Avalue Technology APC-18W5 Manuale utente

Part No. E201718W5A2R

APC-18W5

18" WXGA TFT Fanless Plastic Multi-Touch Full Flat Panel

PC with ATOM Dual Core Solution

Quick Reference Guide

2nd–18 November, 2013

APC-18W5

2 APC-18W5 Quick Reference Guide

Contents

1. Getting Started............................................................................................................3

1.1 Safety Precautions ................................................................................................3

1.2 Packing List...........................................................................................................3

1.3 System Specifications ...........................................................................................4

1.4 System Overview...................................................................................................6

1.4.1 Front View.................................................................................................................................... 6

1.4.2 Rear View..................................................................................................................................... 7

1.5 System Dimensions...............................................................................................8

2. Hardware Configuration...........................................................................................10

2.1 Jumper and Connector Settings, Driver and BIOS Installation............................10

2.2 Stand Installation.................................................................................................11

Quick Reference Guide

APC-18W5 Quick Reference Guide

1. Getting Started

1.1 Safety Precautions

Warning!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden power

surges. Only experienced electronics personnel should

open the PC chassis.

Caution!

Always ground yourself to remove any static charge before

touching the CPU card. Modern electronic devices are very

sensitive to static electric charges. As a safety precaution,

use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded

bag when they are not in the chassis.

1.2 Packing List

1 x 18" WXGA TFT Fanless Plastic Multi-Touch Full Flat Panel PC with

ATOM Dual Core Solution

1 x CD/DVD-ROM containing the following:

—Quick Reference Guide (this manual in PDF file)

—Ethernet driver and utilities

—VGA drivers and utilities

—Audio drivers and utilities

—Wi-Fi drivers and utilities

—Touch controller drivers and utilities

1 x Power Adapter

1 x Stand for Panel PC (with 6 screws & 5 rubber feet)

APC-18W5

4 APC-18W5 Quick Reference Guide

1.3 System Specifications

Panel

Specifications

APC-18W05

LCD size

18.5", 16 : 9

Display type

WSGA TFT

Resolution

1366 x 768

Color

16.7M

Pixel pitch

0.300mm(H) x 0.300mm(V)

Luminance

300 cd/m²

Contrast ratio

300

Viewing angle

80(U), 80(D), 85(L), 85(R)

Response time

5 ms

Backlight

2 x CCFL

Touch Type

5 Wire resistive

Touch Light Transmission

80%

Touch Interface

USB

System

Board

EBM-PNV

CPU

Onboard Intel® Atom™ D525 Dual-Core 1.8 GHz CPU

System Chipset

Intel ICH8-M

I/O Chip

Winbond W83627DHG-P

Memory

Onboard 1 GB up to 2GB & one 204-pin SODIMM support up to 4 GB DDR3

800 SDRAM

SSD

One CF socket supports Type I / II Compact Flash Card

HDD Drive Bay

One 2.5" SATA HDD/SSD

WiFi

Optional USB or Mini PCIe WiFi module

Watchdog Timer

Reset: 1 ~ 255min. and 1sec. or 1min./step

H/W Status Monitor

Monitoring system temperature and voltage. Auto throttling control when

CPU overheats

Expansion Slot

One Mini PCIe slot

Quick Reference Guide

APC-18W5 Quick Reference Guide

Rear Panel I/O

Serial Port

1 x RS-232

Ethernet

1 x RJ-45

VGA

1 x DB-15

Audio port

1 x Line out

USB

2 x USB 2.0

KB/MS

1 x PS/2 KB & MS

Speaker

2W x 2

Mechanical & Environmental

System Fan

Passive Heat Sink

Color

Front & Rear panel Black (Plastics)

Mounting

Wall/Stand/VESA 100 mm X 100 mm

Power

Requirement

+12V ~ +26V DC Power Input

Power Adapter

Input: 100~250 Vdc/ 47~63 Hz

Output: +12 Vdc / 5 A (60W)

Operating Temperature

0 to 40°C (32 to 140°F )

Storage Temperature

-10°C to 50°C

Relative Humidity

0%~90% relative humidity, non-condensing

Dimensions

443 x 290 x 59.8 mm

Weight

4.54Kgs

APC-18W5

6 APC-18W5 Quick Reference Guide

1.4 System Overview

1.4.1 Front View

Note: Programmable keys are available to be programmed by the user; they are

unable to work unless programmed.

Quick Reference Guide

APC-18W5 Quick Reference Guide

1.4.2 Rear View

Connectors

Label

Function

Note

COM

Serial port

DB-9 male connector

DC in

DC-in power connector

HDD

HDD LED

LAN

10/100/1000Base-Tx Ethernet connector

RJ-45

KBMS

PS/2 keyboard & mouse

6-pin Mini DIN

LINE OUT

Line-out audio jack

PWR

Power LED

Reset

Rest button

USB

USB 2.0 connector

VGA

CRT connector

DB-15 female connector

APC-18W5

8 APC-18W5 Quick Reference Guide

1.5 System Dimensions

(Unit: mm)

Quick Reference Guide

APC-18W5 Quick Reference Guide

APC-18W5

10 APC-18W5 Quick Reference Guide

2. Hardware

Configuration

2.1 Jumper and Connector Settings, Driver and BIOS Installation

Please refer to EBM-PNV Quick Installation Guide or User’s Manual.

Note: If you need more information, please visit our website:

http://www.avalue.com.tw
