AXIOMTEK GOT318W-521-PCT Manuale utente

GOT318W-521-PCT

All-in-One

18.5” FHD TFT Fanless

PCT Multi-Touch Panel PC

User’s Manual

Disclaimers

This manual has been carefully checked and believed to contain accurate information. Axiomtek

Co., Ltd. assumes no responsibility for any infringements of patents or any third party’s rights,

or any liability arising from such uses.

Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,

completeness or usefulness of any information in this document. Axiomtek does not make any

commitment to update any information in this manual.

Axiomtek reserves the right to change or revise this document and/or product at any time

without notice.

No part of this document may be reproduced, stored in a retrieval system, or transmitted in any

forms or by any means, electronic, mechanical, photocopying, recording, among others, without

prior written permission from Axiomtek Co., Ltd.

WARNING

•Replacing the battery with an incorrect model may cause an

explosion. Only use the same or equivalent type of battery as

recommended by the manufacturer.

•Properly dispose of used batteries according to the instructions.

January 2022, Version A2

Printed in Taiwan

iii

Safety Precautions

Before getting started, please read the following important safety precautions.

1. Be sure to ground yourself to prevent static charge when installing any internal

components. Use a grounding wrist strap and place all electronic components in any

static-shielded devices. Most electronic components are sensitive to static electrical

charge.

2. Disconnect the power cord from the GOT318W-521-PCT prior to any installation. Be sure

both the system and all external devices are turned off. Sudden surge of power could ruin

sensitive components. Make sure the GOT318W-521-PCT series is properly grounded.

3. Make sure the voltage of the power source is correct before connecting the GOT318W-

521-PCT to any power outlet.

4. Turn off system power before cleaning. Clean the system using a cloth only. Do not spray

any liquid cleaner directly onto the screen.

5. Do not open the system’s back cover. If opening the cover for maintenance is a must, only

a trained technician is allowed to do so. Integrated circuits on computer boards are

sensitive to static electricity. To avoid damaging chips from electrostatic discharge,

observe the following precautions:

Before handling a board or integrated circuit, touch an unpainted portion of the

system unit chassis for a few seconds. This will help to discharge any static electricity

on human body.

When handling boards and components, wear a grounding wrist strap available from

most electronic component stores.

Trademark Acknowledgments

Axiomtek is a trademark of Axiomtek Co., Ltd.

Intel® and Pentium® are registered trademarks of Intel Corporation.

Windows 10 and Windows 10 IoT Enterprise are trademarks of Microsoft Corporation.

Other brand names and trademarks are the properties and registered brands of their respective

owners.

iv
Table of Contents


Disclaimers.....................................................................................................ii
Safety Precautions................................................................................iii
SECTION 1 INTRODUCTION ................................ 1
1.1...................................................................................General Descriptions
 1
1.2................................................................................................Specifications
 2
1.3...........................................................................Dimensions and Outlines
 4
1.4.......................................................................................................I/O Outlets
 6
1.5................................................................................................... Packing List
 7
SECTION 2  ............................HARDWARE INSTALLATION
 9
2.1......................................................................................... Open Back Cover
 9
2.2.............................................................. Jumper and Connector Settings
 10
2.2.1 Restore BIOS Optimal Defaults Jumper (JP4).......................................... 10
2.2.2 Auto Power On Jumper (JP6) ....................................................................11
2.2.3 COM Port Connector..................................................................................11
2.3......................................................................................Ethernet Connector
 12
2.4............................................................................... Mounting the Panel PC
 13
2.4.1 Panel Mount .............................................................................................. 13
2.4.2 Wall Mount................................................................................................. 15
2.4.3 VESA Arm Mount....................................................................................... 17
2.2.4 Desktop Mount .......................................................................................... 18
2.5.................................................................................. Hardware Installation
 19
2.5.1 Installing an HDD ...................................................................................... 19
2.5.2 Installing DRAM......................................................................................... 20
2.5.3 Installing a CPU......................................................................................... 23
2.5.4 Connecting the Power Input...................................................................... 25

v
SECTION 3  ................................ AMI BIOS SETUP UTILITY

1............................................................................................................Starting

2............................................................................................Navigation Keys

3...................................................................................................... Main Menu

4............................................................................................ Advanced Menu

4.1 IT8625 Super IO Configuration ................................................................. 29
4.2 Hardware Monitor...................................................................................... 31
4.3 Trusted Computing.................................................................................... 32
4.4 ACPI Setting.............................................................................................. 34
4.5 CPU Configuration .................................................................................... 35
4.6 SATA Configuration ................................................................................... 36
4.7 PCH-FW Configuration ............................................................................. 37
4.8 USB Configuration..................................................................................... 38
5.................................................................................................Chipset Menu

5.1 System Agent (SA) Configuration ............................................................. 38
6............................................................................................... Security Menu

