Axis P14 Series Manuale utente
AXISP14CameraSeries
AXISP1455-LENetworkCamera
AXISP1455-LE29mmNetworkCamera
RepaintingInstructions
AXISP14CameraSeries
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
axis.com/warranty-implication-when-repainting.
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2
AXISP14CameraSeries
Repainttheproduct
Repainttheproduct
Preparations
•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.
•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,
ormicrophones)beforeyoupaint.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.
Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne
sandpaper,andcleanthepartsbeforepainting.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
isassembly
1Backplate
2Bottombasecover
3Cameraunit
4Holer
5Weathershiel
6Li
3
AXISP14CameraSeries
Repainttheproduct
1.Removethebottombasecover.
2.Removethelidfromthebottombasecover.
3.Removetheweathershield.
4.Removetheholderfromtheweathershield.
7Lockscrew
8Screw
9Armcover
10Pin
5.Removethelockscrew,thescrewsandthearmcover.
6.Removethepin.
4
AXISP14CameraSeries
Repainttheproduct
Masking
1.Makesureallnecessarypreparationsofthecameraunithasbeenmade.SeePreparationsonpage3.
2.Maskallscrewandscrewholes.
3.Masktheentiretopsurfaceofthebottombasecover.
4.Masktheentirebottomsurfaceofthebottombasecover.
5.Maskthebackofthelid.
6.Masktheundersideoftheweathershield.
7.Masktheholder.
8.Masktheinsideofthearmcover.
9.Maskeverythingbetweenthefootandtheballjoint.
10.Masktheslotsfortheweathershield.
11.Maskthefrontofthecamera.
Repainting
1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
2.Letthepaintdry.
3.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
4.Whenthepaintisdry,removethemasking.
5
AXISP14CameraSeries
Repainttheproduct
Reassembly
1.Placethepinintherecessinthearm.
2.Attachthearmcover,thefourscrewsandthelockscrew.Donottightenthelockscrew.Tightenthefourscrewswith1
Nm(0.7lbft)tighteningtorue.
3.Attachtheweathershield.
4.Reassemblethecamera.Tightenthescrewswith1.2Nm(0.9lbft)tighteningtorue.
6
RepaintingInstructionsVer.M1.2
AXISP14CameraSeriesDate:June2021
©AxisCommunicationsAB,2021PartNo.T10168119
