: 2 chirps, disappears.
