2N Indoor View
®
User guide
Firmware: 2.29
Version: 2.29
The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of
telecommunications equipment.
The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways,
private branch exchanges (PBX), and door and lift communicators. 2N
TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years
and represented a symbol of stability and prosperity on the telecommunications
market for almost two decades. At present, we export our products into over 120
countries worldwide and have exclusive distributors on all continents.
2N is a registered trademark of 2N TELEKOMUNIKACE a.s. Any product and/or other
®
names mentioned herein are registered trademarks and/or trademarks or brands
protected by law.
2N TELEKOMUNIKACE a.s. administers the FAQ database to help you quickly find
information and to answer your questions about 2N products and services. On www.
faq.2n.cz you can find information regarding products adjustment and instructions for
optimum use and procedures „What to do if...".
2N TELEKOMUNIKACE a.s. hereby declares that the 2N product complies with all
basic requirements and other relevant provisions of the 1999/5/EC directive. For the
full wording of the Declaration of Conformity see the CD-ROM (if enclosed) or our
website at www.2n.cz.
The 2N TELEKOMUNIKACE a.s. is the holder of the ISO 9001:2009 certificate. All
development, production and distribution processes of the company are managed by
this standard and guarantee a high quality, technical level and professional aspect of
all our products.
2N TELEKOMUNIKACE a.s., www.2n.cz 3/112
Content:
1. Product Description
1.1 Product Description
1.2 Differences between Models and Associated Products
1.3 Terms and Symbols Used
1.4 Safety Precautions
2. Description and Installation
2.1 Before You Start
2.2 Quick installation guide
2.3 Installation Conditions
2.4 2N® Indoor View LAN Location via 2N® Network Scanner
2.5 IP Address Lookup
3. Configuration
3.1 Factory Reset
3.2 Software Configuration
4. Device Control via Display
4.1 Access Logs
4.2 Directory
4.3 Settings
5. Operational Statuses
6. Technical Parameters
7. Supplementary Information
7.1 Troubleshooting
7.2 Directives, Laws and Regulations - General Instructions and Cautions
2N TELEKOMUNIKACE a.s., www.2n.cz 4/112
1. Product Description
In this section, we introduce the product, outline its application 2N Indoor View
®
options and highlight the advantages following from its use. The section also includes
safety precautions.
1.1 Product Description
1.2 Differences between Models and Associated Products
1.3 Terms and Symbols Used
1.4 Safety Precautions
2N TELEKOMUNIKACE a.s., www.2n.cz 5/112
1.1 Product Description
2N Indoor View
® is a stylish, compact-design indoor IP/SIP unit providing audio and
video communication with the . The device includes a 4 mm enhanced 2N IP intercoms
glass touchscreen panel, Speakerphone, high-quality microphone with excellent
audibility and intelligibility properties, Ethernet LAN interface and induction loop and
doorbell external supply connectors. is a top-quality, cost efficient 2N Indoor View
®
and easy to install and configure answering unit. One installation can combine variable
answering units manufactured by 2N Telekomunikace a.s.
2N Indoor View
® is equipped with a specific user interface for an increased user
comfort and safety.
2N Indoor View
® basic features
7" color LCD video display
full duplex handsfree HD audio communication
LAN interface with PoE supply option
easy flush mounting
the device can be combined in installations with , 2N Indoor Touch
®2N Indoor
®
or answering units,Compact 2N Indoor Talk
®
remote administration and configuration via 2N Remote Configuration
®
call setup option via on a smartphone2N Mobile Video
®
DND mode and parental lock
remote door lock control
time display at relax
display of the current weather,
integrated administrator web interface,
external doorbell button input
external power supply input
induction loop output
2N TELEKOMUNIKACE a.s., www.2n.cz 6/112
1.2 Differences between Models and
Associated Products
2N ® Indoor View indoor units
2N Part No. 91378601
Axis Part No. 02087-001 2N Indoor View
® – black
Indoor answering audio/video unit with
touchscreen designed for all 2N IP
intercoms
2N Part No. 91378601WH
Axis Part No. 02088-001 2N Indoor View
® – white
Indoor answering audio/video unit with
touchscreen designed for all 2N IP
intercoms
2N TELEKOMUNIKACE a.s., www.2n.cz 7/112
Other Indoor Units and Accessories
Part Numbers:
913783752N Part No.
Axis Part No. 01668-001
913783762N Part No.
Axis Part No. 01670-001
2N Indoor Touch 2.0
® – black
WiFi version (third and fourth Part Nos.)
2N Indoor Touch 2.0
®, an elegant indoor touch
panel, is designed for all of the . The 2N IP intercoms
display panel shows you the person standing at
your door and helps you make conversation with
the visitor, open the door lock or switch on the
entrance hall lights.
913783822N Part No.
Axis Part No. 01425-001 2N Indoor Touch
® – desk stand black
2N TELEKOMUNIKACE a.s., www.2n.cz 8/112
Part Numbers:
91378375WH2N Part No.
Axis Part No. 01669-001
91378376WH2N Part No.
Axis Part No. 01671-001
2N Indoor Touch 2.0
® – white
WiFi version (third and fourth Part Nos.)
2N Indoor Touch 2.0
®, an elegant indoor touch
panel, is designed for all of the . The 2N IP intercoms
display panel shows you the person standing at
your door and helps you make conversation with
the visitor, open the door lock or switch on the
entrance hall lights.
2N Part No. 91378382W
Axis Part No. 01426-001 2N Indoor Touch
® – desk stand white
2N Part No. 91378501
Axis Part No. 01935-001 2N Indoor Compact
® – black
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms
2N TELEKOMUNIKACE a.s., www.2n.cz 9/112
2N Part No. 91378501WH
Axis Part No. 01936-001 2N Indoor Compact
® – white
Indoor answering audio/video unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378401
Axis Part No. 01698-001 2N Indoor Talk
® – black
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms
2N Part No. 91378401WH
Axis Part No. 01699-001 2N Indoor Talk
® – white
Indoor answering audio unit with touchscreen
designed for all 2N IP intercoms
2N TELEKOMUNIKACE a.s., www.2n.cz 10/112
Mounting Accessories
913788002N Part No.
Axis Part No. 01700-001
Installation box for 2N indoor answering units for
installation in a wall or plasterboard.
Not included in the package.2N Indoor View
®
913788022N Part No.
Axis Part No. 02039-001
Stand for the 2N indoor answering unit.
Not included in the package.2N Indoor View
®
