Installing Natural Gas Line
Installation should be done by a qualified service person.
WCAUTION: If young children are in the area, a locking valve should be
considered.
Connecting Natural Gas Line
1. Before connecting, be sure there is no debris caught in
the head of the natural gas line, head of the grill natural
gas line or in the head of the burner or burner ports.
2. Connect grill natural gas line to natural main gas line.
Disconnecting Natural Gas Line
1. Before disconnecting, make sure the natural gas main line valve is “OFF.”
2. Disconnect grill natural gas line from natural gas main line.
Operating Instructions
Checking for Leaks
Burner Connections
1. Make sure the regulator hose and valve
connections are securely fastened to the burner
and the tank.
2. Visually check the connection between the
burner/venturi tube and orifice.
3. Make sure the burner/venturi tube fits over the
orifice.
WWARNING: Failure to inspect this
connection or follow these instructions
could cause a fire or an explosion
which can cause death, serious bodily
injury or damage to property.
4. Please refer to diagram for proper installation
(Figures 1 and 2).
5. If the burner/venturi tube does not rest
flush to the orifice as shown, please contact
1.800.762.1142 for assistance.
Tank/Gas Line Connection
1. Make 2-3 oz. of leak detection solution by mixing
one part liquid dishwashing soap with three parts
water.
2. Make sure control knobs are in the “ OFF”
position (Figure 3).
3. Connect NG main line per “Installing Natural Gas
Line” section.
4. Turn “ON” natural gas main valve.
5. Spoon several drops of solution, or use a squirt
bottle, at all “X” locations (Figures 1 and 3).
a. If any bubbles appear, turn natural gas main
valve “OFF,” reconnect and re-test.
b. If you continue to see bubbles after several
attempts, turn natural gas main valve to
“OFF.” Disconnect natural gas line and contact
1.800.762.1142 for assistance.
c. If no bubbles appear after one minute, turn
natural gas main valve to “OFF,” wipe away
solution and proceed.
Operating Main Burners
See your grill’s owner’s manual for instructions.
If you do not have the owner’s manual, please
visit BlueRhino.com or call Customer Care at
1.800.762.1142.
Operating Side Burner
See your grill’s Owner’s Manual for Instructions.
If you do not have the Owner’s Manual, please
visit BlueRhino.com or call Customer Care at
1.800.762.1142.
Cleaning and Care
See your grill’s owner’s manual for instructions. If you do not have the owner’s manual, please
visit BlueRhino.com or call Customer Care at 1.800.762.1142.
Limited Warranty
Blue Rhino Global Sourcing, Inc. (“Blue Rhino”) warrants to the original retail purchaser of this
product, and to no other person, that if this product is assembled, maintained, and operated
in accordance with the printed instructions accompanying it, then for a period of one (1) year
from the date of purchase, all parts in such product shall be free from defects in material and
workmanship. Blue Rhino may require reasonable proof of your date of purchase. Therefore,
you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair
or replacement of parts, which prove defective under normal use and service and which Blue
Rhino shall determine in its reasonable discretion upon examination to be defective. Before
returning any parts, you should contact Blue Rhino’s Customer Service Department using the
contact information listed below. If Blue Rhino confirms, after examination, a defect covered
by this Limited Warranty in any returned part, and if Blue Rhino approves the claim, Blue Rhino
will replace such defective part without charge. If you return defective parts, transportation
charges must be prepaid by you. Blue Rhino will return replacement parts to the original retail
purchaser, freight or postage prepaid.
This Limited Warranty does not cover any failures or operating difficulties due to accident,
abuse, misuse, alteration, misapplication, improper installation or improper maintenance or
service by you or any third party, or failure to perform normal and routine maintenance on
the product as set out in this owner’s manual. In addition, the Limited Warranty does not cover
damage to the finish, such as scratches, dents, discoloration, rust or other weather damage,
after purchase.
This Limited Warranty is in lieu of all other express warranties. Blue Rhino disclaims all
warranties for products that are purchased from sellers other than authorized retailers or
distributors, including the warranty of merchantability or the warranty of fitness for a particular
purpose. BLUE RHINO ALSO DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. BLUE RHINO SHALL HAVE NO LIABILITY TO PURCHASER OR ANY THIRD
PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Blue Rhino further disclaims any implied or express warranty of, and assumes no responsibility
for, defects in workmanship caused by third parties.
This Limited Warranty gives the purchaser specific legal rights; a purchaser may have other
rights depending upon where he or she lives. Some jurisdictions do not allow the exclusion or
limitation of special, incidental or consequential damages, or limitations on how long a warranty
lasts, so the above exclusion and limitations may not apply to everyone.
Blue Rhino does not authorize any person or company to assume for it any other obligation
or liability in connection with the sale, installation, use, removal, return, or replacement of its
equipment, and no such representations are binding on Blue Rhino.
Blue Rhino Global Sourcing, Inc.
Winston-Salem, North Carolina 27105 USA
1.800.762.1142
Figure 1: Main Burners
LP Gas
Connection
LP Gas
Valve with
Orifice
Burner/
Venturi
Tube
Figure 2: Side Burner
LP Gas
Connection
LP Gas
Valve with
Orifice
Burner/
Venturi
Tube
Valve Soft Pipe
Connection
Figure 3
OFF
ARRÊT
Figure 4
