AXISP3925-LRENetworkCamera

RepaintingInstructions

AXISP3925-LRENetworkCamera

Impactonwarranty

ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat

axis.com/warranty-implication-when-repainting.

Riskswithrepainting

ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training

ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:

ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD

damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.

Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.

Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.

Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems

withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe

parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.

Important

Ifyourepaintthecamera,itlowersthemaximumoperatingtemperature,sincedarkercolorsabsorbmoreheat.

AXISP3925-LRENetworkCamera

Repaintteproduct

Preparations

•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.

•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.

•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,

ormicrophones)beforeyoupaint.

Pretreatmentofparts

Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto

adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.

Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetataxis.com.

Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne

sandpaper,andcleanthepartsbeforepainting.

Anodisedandchromatedparts-Useaprimer.

Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.

Plastic-Useaprimer.

Disassemly

TR20

1.Removethefourscrews.

AXISP3925-LRENetworkCamera

Repaintteproduct

PH1

2.Removethetwoscrewsandthebracket.

3.Removethegasket.

AXISP3925-LRENetworkCamera

Repaintteproduct

Repainting

PH1

1.Maskthefrontwindowwiththeincludedcardboard.Makesurethecardboardisproperlypositioned.Reassemblethe

bracketandfastenthetwoscrews.

2.MasktheIRwindowswithmaskingtape.

AXISP3925-LRENetworkCamera

Repaintteproduct

3.Makesureallnecessarypreparationsofthedomecoverhavebeenmade.SeePreparationsonpage3.

4.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.

5.Letthepaintdry.

6.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.

7.Whenthepaintisdry,removethemasking.

Reassemly

Reassemblethecamera.

RepaintingInstructionsVer.M3.2

AXISP3925-LRENetworkCameraDate:November2020

©AxisCommunicationsAB,2020PartNo.T10156716
