PACE 500 OWNER’S MANUAL
AVENTON PACE 500 OWNER’S MANUAL
Thank you for purchasing an Aventon Pace 500 E-Bike! Before
riding, please take a moment to review these instructions.
Need service or support? Visit our website for quick answers,
manuals and live chat support, and/or give us a call and we’ll find
you a solution.
18457 Railroad St
Industry, CA 91748
Phone: (866) 300-3311
Email: [email protected]
Version 1.1.3 (September 10, 2018)
Latest version can be found: www.aventon.com
CONTENTS
Display / Control Specifications
Getting Started
What’s on the Display?
Using the Controls
Customizing the Display
• Function 02P Unit of Measure
• Function 03P Battery Voltage
• Function 04P Wheel Size
• Function 05P Speed Limit
• Function 06P Odometer Reset
Battery and Charging
Maintenance and Service
Safety
Error Codes and Troubleshooting
1
2
3
4
4
4
5
5
5
6
7
8
9
11
PACE 500 OWNER’S MANUAL
4
DISPLAY / CONTROL SPECIFICATIONS
• 36 Volt Power Supply
• Current Rated: 10mA
• Maximum Operating Current: 30mA
• Power O Leakage Current < 1uA
• Operating Current to Controller: 50mA
• Operating Temperature: -18º to 65ºC
• Storage Temperature: -30º to 80ºC
PACE 500 OWNER’S MANUAL 1
GETTING STARTED
The Pace 500 is operated using the control pad on the
handlebars. The control pad is located near the left-hand brake
lever.
First, turn on the power switch on the battery itself. Then press
and hold the “M” button on the control pad for 3 seconds to
power up the system. While the bike and display are powered on,
press and hold “M” for 3 seconds to turn o.
The Pace 500 E-Bike oers pedal assist. When using pedal assist,
an electric motor supplements the rider’s own eort. To use the
pedal assist, simply start pedaling, then tap the “U” or “D” arrows
to increase or decrease the amount of pedal assist. Pedal assist
will engage at speeds up to 28 MPH.
The Pace 500 E-Bike is equipped with a throttle, which is
mounted near the rider’s left thumb, to propel the bike without
pedaling. To use the throttle, start pedaling then apply the throttle.
Once the bike is moving on throttle power, you can stop pedaling
entirely and use your thumb to control the speed of the bike. The
throttle can propel you at speeds up to 20 MPH.
The motor stops when you: stop pedaling, squeeze the brake
levers, or release the throttle. Simply start pedaling again to re-
engage the motor.
PACE 500 OWNER’S MANUAL
2
WHAT’S ON THE DISPLAY
While you are riding, you can use the display to monitor your
speed, the amount of pedal assist, battery life remaining, and
other data.
As shown below, your Pace 500 uses a LCD display screen that
looks like this:
SPEED INDICATOR
(Current / Max / Average)
5 LEVELS OF ASSIST
(0: No Assist. 5: Max Assist)
WALK MODE
(On / O)
DISTANCE INDICATOR
(Current Trip / System Mileage)
ERROR CODE INDICATOR
(In the Event of a Problem)
BACKLIGHT INDICATOR
(On / O)
BATTERY LEVEL INDICATOR
(Current / Max / Average)
VOLTAGE OUTPUT INDICATOR
(Real-Time)
PACE 500 OWNER’S MANUAL 3
USING THE CONTROLS
To turn on your bike, double-tap the power switch on the battery,
then press and hold the “M” button for 3 seconds. To turn o,
press and hold the “M” button for 3 seconds. The display has an
energy-saving feature, if there is no activity for 10 minutes, it will
turn o automatically to preserve battery.
Tap the “U” or “D” arrows to change the level of pedal assist.
Hold “U” and “M” for 3 seconds to switch between showing real-
time speed, average speed, and max speed.
Tap “M” to toggle between the display of the Odometer, Trip
Distance, Voltage, and Elapsed Time.
Press and hold “U” for 3 seconds to enable the backlight on the
display. Press and hold “U” again for 4 seconds to turn it o.
To enable walk mode, first come to a complete stop and stand
next to the bike. Press and hold “D” for 3 seconds. The bike will
slowly move forward at 3.5 MPH / 6 KPH as long as you hold the
“D” button. This feature is useful for pushing the bike up stairs or
walking through a crowd, where you cannot safely ride.
PACE 500 OWNER’S MANUAL
4
CUSTOMIZING THE DISPLAY
You can use the settings features of the display to customize the
Pace 500 for your use. To enter the “Settings” mode, hold the “U”
and “D” buttons at the same time for 2 seconds.
You can customize 5 out of the 6 dierent functions on the
display. Tap the “M” button to move from function to function, and
use the “U” and “D” arrows to adjust each to your preferences.
When you are finished, press and hold the “M” button to
save your changes. Note: The system will save your changes
automatically after 8 seconds.
FUNCTION 01P - BACKLIGHT BRIGHTNESS
You can control how bright you’d like the display backlight
to be. 1 being the dimmest and 3 is the brightest.
FUNCTION 02P - UNIT OF MEASURE
You can toggle between miles or kilometers, based on your
location and preference.
FUNCTION 03P - BATTERY VOLTAGE
This function sets the battery voltage of the system. On
the Pace 500, this function is locked at 48V to match the
battery and motor, and cannot be changed.
PACE 500 OWNER’S MANUAL 5
FUNCTION 04P - WHEEL SIZE
This function can be used to change the wheel size to
16, 18, 20, 22, 24, 26, 27.5, or 28” wheels. The Pace 500
comes stock with 27.5” wheels, which is the default and
recommended setting. Note: Selecting the incorrect
wheel size will aect the accuracy of the bike’s speed, the
odometer, and the functionality of its pedal assist.
FUNCTION 05P - SPEED LIMIT
The Pace 500 is a California Class III E-Bike. This
designation carries a pedal assist limit of 28 MPH (45
KPH). You can pedal faster without assist, but the motor
will stop providing assist when the speed limit is reached.
You can use the Speed Limit function to change the speed
limit based on your preferences and the law in your area.
The Speed Limit function can be set from 20-51 KPH (for
reference, that is 12.4 - 31.7 MPH) and is always set in KPH.
You should only set the Speed Limit to a value that is safe
and legal in your community.
FUNCTION 06P - ODOMETER RESET
The odometer tracks the distance you’ve ridden over the
lifetime of your bicycle. Press and hold “U” for 5 seconds to
reset the trip distance from a single trip.
PACE 500 OWNER’S MANUAL
6
BATTERY AND CHARGING
The Pace 500 uses a Lithium-Ion battery which can be charged
on or o the bike. We recommend charging the battery o the
bike indoors, in moderate temperature conditions. To charge the
battery, plug the charger into the charging port and then connect
the charger to a wall outlet. The LED indicator light will be red
when charging and will turn green when charging is complete.
Take care of the battery to ensure a long service life:
• Charge and store the battery indoors if possible. The
battery can be removed from the bicycle for this purpose.
• Avoid extreme hot and cold temperatures.
• DO NOT submerge your bike or any of the components in
water. This action will void the warranty.
After many charging and discharge cycles, runtime and range will
be reduced. Replacement batteries are available from Aventon to
extend the life of your E-Bike. The lifespan of the battery is about
500 charge / discharge cycles.
When you install the battery on the Pace 500, it locks into place
automatically. To unlock it for removal, use the supplied key. Do
not ride the bicycle if the battery rattles or moves - it should be
firmly attached.
The Pace 500 battery contains a USB port for transmitting
diagnostic data only, not for charging. It will not charge or power
devices via USB.
