2IX09

Dual channel integrity checking probe

with switch over function

Lange Wagenstraat 55

NL-5126 BB Gilze

The Netherlands

Phone: +31 161 850 450

Fax: +31 161 850 499

E-mail: [email protected]

Web: www.axon.tv

TECHNICAL MANUAL

2IX09

WARNING: TO REDUCE THE RISK OF FIRE OR

ELECTRICAL SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE

● ALWAYS disconnect your entire system from the AC mains before cleaning any component. The product

frame (SFR18 or SFR04) must be terminated with three-conductor AC mains power cord that includes an

earth ground connection. To prevent shock hazard, all three connections must always be used.

● NEVER use flammable or combustible chemicals for cleaning components.

● NEVER operate this product if any cover is removed.

● NEVER wet the inside of this product with any liquid.

● NEVER pour or spill liquids directly onto this unit.

● NEVER block airflow through ventilation slots.

● NEVER bypass any fuse.

● NEVER replace any fuse with a value or type other than those specified.

● NEVER attempt to repair this product. If a problem occurs, contact your local Axon distributor.

● NEVER expose this product to extremely high or low temperatures.

● NEVER operate this product in an explosive atmosphere.

Warranty: Axon warrants their products according to the warranty policy as described in the general terms.

That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not

removed.

Date created: 02-04-2006

Date last revised: 17-08-2012

Axon, the Axon logo and Synapse are trademarks of Axon Digital Design B.V.

This product complies with the requirements of the product family standards for audio, video, audio-visual

entertainment lighting control apparatus for professional use as mentioned below.

EN60950

EN55103-1: 1996

EN55103-2: 1996

Safety

Emission

Immunity

Axon Digital Design 2IX09

Tested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

This device complies with part 15 of the FCC Rules

Operation is subject to the following two conditions:

(1) This device may cause harmful interference, and

(2) This device must accept any interference received, including

interference that may cause undesired operation.

Table of Contents

Chapter 1 Introduction to Synapse

An introduction to Synapse

Local Control Panel

Remote Control Capabilities

Chapter 2 Unpacking and Placement

Unpacking

Placing the card

Chapter 3 A Quick Start

When powering-up

Default settings

Changing parameters and settings

Front Panel Control

Example of changing parameter using

Front Panel control

Synapse Setup Software

Menu Structure Example

Chapter 4 The 2IX09 card

Introduction

Key Features

Chapter 5 Settings Menu

Chapter 6 Status Menu

Chapter 7 Events Menu

Chapter 8 LED Indication

Chapter 9 Block Schematic

Chapter 10 Connector panel

1 Introduction to Synapse

An Introduction to

Synapse

Synapse is a modular system designed for the broadcast industry.

High density, intuitive operation and high quality processing are

key features of this system. Synapse offers a full range of converters

and processing modules. Please visit the AXON Digital Design

Website at www.axon.tv to obtain the latest information on our new

products and updates.

Local Control

Panel The local control panel gives access to all adjustable parameters and

provides status information for any of the cards in the Synapse

frame, including the Synapse rack controller. The local control

panel is also used to back-up and restore card settings. Please refer

to the RRC18, RRC10, RRC04, RRS18 and RRS04 manuals for a

detailed description of the local control panel, the way to set-up

remote control over IP and for frame related settings and status

information.

Remote Control

Capabilities

The remote control options are explained in the rack controller

(RRC18/RRC10/RRC04/RRS18/RRS04) manual. The method of

connection to a computer using Ethernet is described in the

RRC/RRS manual.

CHECK-OUT: “AXON CORTEX” SOFTWARE WILL

INCREASE SYSTEM FLEXIBILITY OF ONE OR

MORE SYNAPSE FRAMES

Although not required to use Cortex with a Synapse frame, you are

strongly advised to use a remote personal computer or laptop PC

with Axon Cortex installed, as this increases the ease of use and

understanding of the modules.

2Unpacking and Placement

Unpacking The Axon Synapse card must be unpacked in an anti-static

environment. Care must be taken NOT to touch components on the

card – always handle the card carefully by the edges. The card must

be stored and shipped in anti-static packaging. Ensuring that these

precautions are followed will prevent premature failure from

components mounted on the board.

Placing the card The Synapse card can be placed vertically in an SFR18 frame or

horizontally in an SFR04 or SFR08 frame. Locate the two guide

slots to be used, slide in the mounted circuit board, and push it

firmly to locate the connectors.

Correct insertion of card is essential as a card that is not located

properly may show valid indicators, but does not function correctly.

