TM-XGT (RS485)
Solution Guide
ii © Copyright Reserved Autonics Co., Ltd.
© Copyright Reserved Autonics Co., Ltd. 3
Preface
Thank you very much for selecting Autonics products.
Please familiarize yourself with the information in this manual and in the product manuals before using
them.
This solution guide contains information about a specific architecture solution and does not replace any
specific product documentation.
This document does not attempt to describe the entire solution architecture and configuration but only
introduce some basics procedures. Customization of this solution can be made by the users in respect of
safety laws and regulations.
4 © Copyright Reserved Autonics Co., Ltd.
Document Guide
This manual provides procedure steps for a particular solution architecture. It does not offer any
guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without written permission
of Autonics.
This manual is not provided as part of the product package. Please visit our home-page
(www.autonics.com) to download a copy.
The content of this manual may vary depending on updates of the product software and others
unforeseen developments within Autonics. It is subject to change without prior notice. Upgrade
notices are published through our homepage.
We contrived to describe this manual the easiest and more accurate way. However, if there are
any corrections required or questions, please notify us these remarks on our homepage.
© Copyright Reserved Autonics Co., Ltd. 5
Document Symbols
Symbol
Description
Additional information about a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product
damage.
An example of the concerned feature's use.
※1
Annotation mark.
6 © Copyright Reserved Autonics Co., Ltd.
Document Version History
Date
Version
Author
Description
August 24th 2016
v1.0
기술지원팀 - YCG
Document creation
November 17th 2017
v2.0
기술지원팀 - GTE
Document revision, template update
Add several sections, change example
© Copyright Reserved Autonics Co., Ltd. 7
Table of Contents
Preface.................................................................................................................3
Document Guide .................................................................................................4
Document Symbols.............................................................................................5
Document Version History.................................................................................6
Table of Contents................................................................................................7
1Solution Overview.......................................................................................9
1.1 Solution description 9
1.2 Solution components and version 10
1.3 Solution architecture 10
2TM4 Communication Settings..................................................................11
3XGT Project Settings ................................................................................13
4Data Exchange Example...........................................................................19
4.1 Solution overview 19
4.1.1 Communication objective 19
4.1.2 TM4 –XGT connection 19
4.2 XG5000 program 20
4.2.1 P2P Block definition 20
4.2.2 Ladder program 22
4.3 Data exchange test 24
5Appendix....................................................................................................27
5.1 TM device connection to DAQ Master 27
6Troubleshooting........................................................................................31
6.1 XG5000: I/O synchronization 31
8 © Copyright Reserved Autonics Co., Ltd.
1 Solution Overview
© Copyright Reserved Autonics Co., Ltd. 9
1Solution Overview
1.1 Solution description
Autonics TM4 device from the TM series is a multi-channel PID temperature controller, capable of
controlling various type of power controllers thanks to its build-in SSR driver or relay output and
simultaneously controlling up to 4 elements, (up to 2 elements for the TM2 type). It has also build-in serial
Modbus connection through RS-485 pins.
Thanks to its characteristic, the TM device can be added in any existing automation architecture with
Modbus connection and device parameters or statuses, values limits and Present Value can be
monitored or set, allowing remote access to key-data.
This solution brings the following benefits to your current installation:
Allows to monitor in real time several TM devices status and feedback values
Allows settings of several TM devices parameters like setting values or PID parameters from only
1 device
Allows data exchange between different device types
1 Solution Overview
10 © Copyright Reserved Autonics Co., Ltd.
1.2 Solution components and version
Hardware / Software
Version
Note
MS Windows
Win 7
TM4-N2RB
Autonics product.
XG-5000
v4.22
LS product. Release 2017.09.29
XGT Series(Cnet)
LS product
1.3 Solution architecture
Bridges should be addded between the “Tx+“ and “Rx+“ pins and between the “Tx-“ and “Rx-“ pins of the
XGL communication module.
Indice
