Axis P8815-2 Manuale utente

AXISPeopleCounter

UserManual

AXISPeopleCounter

TableofContents

Solutionoverview...........................................3

AXISPeopleCounter.............................................3

What’sthedifferencebetweenAXISPeopleCounterandAXISP8815-3D

PeopleCounter?................................................4

Getstarted................................................5

Mountthecamera..............................................5

Findthedeviceonthenetwork....................................7

Securepasswords...............................................8

Installtheapplicationonthecamera...............................8

Conguretheapplication....................................10

Setthedateandtime............................................10

Createauseraccount............................................10

Setupthecounter..............................................10

Adjustthecountingarea.........................................11

Neighborcountersforwideentrances...............................1 1

Setupaschedule...............................................13

Anonymizepeople...............................................13

Copytheapplicationsettingstoanothercamera......................14

Occupancyestimation............................................14

Setuprulesandalerts...........................................17

Validatethesystem.........................................18

Validatethecounter.............................................18

Fine-tunethecounter............................................18

Statistics..................................................19

ConnectacameratoafolderinAXISStoreDataManager..............19

Downloadstatistics..............................................0

Reportdatatoaremotedestination................................0

Troubleshooting............................................1

Restarttheapplication...........................................1

Resettheapplication............................................1

Backupthesettings.............................................1

Restorethesettings.............................................1

Generatealogreport............................................

Manageyourlicense.............................................

Thelightwebinterface......................................3

APIinformation............................................4

AXISPeopleCounter

Solutionoverview

Anoverviewofthedifferentdevices,applications,andtoolsneededforacompletesystem.

AXISPeopleCounter

AXISPeopleCounterisananalyticapplicationthatyoucaninstallonanetworkcamera.Youcanusetheapplicationtocounthow

manypeoplepassthroughanentrance,inwhatdirectiontheypass,andifmorethanonepersonpassesduringapredenedinterval.

Youcanalsouseittoestimatehowmanypeoplearecurrentlyoccupyinganarea,andtheaveragevisitingtime.

Theapplicationrunsembeddedinthecamerawhichmeansyoudon’tneedadedicatedcomputertoruntheapplication.

AXISPeopleCounterissuitableforanyindoorenvironment,likestores,libraries,orgyms.

owdoesestimatingoccupancywork?

Youcanusetheapplicationtoestimateoccupancyinareaswithoneorseveralentrancesandexits.Eachentranceandexitneedstobe

equippedwithanetworkcamerawithAXISPeopleCounterinstalled.Ifthereareseveralcameras,theycommunicatewitheachother

overthenetworkinaprimaryandsecondaryconcept.Theprimarycameracontinuouslyfetchesdatafromthesecondarycamerasand

presentsthedataintheliveview.Everyfteenminutes,theprimarycamerasendsthestatisticaldatatoAXISStoreDataManager.

Consequently,thereportsgeneratedfromAXISStoreDataManagercanpresentthedatainaminimumof15minutestimeinterval.

AXISPeopleCounter

Solutionoverview

What’sthedifferencebetweenAXISPeopleCounterandAXISP8815-23People

Counter?

Theapplicationshavetwodifferentalgorithmsforcountingpeoplewhichmakesthemsuitablefordifferentenvironments:

•AXISPeopleCounterrecognizesobjectsthatmoveintheeldofviewandidentiesthemaspeoplebasedontheiroverall

sizeandmovement.AXISPeopleCounterissuitableformostscenarios,coveringsingleaswellasdoubledoorentrances.

•AXISP8815-3DPeopleCountercalculatesthedepthwithinthecountingareainordertomeasuretheheightandthe

sizeoftheobject.AXISP8815-3DPeopleCounterissuitableforcrowdedscenariosandsceneswithchallenging

lightconditionslikestrongsunlight,glaresandshadows.

AXISPeopleCounter

Getstarted

Mountthecamera

NO NO

NOTICE TICE

TICE

Theapplicationisdesignedforscenarioswhereitcountsobjectswiththecharacteristicsofanadultperson.Theexactheight

limitationoftheobjectdependsoncameramodel,cameralens,andtheselectedcountersensitivity.

Inadditiontotheinstructionsinthecamera’sInstallationGuide,therearesomeimportantstepstofollowfortheapplicationto

behaveintheexpectedway:

•Werecommendthatyouinstallthecameraataminimumheightof70cm(8.9ft).

•Asarule-of-thumb,thecameracoversanareaaswideasthecamera’smountingheight.Fordetailsaboutaspecic

cameramodel,seetheCameraselectorforAXISPeopleCounter

•Afterinstallation,thecoveredareacanbeincreaseddependingonthecamera’szoomsetting.

•Ifthecameraismountedhighenough,youcangetacoveragewidthof8meters.Youcancoverevenwiderentrancesby

usingmultiplecounters.

•Thecameramustbemountedstraightabovethepointwherepeoplepass.

•Makesurethecameraisfacingstraightdown,inlinewiththeceiling.

