Avanti WDB101 Manuale utente

1



INSTRUCTION MANUAL

MANUAL DE INSTRUCCIONES



Model Number/ No. de Modelo: WDB101

CLOTHES DRYER STACKING BRACKET



CAUTION:

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING

INSTRUCTIONS.

Avanti has a policy of continuous improvement on its products and reserves the right to change materials and

specifications without notice.



Avanti Products

P.O. Box 520604 - Miami, Florida 33152

www.avantiproducts.com



2

Beforebeginningtoassemblethisproduct,reviewandensurethatyouhavereceivedallofthepartsas

listed/shownbelow:



**PartI:2additionalpiecesaresuppliedasspares.

ComponentsIncluded

PartCode:Description Quantity

ABottomSupportFrame 1

BMiddleSupportFrame 1

CTopShel

1

DRearLeg(Bottomsection) 2

EFront/RearLeg(Topsection) 4

FFrontLeg(Bottomsection) 2

GAnti‐TipSafetyBracket(Part1of2) 2

HAnti‐TipSafetyBracket(Part2of2) 2

IShelf/FrameSupportClips 30**

JSpannerWrench 1

KNut(ForAnti‐TipSafetyBracketAssembly) 2

LWallAnchor2

MPhillipsHeadSel

‐TappingScrew 2

NPhillipsHeadMetalScrew (ForAnti‐TipSafetyBracket

Assembly)

2

OLogo/SupportBar 1

PFront/RearLeg(Middlesection) 4

QPlasticPad

(Notforinstallation.Forpackingprotectiononly)

4

3

AssembledDimensions

4

YourWasher/DryerStackingBracketisdesignedtoaccommodatebothtoploadingorfrontloading

washingmachines.Followtheassemblyinstructionsbelowtoassemblethebrackettofityourspecific

washingmachinetype.ImagesshowninthisinstructionguideareforassemblyforusewithaTOP‐Load

washer.



Step1:Assemblingthelegs:

WhenusingwithaTOP‐Loadwasher.

Assembletherearlegsbyscrewingtogetherallthreesectionsofthe

rearleg.

PartD–RearLeg(Bottomsection)

PartP–Front/RearLeg(Middlesection)

PartE–Front/RearLeg(Topsection)

Assemblethefrontlegsbyscrewingtogetherallthreesectionsofthe

frontleg.

PartF–FrontLeg(Bottomsection)

PartP–Front/RearLeg(Middlesection)

PartE–Front/RearLeg(Topsection)



WhenusingwithaFRONT‐Loadwasher.

Assembletherearlegsbyscrewingtogetheronlythebottomandtop

sectionsoftherearleg

(PartsD&E).

Assemblethefrontlegsbyscrewingtogetheronlythebottomandtop

sectionsofthefrontleg

(PartsF&E).



Step2:AssemblingtheBottomSupportFrame.

WesuggestthatyouputtheUshapedbottomsupportframe

(PartA)inaverticalposition.Asthiswillallowyoutoinsert

thelegsandtheShelf/Framesupportclipswithease.



a) LaytheBottomsupportframe(PartA)onitsbackwith

eachsidebarfacingupwards.

b) Inserteachoftherearlegs(assembledinstepone)

intotheholesatbothrearcornersofthesupport

frame.

c) UsingtheShelf/Framesupportclips(PartI)insertthe

plastictaperedclipsintotheappropriategrooveson

eachleg.(Seetheimage).

d) Slightlypressthebottomsupportframedownwardon

tothesupportclips.

e) InserteachoftheFRONTlegsintheremainingcorner

holesofthesupportframeandrepeatStepC.

f) Standtheunituprighttocontinuetheremainderof

thisassembly.

g) Presseachcornerdownwardfirmlytoensurethe

supportframeisfullylockedintoposition.



5

Step3:AssemblingtheMiddleSupport

FrameandLogo/SupportBar.

TheMiddlesupportframe(PartB)MUSTbeinstalledto

maintainthestackingbracketsquareandstable.



a) UsingtheShelf/Framesupportclips(PartI)insert

theplastictaperedclipsintotheappropriate

groovesoneachleg.(Seetheimage).



b) AlignthecornerholesoftheMiddlesupport

frame(PartB)witheachofthelegsandgently

lowerontothesupportclips.Presseachcorner

downwardfirmlytoensurethesupportframeis

fullylockedintoposition.



c) UsingtheShelf/Framesupportclips(PartI)insert

theplastictaperedclipsintotheappropriate

groovesoneachoftherearlegs.(Seetheimage).



d) AligntheholesoneachendoftheLOGO/Support

Bar(PartO)witheachoftherearlegsandslightly

lowerontothesupportclips.



Step4:AssemblingtheTopShelf:

a) UsingtheShelf/Framesupportclips(PartI)insert

theplastictaperedclipsintotheappropriate

groovesoneachoftherearlegs.(Seetheimage).



b) AligntheholesateachcorneroftheTopShelf

(PartC)witheachofthelegsandgentlylower

ontothesupportclips.



6

Step5:InstallingtheAnti‐TipSafetyBracket:



a) AttachtheAnti‐TipSafetyBracket(PartsGandH)to

theStackingbracketasshown.Byjoiningthetwo

(2)partsusingthePhillipsHeadScrewandNut

(PartsKandN).



b) AligntheassembledStackingbracketinplaceand

markwheretheAnti‐TipSafetyBracketistobe

attachedtothewall.



c) UsingtheWallAnchorsandSelfTappingPhillips

headscrews(PartsLandM)includedtoattachthe

assembledStackingbrackettothewall.



Step6:InstallingYourAvantiDryer(ModelD110)tothe

topshelf.

InordertoplaceyourAvantiDryer(ModelD110)onthestackingkityou

mustfirstremovethefour(4)levelinglegsfromthebottomofthedyer.

a) PlacetheDryeronthetopshelf.



b) Re‐installthefour(4)levelinglegspreviouslyremovedthrough

theundersideofthetopshelfandtightenuntilthedryeris

secure.


