AWS MC series Manuale utente

American Weigh Scales, Inc.

MC-100 (100x0.01g)

MC-500 (500x0.1g)

User Manual

Digital Pocket Scale

MC-Series

MC-Series Manual

Thank you for purchasing the American Weigh MC-

Series digital pocket scale. Please read all operating

instructions carefully before use. Scales are precision

instruments and should always be handled with proper

care. To ensure years of reliable service, keep these

simple tips in mind:

• Do not exceed the scales maximum capacity.

Overloading your scale can permanently damage it!

• Avoid exposure to extreme heat or cold. Scales

perform best at normal room temperature. If

temperatures have changed dramatically, recalibration

may be necessary.

• Allow your scale to warm up for 30-60 seconds

before performing calibration (if available).

• Store your scale in a clean, dry location. Dust, dirt,

and moisture can accumulate on the weighing sensors

and electronics causing innacuracy or malfunction.

• Avoid using your scale in close proximity to strong

radio wave emitting devices such as computers, cash

registers, and cordless phones.

• Always weigh on a at and level surface, free from

vibrations and drafts. The corner of a room is usually

the most stable.

• Gently apply all items to be weighed. Do not drop

items onto the weighing platform.

• Avoid dropping your scale. The warranty does not

cover damage due to rough treatment or overload.

I. SCALE OPERATION

Place the scale on a horizontal at surface.

1. Press the [ ] key to turn the scale on.

2. Wait until “0.0” or “0.0” is displayed.

3. Place the object(s) on the weighing platform.

4. By pressing the [ M ] key, you can switch between

weighing units.

5. The removable covers can also be used as

weighing trays.

6. To turn the scale off, press and hold the [ ] key.

II. TARE WEIGHING

1. Turn on the scale as described above.

2. Place a tray or container on the scale platform.

3. Press the [ T ] button. “0.0” will be displayed.

4. You can now add items to the container or tray to

obtain just the weight of the contents.

5. When the container is removed, a negative number

will be displayed. Press [ T ] again to zero the scale.

III. CALIBRATION

This scale has come pre-calibrated at the factory. Only

re-calibrate if you are experiencing trouble weighing.

MC-100 uses a 100g calibration weight

MC-500 uses a 500g calibration weight

1. Turn on the scale as described above.

2. Press and hold the [ M ] until the display shows

“CAL”.

3. Make sure nothing is on the platform and press the

[ M ] key once again.

4. The display will ash “CAL” followed by the required

calibration weight (500.0g).

5. Place the required weight (not included) on the

center of the platform.

6. The display will show “CAL” then “PASS”.

Calibration is complete! You can turn off the scale.

IV. TROUBLESHOOTING

The primary reasons for inaccuracy or malfunction

are low batteries, incorrect calibration, overload or

operating on an unstable surface. Please keep this in

mind and maintain and operate your scale properly.

This scale is a precise instrument and must be

handled with the utmost care and caution.

[Display] Elimination of errors

[Lo] Change the batteries.

[OUE2] Recalibrate the scale as shown above.

[O_Ld] You are overloading the scale. Remove the

excessive load immediately!

[UnST] Use the scale in a more stable position

Model MC-100 MC-500

Capacity 100g / 3.528oz / 500ct /

1543gn

500g / 1.64oz / 16.08ozt /

321.5dwt

Resolution 0.01g / 0.001oz / 0.05ct /

0.15gn

0.1g / 0.01oz / 0.01ozt /

0.1dwt

Weighing Units g, oz, ct, gn g, oz, ozt dwt

Calibration Weight (not Included) 100g 500g

Platform Dimensions (inches) 2.2” Ø Stainless Steel

Scale Dimensions (inches) 4.6 x 2.2 x 0.8” (open)

Power 2 x AAA Batteries (included)

Warranty 10 Year Warranty

Specications
