Avaya Scopia XT Series Istruzioni per il montaggio

Avaya and the Avaya logo are trademarks of Avaya Inc. and are registered in

the United States and other countries. All other trademarks identified by ®,

TM, or SM are registered marks, trademarks, and service marks, respectively,

of Avaya Inc. 01/15 • Quick Tips for Avaya Scopia XT Series.

About Avaya

Avaya is a leading, global provider of customer and team

engagement solutions and services available in a variety of

flexible on-premise and cloud deployment options. Avaya’s

fabric-based networking solutions help simplify and

accelerate the deployment of business critical applications

and services.

For more information, please visit www.avaya.com.

Quick Tips

www.avaya.com

for

Avaya Scopia XT Series

Press the mute button on the Microphone Pod.

The red light indicates that the Pod is muted.

* Optional feature, may require an additional license

in some XT models

1. From the meeting menu, select Control Camera.

2. Adjust the camera using the arrows

and the zoom keys.

1. Connect your laptop to the DVI cable that is

connected to the Codec Unit and turn off the

laptop’s screensaver.

If the content does not appear on the endpoint,

check the resolution of your laptop.

2. (Optional) Connect the audio output of your

lapt op to the analog/digital audio input

of the Codec Unit.

3. Press Present. Press again to

end content sharing.

Adjusting the Volume

Adjusting the Camera

Sharing Content

Muting/Unmuting the Microphone

rev. A01P/N 62111-02042

Press + or - on the Remote Control

1. Connect a USB storage device to the USB

port on the XT Codec Unit.

2. From the meeting menu, press ok/menu,

and select Meeting Options > Recording.

Dial the virtual room number, meeting ID,

or the XT directly, and press

Press Disconnect on

the Remote Control.

Dial the ﬁrst participant, and press

Dial your virtual room number, and press

Using the Remote Control

Recording the Videoconference*

Add contacts from recent calls

Starting a Videoconference

from the Endpoint

Starting a Videoconference Hosted

by an External MCUEndpoint

Joining a Videoconference

Ending a Call

1. Press ok/menu to access the meeting menu.

2. Select Participants > Invite a new participant.

3. Press ok/menu.

4. Repeat for each additional participant.

Maximum number of participants (4/9, included

the local XT) depends on available MCU license.

Answering a Call

Accept the call by pressing ok/menu.

Or press

Inviting Additional Participants*

Making a Video Call

Dial the remote endpoint or virtual room number

and press call

During a videoconference, press ok/menu to access

all available videoconferencing features from the

meeting menu:

From the Recent Calls section, select the entry with the

right-arrow and choose Add to favorites.

Press the Power key on the XT Remote Control.

Before You Begin Accessing All Videoconferencing Features

3. Select Start.

When recording on local USB storage,

the monitor displays the remaining

time available for the recording.

Switch between

numbers & letters

Enter numbers

& letters.

Hold to recall presets

Make a call

Hold to select do

not disturb

Deletes a character or

a selected item.

Disconnect/reject a call.

Zoom camera

in or out.

Switch between local

& remote cameras

Hold to change

camera input

Navigate through

menus.

Move Camera

Back to

pervious page

Control volume

Press to switch on/

put in

standbay mode.

Hold to Switch off.

Mute microphone.

Hold to hide

your video

Switch between views.

Hold to open

Layout Menu

Start/stop sharing

content, locally or

in a call