7...................................................................................................... Boot Menu

8......................................................................................... Save & Exit Menu

SECTION 4 DRIVER and INSTALLATION ............. 48
1.........................................................................................Operating System

1.1 Driver CD Content ..................................................................................... 48
2.................................................................................................Touch Screen

APPENDIX A WATCHDOG TIMER ......................... 50
A.1 .............................................................................. About Watchdog Timer

A.2 .......................................................................................... Sample Program

APPENDIX B iAMT SETTINGS.............................. 52

B.1 ............................................................................................. Entering MEBx

B.2 ........................................................................Set and Change Password

B.3 ............................................................................................... iAMT Settings

B.4 ...................................................................................iAMT Web Console

............................................................................................................57

vii

This page is intentionally left blank.

GOT318W-521-PCT User’s Manual

Introduction 1

SECTION 1

INTRODUCTION

This section contains general information and detailed specifications of the GOT318W-521-

PCT, including the following subsections:

Figure 1-1 Front panel of the GOT318W-521-PCT

⚫General Descriptions

⚫Specifications

⚫Dimensions and Outlines

⚫I/O Outlets

⚫Packing List

1.1 General Descriptions

The GOT318W-521-PCT multi-touch panel PC adopts a 18.5-inch FHDTFT LCD with 500nit

brightness and supports the LGA1151 socket 8/9th gen Intel® Core™ i7/i5,i3 & Pentium®

processor (Tj 100°C) up to 35W, providing excellent computing performance and thermal

resistance. This fanless platform is particularly designed for operation under harsh

environments including steel refineries, oil pipes, ships, machine makers, and many more.

Having the abilities described below surely makes GOT318W-521-PCT the most robust and

cost-effective solution.

Designed for extended operating temperature range and ingress protection

The GOT318W-521-PCT’s compact industrial design and fanless cooling system allow the

panel PC to sustain an extended operating temperature range between 0°C and +50°C, making

the system a power-efficient solution. It also features an IP65 front bezel for protection from

liquid and dust.

Reliable and stable design

The GOT318W-521-PCT is specifically designed for vibration-prone environments, best for the

industrial machinery markets. With a patented anti-vibration design, the GOT318W-521-PCT is

able to work in operation mode under 1.0G (10 ~ 500Hz), which has significantly improved

system reliability and sustainability.

NOTE

Heavy-vibration may sometimes cause the LCD screen to flash in white

color; however, it won’t affect the function of the product.

GOT318W-521-PCT User’s Manual

2Introduction

WLAN antenna supported (optional)

The GOT318W-521-PCT includes two Mini Card slots as an add-on option for connecting to a

wireless LAN card under 802.11 a/b/g/n protocols or with other 4G/GPRS applications. These

slots also come with three fixed rotational WLAN/WWAN antennas as optional components for

wireless network connection.

Multi-Touch PCAP touch with 3H surface hardness

The GOT318W-521-PCT comes with a user friendly multi-PCAP touchscreen display which

allows users to operate the panel PC with direct touch. The surface hardness of the touch glass

is up to 7H, providing excellent anti-scratch protection.

Other features

The GOT318W-521-PCT features one 260-pin DDR4-2666/2400 SO-DIMM socket to support

maximum system memory capacity of up to 32GB, along with one 2.5” wide temperature SATA

HDD/SSD for storage needs. It also provides a full set of I/O including RS-232/422/485, USB

2.0, USB 3.0, audio (line-out), HDMI, DP and VGA output, as well as Gigabit Ethernet. This slim

panel PC option supports panel mount, wall mount, VESA mount, and desktop stand mount to

offer more installation flexibility.

1.2 Specifications

Main CPU Board

⚫CPU

➢LGA1151 socket 8/9th gen Intel® Core™ i7/i5 /i3& Pentium® processor (Tj 100°C), up

to 35W

⚫System Memory

➢1 x DDR4 2666/2400MHz SO-DIMM slot

➢Maximum memory up to 32GB

⚫BIOS

➢AMI UEFI BIOS

I/O System

⚫Standard I/O

➢1 x COM (1 x RS-232/422/485)

➢2 x USB 2.0

➢2 x USB 3.0

➢1 x Switch for power on/off

➢1 x Remote switch for power on

➢1 x AT/ATX switch

➢1 x Grounding hole

➢1 x HDMI output

➢1 x DP output

➢1 x VGA output by 9-pin D-sub female

➢1 x Audio line out

⚫Ethernet

➢1 x 10/100/1000 Mbps Ethernet with Intel® i211-AT; supports Wake-on-LAN, PXE Boot

ROM

➢1 x 10/100/1000 Mbps Ethernet with Intel® i219-V (LM); supports Wake-on-LAN, PXE

Boot ROM
