Avalue Technology LX800 Manuale utente

Part No. E20173711A6R

EPC Series

VIA Eden V4/ Intel® Core™Duo/ Intel® Atom™/

AMD Geode™ LX 800 Tiny Box PC

Quick Reference Guide

7th Ed –17 March 2011

EPC-Series

2 EPC Series Quick Reference Guide

FCC Statement

THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS

SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING

INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS

FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.

THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST

HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A

COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN

RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN

ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL

INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE

HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO

CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

A Message to the Customer

Avalue Customer Services

Each and every Avalue’s product is built to the most exacting specifications to ensure

reliable performance in the harsh and demanding conditions typical of industrial

environments. Whether your new Avalue device is destined for the laboratory or the factory

floor, you can be assured that your product will provide the reliability and ease of operation

for which the name Avalue has come to be known.

Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To

ensure you get the full benefit of our services, please follow the instructions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions, you can

easily find answers in your product documentation. These answers are normally a lot more

detailed than the ones we can give over the phone. So please consult the user’s manual

first.

To receive the latest version of the user’s manual; please visit our Web site at:

http://www.avalue.com.tw/

Quick Reference Guide

EPC Series Quick Reference Guide

If you still cannot find the answer, gather all the information or questions that apply to your

problem, and with the product close at hand, call your dealer. Our dealers are well trained

and ready to give you the support you need to get the most from your Avalue’s products. In

fact, most problems reported are minor and are able to be easily solved over the phone.

In addition, free technical support is available from Avalue’s engineers every business day.

We are always ready to give advice on application requirements or specific information on

the installation and operation of any of our products. Please do not hesitate to call or e-mail

us.

Headquarters and Branch

Avalue USA

Avalue Technology Inc.

7F, 228, Lian-cheng Road, Chung Ho City, Taipei,

Taiwan

Tel:+886-2-8226-2345

Fax: +886-2-8226-2777

Information:sales@avalue.com.tw

Service: service@avalue.com.tw

Avalue Technology Inc.

9 Timber Lane, Marlboro, NJ 07746-1443

Tel: (732) 414-6500

Fax: (732) 414-6501

Information: sales@avalue-usa.com

Service: support@avalue-usa.com

BCM Advanced Research

Avalue Europe

BCM Advanced Research

an Avalue Company

7 Marconi, Irvine, CA92618

Tel: +1-949-470-1888

Fax: +1-949-470-0971

Information: BCMSales@bcmcom.com

Web: www.bcmcom.com

Avalue Europe A/S

Moelledalen 22C, 3140

Aalsgaarde, Denmark

Tel: +45-7025-0310

Fax:+45-4975-5026

Information: sales.e[email protected].tw

Service: service.[email protected].tw

Avalue China

Avalue Japan

Avalue Technology Inc.

Room 805, Building 9,No.99 Tianzhou Rd.,

Caohejing Development Area,

Xuhui District, Shanghai

Tel: +86-21-5169-3609

Fax:+86-21-5445-3266

Information: sales.chi[email protected].cn

Service: service@avalue.com.tw

Avalue Technology Inc.

2F keduka-Bldg, 2-27-3 Taito,

Taito-Ku, Tokyo 110-0016 Japan

Tel: +81-3-5807-2321

Fax: +81-3-5807-2322

Information: sales.japa[email protected].tw

Service: service@avalue.com.tw

EPC-Series

4 EPC Series Quick Reference Guide

Product Warranty

Avalue warrants to you, the original purchaser, that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Avalue, or which have been subject to

misuse, abuse, accident or improper installation. Avalue assumes no liability under the

terms of this warranty as a consequence of such events. Because of Avalue’s high

quality-control standards and rigorous testing, most of our customers never need to use our

repair service. If any of Avalue’s products is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will be billed according

to the cost of replacement materials, service time, and freight. Please consult your dealer

for more details. If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU type and

speed, Avalue’s products model name, hardware & BIOS revision number, other

hardware and software used, etc.) Note anything abnormal and list any on-screen

messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your manual, product, and any

helpful information available.

3. If your product is diagnosed as defective, obtain an RMA (return material authorization)

number from your dealer. This allows us to process your good return more quickly.

4. Carefully pack the defective product, a complete Repair and Replacement Order Card

and a photocopy proof of purchase date (such as your sales receipt) in a shippable

container. A product returned without proof of the purchase date is not eligible for

warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid to your

dealer.

