AV Access HDEX80-KVM Manuale utente
HDEX80-KVM
1080P HDMI KVM Extender with USB2.0
User Manual
Disclaimers
The information in this manual has been carefully checked and is believed to be
accurate. AV Access Technology Limited assumes no responsibility for any
infringements of patents or other rights of third parties which may result from its
use.
AV Access Technology Limited assumes no responsibility for any inaccuracies that
may be contained in this document. AV Access Technology Limited also makes no
commitment to update or to keep current the information contained in this
document.
AV Access Technology Limited reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright
Copy, Reproduce, Distribute and/or Edit of this document or part of it as well as
utilization of its contents and communication thereof to others without express
authorization are prohibited. Offenders will be held liable for payment of damages.
All rights created by patent grant or registration of a utility model or design patent
are reserved. Copyright ©2017 AV Access Technology Limited All rights reserved.
Trademarks Notice
All products or service names mentioned in this document may be trademarks of
the companies with which they are associated.
Contact Us
Business inquiry: services@avaccess.com
Technical problems: support@avaccess.com
Important Safety Instructions
Do not expose this device to rain, moisture, dripping or splashing. No objects
filled with liquids, such as vases, shall be placed on the device.
Do not install or place this unit in a bookcase, built-in cabinet, or in another
confined space. Ensure the unit is well ventilated.
To prevent risk of electric shock or fire hazard due to overheating, do not
obstruct the unit’s ventilation openings with newspapers, tablecloths,
curtains, or similar items.
Do not install near any heat sources such as radiators, heat registers, stoves,
or other device (including amplifiers) that produce heat.
Do not place sources of naked flames, such as lighted candles, on the unit.
Clean this device only with dry cloth.
Unplug this device during lightning storms or when unused for long periods
of time.
Protect the power cord from being walked on or pinched, particularly at
plugs.
Only use attachments / accessories specified by the manufacturer.
Refer all servicing to qualified service personnel.
Introduction
Table of Contents
Introduction..........................................................................................................2
Overview .................................................................................................................................. 2
Features .................................................................................................................................... 2
Package Contents.................................................................................................................. 3
Panel .......................................................................................................................................... 4
Transmitter ..................................................................................................................... 4
Receiver........................................................................................................................... 5
Installation and Application.................................................................................6
Brackets Installation.............................................................................................................. 6
Steps to install the device in a suitable location................................................. 6
Application .............................................................................................................................. 7
Installation requirements........................................................................................... 7
Specifications .......................................................................................................9
Trouble Shooting................................................................................................10
Steps of Regular Troubleshooting Routine......................................................... 10
Typical Questions ....................................................................................................... 10
Warranty .............................................................................................................11
Introduction
Introduction
Overview
The HDEX80-KVM extends full HD HDMI signal up to 80m/260ft via a single Cat X
cable, without any video loss and time delay. It supports USB 2.0 pass-through.
With USB Host connector in transmitter, and USB Device connectors in receiver, it
provides remote source PC control with keyboard and mouse, interactive display
operation, data transmission and USB streaming over distances up to 80m/260ft. It
has many professional designs which suitable for various application scenario,
especially for engineering project usage. Two-way PoE (Power over Ethernet),
integrates power into the Cat 5e/6 cable, only one power adapter is needed to
either transmitter or receiver.
Features
Extends full HD HDMI signal up to 80m/260ft via a single Cat X cable without
signal loss and delay
Extends high speed USB 2.0 signal (480Mbps) up to 260ft/80m, provides
2xUSB 2.0 ports at display end
Supports two-way PoE (Power over Ethernet), only one power adapter is
needed to either transmitter or receiver
Auto EDID management automatically adjusts to overcome compatibility
issues
Plug and play, no driver needed.
Introduction
Package Contents
Before you start the installation of the product, please check the package
contents:
HDEX80-KVM Transmitter x 1
HDEX80-KVM Receiver x1
Power Adapter (DC 12V 2A) x 1
USB type-A to type-A Cable x 1
Mounting Brackets (with Screws) x 4
User Manual x 1
Introduction
Panel
Transmitter
No. Name Description
1 HDMI In HDMI signal input. Connects to an HDMI source device
2 DC 12V
Power input. Connects to the power adapter provided.
Only one power adapter is needed at transmitter or
receiver side.
3 UTP Out Connects to the receiver via Cat X cable.
4 USB (PC) Connects to a computer.
a Power LED Lights on when the device is powered on.
b Status LED On: HDMI data is being transmitted.
Off: No signal.
c USB (PC) LED
Breathing Status:No USB device is connected.
Solid on:USB device is linked.
Flashing:USB data is being transmitted.
Introduction
Receiver
No. Name Description
1 HDMI Out HDMI signal output. Connect to an HDMI display device
2 DC 12V
Power input. Connect to the power adapter provided.
Only one power adapter is needed at transmitter or
receiver side.
3 UTP In Connects to the transmitter via Cat X cable.
4 USB Device Connects to the USB devices.
a Power LED Lights on when the device is powered on.
b Status LED On:HDMI data is being transmitted.
Off:No signal.
c USB Device
LED
Breathing Status:No USB device is connected.
Solid on:USB devices are linked.
Flashing:USB data is being transmitted.
Installation and Application
Installation and Application
Brackets Installation
Note: Before installation, please ensure HDEX80-KVM is disconnected from the
power source.
Steps to install the device in a suitable location
1. Attach the installation bracket to the enclosure using the screws that were
provided in the package separately. The bracket height can be adjusted
up/down or bracket face up or down.
2. The bracket is attached to the enclosure as shown.
3. Repeat steps 1-2 for the other side of the unit.
4. Attach the brackets to the surface you want to hold the unit against using
the screws (provided by others).
5. Repeat steps 1-4 to install the receiver.