NOTE: On power up all LED’s will light for a few seconds, this is

the time it takes to initialise the card.

3A Quick Start

When Powering-up On powering up the Synapse frame, the card set will use basic data

and default initialisation settings. All LED’s will light during this

process. After initialisation, several LED’s will remain lit – the

exact number and configuration is dependant upon the number of

inputs connected and the status of the inputs.

Default settings In its default condition the 2IX09 acts as a back-up switcher with

only the carrier detector active.

Changing settings

and parameters The front panel controls or the Axon Cortex can be used to change

settings. An overview of the settings can be found in chapter 5, 6

and 7 of this manual.

Front Panel

Control Front Panel Display and Cursor

Settings are displayed and changed as follows;

Use the cursor ‘arrows’ on the front panel to select the menu and

parameter to be displayed and/or changed.

Press ►

To go forward through the menu structure.

Press ◄

To go back through the menu structure.

Press ▲

To move up within a menu or increase the value of

a parameter.

Press ▼

To move down through a menu or decrease the

value of a parameter.

NOTE: Whilst editing a setting, pressing ► twice will reset the

value to its default.

[No Alarms]

Example of

changing

parameters using

front panel control

With the display as shown below

Pressing the ► selects the SFS10 in frame slot 01.

The display changes to indicate that the SFS10 has been selected. In

this example the Settings menu item is indicated.

Pressing the ► selects the menu item shown, in this example

Settings.

(Pressing ▲ or ▼ will change to a different menu eg Status,

Events).

The display changes to indicate that the SFS10 Settings menu

item SDI-Format has been selected and shows that it current

setting is Auto.

Pressing the ► selects the settings item shown, in this example

SDI-Format.

(Pressing ▲ or ▼ will change to a different setting, eg Mode,

H-Delay).

The display changes to indicate that the SFS10 Edit Setting

menu item SDI-Format has been selected.

To edit the setting of the menu item press ▲ or ▼.

All menu items can be monitored and/or changed

in this way.

Changing a setting has an immediate effect.

RRC18 [Select Card]

>S01=SFS10

SFS10 [Select Menu]

>Settings

SFS10 [Settings]

>SDI-Format=Auto

SFS10 Edit Setting]

SDI-Format>Auto

Axon Cortex

Software

Axon Cortex can be used to change the settings of Synapse modules

from a PC, either locally or remotely. The software enables

communication based on TCP/IP between the Setup PC and

Synapse frames/modules.

Each Synapse frame is addressed through its rack controller’s

unique IP address, giving access to each module, its menus and

adjustment items. Axon Cortex has access to data contained within

the Synapse module and displays it on a GUI. The software has an

intuitive structure following that of the module that it is controlling.

For operation of Axon Cortex, please refer to the Cortex help files

Menu Structure

Example

Slot

Module

Item

Parameter

Setting

▲

S02

Identity

▲

S01

SFS10

►

Set-

tings

►

Standard_dig

►

Auto

▼

S00

RRC18

Status

Mode

625

▼

Events

Ref-Input

525

▼

H-Delay

▼

NOTE: Further information about Front Panel Control and Synapse

Cortex can be obtained from the RRC and RRS operational manuals

and the Cortex help files.

4 The 2IX09 Card

Introduction

The 2IX09 is a dual channel high performance SDI video and

embedded audio probe (signal integrity monitor) with clean switch-

over function. The difference between the 2IX10 and 2IX09 is that

the latter has an enhanced range of probing functions that include

phase reversal and macro blocking detection. The switch function

can be trigge

red by any of the monitored parameters or by GPI.

Besides these extensive functions, the card also provides full line

and frame synchronization on both inputs. Each output has a fan-out

amplifier and all outputs can be sourced by the same output.

Three Serial

Digital Outputs Three processed digital outputs are available for each input.

Automatic

Standard

Selection

Both SDI inputs channels have Automatic standard selection. 625

and 525 are the standards that are recognized.

Back planes

BPL11 or BPX04 are the available backplanes for the 2IX09.

The available Fiber backplanes are:

BPL11T2_FC/PC,BPL11T2_SC, BPL11R2_FC/PC, BPL11R2_SC

Miscellaneous The 2IX09 cards fit into the Axon SFR04 & SFR18 racks.

LED’s at the front of the board indicate the presence of an input

signal and connection & processor Errors.

The 2IX09 can be controlled by Axon Synapse Set-Up Software.

A and B input The software is represented the inputs as A and B.

A is for input_1, B is for input_2.