Quick Reference Guide

EPC Series Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x EPC-3711 VIA Eden Tiny Box PC (with ECM-3711-E10 inside) or

1 x EPC-CX700M VIA Eden Tiny Box PC (with ECM-CX700 inside)or

1 x EPC-945 Intel® Tiny Box PC (with ECM-945GME inside ) or

1x EPC-AT270 Inte® l Tiny Box PC (with ECM-945GSE inside)

1 x EPC-LX800W AMD Geode™ LX 800 Tiny Box PC (with ECM-LX800W)

1 x Quick Reference Guide

1 x DVD-ROM contains the followings:

—User’s Manual (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

Other major components include the followings:

—1 x PS/2 keyboard and mouse Y cable (6-pin, Mini-DIN)

—1 x SATA cable

—1 x AC to DC adapter

—1 x Protective Cover

EPC-Series

6 EPC Series Quick Reference Guide

1.3 System Specifications

Model

EPC-3711

EPC-CX700

CPU

Onboard VIA Eden V4 1 GHz

Onboard VIA Eden V4 500 MHz

BIOS

Award 512 KB Flash BIOS

System Chipset

VIA CN700/VT8251

VIA CX700M

I/O Chipset

VIA VT1211

System Memory

One 200-pin SODIMM supports up to 1 GB DDR2 400/533 SDRAM

SSD

One CompactFlash Type I/II socket with ejector

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

H/W Status Monitor

Monitoring system and CPU temperature, voltage,

Auto throttling control when CPU overheats

Display

VIA ProSavage CN700 integrated

2D/3D graphics engine

VIA CX700M with integrated 2D and

3D Graphics engine

Audio

VIA VT1616 supports 5.1 CH Audio

Realtek ALC883 supports 5.1 CH

Audio and 7.1 CH with SPDIF

Ethernet

Dual Realtek RTL8111B 1000Base-T

Fast Ethernet controllers

Dual Realtek RTL8101L

System Indicators

2 LED indicators show the power and HDD

COM Port

1 x RS-232, 1 x RS232/422/485, Setting by BIOS

Ethernet Port

2 x RJ-45

VGA / LCD Port

1 x DB-15

Audio Port

Mic-in, Line-in, Line-out

USB Port

3 x USB 2.0

Mouse & KB

1 x PS/2 mini DIN

Power Input

100 ~ 240 Vac / 50 ~ 60 Hz

Power Output

+5 Vdc / 8 A (40W)

Operating Temperature

0~40°C (32~104°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension (W x D x H)

7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)

Weight

2.65 lbs (1.2 Kgs)

Quick Reference Guide

EPC Series Quick Reference Guide

Model

EPC-945

EPC-AT270

CPU

Supports 65nm Intel® µFC-PGA

478/µFC-BGA 479 Core™Duo/Core™

Duo/Celeron® M CPU

Onboard Intel® Atom™N270 1.6GHz

CPU

BIOS

Award 4 MBit Flash BIOS

Award 8 MBit Flash BIOS

System Chipset

Intel® 945GME / ICH7-M

Intel® 945GSE/ICH7-M

I/O Chipset

Winbond W83627HF-AW

ITE 8712F

System Memory

One 200-pin SODIMM supports up to 2

GB DDR2 400/533/667 SDRAM

One 200-pin SODIMM supports up to 2

GB DDR2 400/533 SDRAM

SSD

One CompactFlash Type I/II socket

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

Display

Intel® 945GME Integrated GMA 950

graphic

Intel® 945GSE Integrated

Audio

Realtek ALC883 supports 7.1-CH Audio

Realtek ALC655 supports 5.1-CH

Audio

Ethernet

Dual Realtek RTL8111C PCI-E Gigabit

Ethernet, supports wake on LAN

(RTL8111B for Rev. A1)

Dual Marvell 88E8053 Gigabit Ethternet,

supports Wake on LAN

System Indicators

2 LED indicators show the power and HDD

Drive Bay

Mounting kit for one 2.5”HDD(hidden)

Expansion Interface

-------

1 x Mini PCIe

Serial Port

1 x RS-232

1x RS-232, 1xRS232/422/485

Ethernet Port

2 x RJ-45

WiFi

Optional (USB Module)

DVI

------

1 x DVI (Optional)

VGA / LCD Port

1 x DB-15

Audio Port

Mic-in, Line-in, Line-out

USB Port

3 x USB 2.0

5 x USB 2.0

Mouse & KB

1 x PS/2 mini DIN

1 x PS/2 mini DIN (Optional)

Power Input

100 ~ 240 Vac / 50 ~ 60 Hz

Power Output

+12 V

Operating

Temperature

0~40°C (32~104°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension (W x D x H)

7.0" x 5.6" x 2.0" (178 x 142 x 50 mm)

7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)

Weight

2.7 lbs (1.2 Kgs)