AXISPeopleCounter

Getstarted

•Ifyouinstalltheapplicationbeforeyouinstallthecamera,youcanusethecountingareaindicatedintheliveviewto

positionthecamera.Thecountingareashouldgofromlefttoright,perpendiculartothepathwherepeoplecross.

•MakesurethereissufcientwhitelightorIRilluminationonsite.

•Makesurethattherearenocontinuouslymovingobjectsinthecountingarea.Forexample,donotinstallthecamera

aboveanescalator.

•Makesuretherearenomovingobjectsinterferinginthecountingarea.Forexample,donotinstallthecameratoo

closetoadoor.

AXISPeopleCounter

Getstarted

•Avoidgettingverystronglight,likesunlight,andsharpshadowsinthecameraview.

•Loiteringpeopleorlargeobjectsthatswayslightlycouldinterferewiththecounting.

Findthedeviceonthenetwork

TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilityorAXISDeviceManager.Both

applicationsarefreeandcanbedownloadedfromais.com/support.

FormoreinformationabouthowtondandassignIPaddresses,gotoHowtoassignanIPaddressandaccessyourdevice.

Accessthedevice

1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.

IfyoudonotknowtheIPaddress,useAXISIPUtilityorAXISDeviceManagertondthedeviceonthenetwork.

.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta

newpasswordfortherootaccountonpage8.

3.Theliveviewpageopensinyourbrowser.

AXISPeopleCounter

Getstarted

Securepasswords

Important

Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set

upasecureandencryptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey

maybeusedinvarioustypesofinstallations.

Toprotectyourdatawestronglyrecommendthatyou:

•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.

•Don’texposethepassword.

•Changethepasswordatarecurringinterval,atleastonceayear.

Setanewpasswordfortherootaccount

Important

Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.See

Towatchthisvideo,gotothewebversionofthisdocument.

www.ais.com/products/online-manual/37891#t10098905

Supporttip:Passwordsecurityconrmationcheck

1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage8.

.Retypethepasswordtoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

Installtheapplicationonthecamera

Note

•Thelicenseisonlyvalidforonecamera.Youcan’tactivatethelicenseonanothercamerawithoutanewregistrationkey.

•Toinstallapplicationsonthecamerayouneedadministratorrights.

1.Installthecameraonyournetwork..

.Gotothecamera’swebpageinyourbrowser,seetheUserManualforthecamera.

3.GotoApps.

4.Uploadtheapplicationle(.eap)tothecamera.

5.Activatethelicense.Ifyou’reonline,enterthelicensecode.Theapplicationautomaticallyactivatesthelicense.

AXISPeopleCounter

Getstarted

owtoactivatethelicensewhenyou’reofine

Toactivatethelicensewhenyou’reofine,youneedalicensekey.Ifyoudon’thavealicensekeyonthecomputer,dothefollowing:

1.Gotowww.ais.com/applications

.GotoLicensekeyregistration.YouneedthelicensecodeandtheAxisdeviceserialnumber.

3.Savethelicensekeyleonthecomputerandselectthelewhentheapplicationasksforit.

Accesstheapplicationsettings

1.Inthecamera’swebpage,gotoApps,starttheapplicationandclickOpen.

AXISPeopleCounter

Conﬁguretheapplication

Setthedateandtime

Thedateandtimesettingsareimportantforyourcameratokeepthecorrecttimeforalongerperiodoftime,andforthestatisticsto

beattributedtothecorrecttime.Yousetthedateandtimeinthecamera’swebpage.

1.Inthecamera’swebpage,gotoSystem>Dateandtime.

.Formoreinformationaboutdateandtimesettings,click.

Createauseraccount

Youcancreateuseraccountswithdifferentprivileges,sothatunauthorizedstaffcanviewstatisticsbutnotchangeanysettings

ofthecounter.

Youcreateuseraccountsinthecamera’swebpage.

1.Inthecamera’swebpage,gotoSystem>Users.

.Formoreinformationaboutuseraccounts,click.

Setupthecounter

Tocheckiftheapplicationiscalibratedforyourcamera,gototheCameraselectorforAXISPeopleCountertool.

Towatchthisvideo,gotothewebversionofthisdocument.

www.ais.com/products/online-manual/37891#t10098768

1.Intheapplication’swebpage,gotoSettings>General.

.MakesureCounterstatusisenabled.

3.InCountername,typethenameofthecameraorlocation.

Thiscanbeforexample“Axis_main_entrance”.Allcamerasneedtohaveuniquenames.

4.SetCalibrationmode:

-Iftheapplicationiscalibratedforyourcamera,selecteightsetting.TypethemountingheightinVisualheight.

-Iftheapplicationisnotcalibrated,selectManualsettingandclickSetup.Placeapersonunderneaththecamera

andadjustthesizeoftheyellowboxsothatitcoversjustoneperson.

5.Ifyouneedtozoomin,dooneofthefollowing:

-TurnonDigitalzoomandclickSetup.
