D isso I ve
This is a three-position switch. ln DISCONNECT (left position) tlre
switch disconnects all outputs to projectors and auxiliaries. A red light to
the left of the switch remains on as a reminder to the operator. Use
DISCONNECT with care. When rhe DISSOLVE switch is in this positlon.
program memory responds to commands as if it's advancing or reversing
trays. As a result, it will lose track of projector tray status. ln NOBI\4AL
(right position) all dissolves are connected and will respond to commands.
ln STANDBY (center position) all projector lamps are turned off but
dissolves are connected and will respond to commands.
Sequence
With this switch in the TWO position the programmer will sequence
between left and right projectors, although the center projector will be
activated if the CENTER Screen Control button is punched. With the
SEOUENCE switch in the THREE position the programmer will
sequence left-center-right.
Keyboard
This switch primarily governs the editing controls on the SHOW PRO V.
When the keyboard switch is in the NORMAL position allediting
buttons activate on a one step basis. The Keyboard switch should be in
the NORMAL position for all playback situations.
The "Fast Edit" position allows the operator to "Edit" any number of
cues in a Block, or "add" any given number of cues in a Block. This
position also changes the run control from a hold down position to a
Latching situation.
Keyboard "Fast Edit" changes the Reverse "O" function also, allowing
extremely rapid reversing through memory.
For more information on each Editing control, and the "Fast Edit"
position for each control, refer to "Editing Controls".
NOTE: When the Keyboard switch is in the "Fast Edit" position the
SHOW PRO V will alert the operator by blinking the Red Mag Tape
Status Led.
Mag Tape Switch
MAG TAPE VEBIFY is the far Left position, indicated by a Red Light.
ln this position a program that has been dumped to magtape may be
completely checked without disturbing the contenrs of the SHOW PBO
V memory.
To verify a program that has been dumped to magtape:
(1) Set Mag Tape switch to Tape Verif y position.
l2l Reset the SHOW PRO V memory and rewind magtape.
(3) After connecting an Audio cable from Line Out of the recorded
track to the Play jack on the back of your SHOW PRO V, start
Tape Deck.
Each time a cue is Read back into the SHOW PRO V. it is checked and
verified against memory. lf the data is correct the cue counter will
advance one step. lf any cue is incorrect the cue counter will indicate
BAD 4.
lf all cuesare good, the cue counter will indicate the number of good
cues. lf this count is the same amount as in memory, the dump is
assured to be accurate and of high quality.
PROGRAM position is for programming your show and transferring all
programmed data to magnetic tape.
PLAY position is for presenting shows from mag tape or memory,
Program Timing
This switch will undoubtedly be used more than any other during
programming. ln the STEP position it allows step-by-step programming.
ln the PLAY position it allows playback of single cues as welI as pre-
programmed high speed sequences.