Mounting

VESA Compliance

EPC-Series

8 EPC Series Quick Reference Guide

Model

EPC-LX800W

CPU

Onboard AMD Geode™ LX 800 @ 500MHz CPU

BIOS

Award 4 MBit Flash BIOS

System Chipset

AMD Geode™ LX 800/ CS5536

I/O Chipset

NuvoTon W83627DHG

System Memory

One 200-pin SODIMM supports up to 1 GB DDR 333/400 SDRAM

SSD

One CompactFlash Type I/II socket

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

Display

AMD Geode LX800 with Integrated Graphics Engine

Audio

Realtek ALC203 supports 2-CH Audio

Ethernet

Dual Realtek RTL8101L 10/100 Rthernet

System Indicators

2 LED indicators show the power and HDD

Drive Bay

Mounting kit for one 2.5” HDD(hidden)

Expansion Interface

N/A

Serial Port

2x RS-232

Ethernet Port

2 x RJ-45

WiFi

Optional (USB Module)

VGA

1 x DB-15

Audio Port

Line-out

USB Port

3 x USB 2.0

Mouse & KB

1 x PS/2 mini DIN

Power Input

100 ~ 240 Vac / 50 ~ 60 Hz

Power Output

+5V

Operating Temperature

-40 ~ 75°C (-40~167°F)

Storage Temperature

-20 to +75°C (-4~167°F)

Relative Humidity

5 to 90% @ 40°C (104°F), relative humidity, non-condensing

Dimension (W x D x H)

7.0" x 4.4" x 2.0" (178 x 112 x 50 mm)

Weight

2.7 lbs (1.2 Kgs)

Mounting

VESA Compliance

Quick Reference Guide

EPC Series Quick Reference Guide

1.4 System Overview

1.4.1 Front View

Connectors

Label

Function

Note

POWER

Power on button

LED

System power indicator

USB

USB 2.0 connector

1.4.2 Rear View

EPC-3711/EPC-CX700

EPC-Series

10 EPC Series Quick Reference Guide

EPC-AT270

EPC-945

EPC-LX800W

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Avalue Technology Scrivania

Avalue Technology

Avalue Technology SID-21W9 Manuale utente

Avalue Technology

Avalue Technology EBM-PNV Manuale utente

Avalue Technology

Avalue Technology EPC Series Manuale utente

Avalue Technology

Avalue Technology BMX-T522-SK Manuale utente

Avalue Technology

Avalue Technology EPC-CDV Manuale utente

Avalue Technology

Avalue Technology EMS-TGL Series Manuale utente

Avalue Technology

Avalue Technology LPC-0833 Manuale utente

Avalue Technology

Avalue Technology PPC-1501 Manuale utente

Avalue Technology

Avalue Technology LPC-1009 Series Manuale utente

Avalue Technology

Avalue Technology ARC-1209 Manuale utente

Avalue Technology

Avalue Technology EPC-BSW Manuale utente

Avalue Technology

Avalue Technology EPC-CDV Manuale utente

Avalue Technology

Avalue Technology EMS-SKLU Series Manuale utente

Avalue Technology

Avalue Technology UB-A200 Manuale utente

Avalue Technology

Avalue Technology EPC-3711 Manuale utente

Avalue Technology

Avalue Technology BMX-T521-BSW Manuale utente

Avalue Technology

Avalue Technology NUC-EHL Manuale utente

Avalue Technology

Avalue Technology HPS-SRSU4A Manuale utente

Avalue Technology

Avalue Technology BMX-T521-BYT Manuale utente

Avalue Technology

Avalue Technology ERS-CDVE Manuale utente

Avalue Technology

Avalue Technology EMS-BYTC2 Manuale utente

Avalue Technology

Avalue Technology EES-CDV Manuale utente

Avalue Technology

Avalue Technology VMS-CFS Manuale utente

Avalue Technology

Avalue Technology HPS-621UTA Manuale utente

Manuali Scrivania popolari di altre marche

HP m9060n - Pavilion - Elite Scheda tecnica

Asus

Asus E210 Series Manuale utente

Dell

Dell Inspiron 600m Manuale utente

Dell

Dell Inspiron 3662 Manuale utente

TotalFlow

TotalFlow uFLO Manuale utente

HP Presario SV7000 - Desktop PC Manuale utente

HP ProDesk 400 G5 Manuale

Logitech

Logitech MK320 Manuale utente

Dell

Dell XPS 730 H2C Manuale utente

Sony

Sony Vaio Series Manuale utente

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuale utente

Alto

Alto MD 250 Manuale utente

Lenovo

Lenovo ThinkCentre Edge 72 Manuale

Lenovo

Lenovo ThinkStation D20 Manuale

Arbor Technology

Arbor Technology FPC-7800 Series Manuale utente

Sony

Sony VAIO VGX-TP1 Series Manuale utente

Asus

Asus Eee Box B204 Manuale utente

Dell

Dell Optiplex 9010 All In One Manuale utente
