This operator’s manual contains handling tips and precautions for safe operation of your BAD BOY 1022H
tractor. Read it carefully before you operate your tractor and make sure that you have a full understanding of
this manual. This will ensure correct operation and to keep the tractor optimum condition.
After reading the manual, keep it close to the tractor for immediate reference. When you loan your tractor to
someone else, loan the manual as well.
In case the manual is lost or damaged, please contact your local authorized dealer for a copy. Some parts of
this product may have been changed for the improvement of quality or for safety reasons, in which case the
photographs or drawings of the parts in this booklet may not be the same as the actual parts installed on this
product. If you nd anything in this manual unclear or need further explanation, please contact your autho-
rized dealer.
PREFACE
※Regarding the purpose of this machine
Do not modify the machine or try to do the job which is beyond purpose of this machine. Otherwise it may cause the
warranty cancellation. (Refer to warranty statement for detail)
BB1022H.indb 1BB1022H.indb 1 2021-06-28 오후 5:53:082021-06-28 오후 5:53:08
SECTION
BB1022H.indb 2BB1022H.indb 2 2021-06-28 오후 5:53:082021-06-28 오후 5:53:08
FOR SAFE OPERATION........................................................
REGARDING WARRANTY SUPPORT.................................
SPECIFICATION ....................................................................
DESCRIPTION OF OPERATING SYSTEM ...........................
CONTROLS AND COMPONENTS ........................................
PERIODIC CHECKS AND MAINTENANCE ..........................
DIAGNOSIS AND TROUBLE SHOOTINGS ..........................
STORAGE AND DISPOSAL ..................................................
1
2
3
4
5
6
7
8
SECTION
TABLE OF CONTENTS
BB1022H.indb 3BB1022H.indb 3 2021-06-28 오후 5:53:082021-06-28 오후 5:53:08
SAFETY AND VEHICLE DAMAGE WARNING
Failure to observe the instruction given with this mark may result in death or injury.
DANGER
NOTE This instruction is to give an additional description to operator so that he/she can operate the
machine more eectively.
Read this Manual for correct and safe use of the product. Failure to use the product properly
may result in an accident. Keep this Manual close to the tractor after you have read it.
IMPORTANT
The instructions given with the following marks are very important for your safety.
WARNING
Failure to observe the instruction given with this mark may expose you to the risk of death
or injury.
Failure to observe the instruction given with this mark may expose you to injury.
• The section, “ To Ensure Safe Operation,” on the following pages details safety points to
be observed to ensure safe operation of your tractor.
•Please make sure you read it carefully before operating the tractor.
CAUTION
BB1022H.indb 4BB1022H.indb 4 2021-06-28 오후 5:53:082021-06-28 오후 5:53:08
This manual includes symbol marks of the controller to simplify operations for maneuverability and mainte-
nance. These meanings are as below, so carefully read it for a proper function.
SYMBOL MARKS OF CONTROLLER
Left side indicator High Beam Preheat
Right side indicator Battery Engine oil pressure
BB1022H.indb 5BB1022H.indb 5 2021-06-28 오후 5:53:092021-06-28 오후 5:53:09
"USE AND DISPOSAL" POLICY CONCERNED WITH ENVIRONMENT PRESERVATION
We try our best to preserve the environment and are always concerned about our environmental impact at
each step of planning, development, production, distribution, use and disposal of products, and for our over-
all operations through an “environmentally friendly” management system. We comply with international en-
vironmental regulations, environmental regulations designated by country and local authorities and other re-
quirements with which we are in agreement, and we work towards the prevention of environmental pollution
and the conservation of resources. We provide environmental education and have an awareness campaign
to raise environmental awareness among all our employees and members of the supporting companies.
We introduce the “Use and Disposal” policy concerned with environment preservation as follows.
1. Please read the operator’s manual thoroughly for global environment protection. Overload on the machine shortens
the product life and increases the harmful exhaust gas, which causes air pollution due to the incomplete combustion.
2. When replacing various uids (for engine, transmission, hydraulics, etc.) by yourself, don’t dispose the used oil to
anywhere not recommended. It can pollute the ground and water. Please contact your local dealer to dispose it legal-
ly.
3. Observe the operator’s manual and store or dispose the waste product properly. Rust, oil, etc. leaked from waste
product improperly stored can pollute the ground and water. Accordingly for a waste product disposal, contact the
necessarily “approved waste collection and recycling facility” to discard the used materials legally.
BB1022H.indb 6BB1022H.indb 6 2021-06-28 오후 5:53:092021-06-28 오후 5:53:09
1
1. FOR SAFE OPERATION
SAFETY PRECAUTIONS .......................................................................1-2
BEFORE USING THE MACHINE ...............................................................................1-2
BEFORE WORKING..................................................................................................1-11
WHILE WORKING .....................................................................................................1-16
AFTER USING THE MACHINE ................................................................................1-17
PRECAUTION FOR PROLONGED STORAGE ......................................................1-21
OTHER........................................................................................................................1-23
DECAL MOUNTING LOCATION .........................................................1-31
CAUTIONS FOR DECAL MAINTENANCE ..............................................................1-34
BB1022H.indb 1BB1022H.indb 1 2021-06-28 오후 5:53:092021-06-28 오후 5:53:09
1-2
BRANSON TRACTOR
SAFETY PRECAUTIONS
If the instructions in this chapter are
ignored, it may cause a machine fail-
ure, a fatal accident with injury or
death.
For further detailed information, refer
to each chapter.
BEFORE USING THE MA-
CHINE
㭂ጚṦ#㊓≮㱲
Ventilating
Wide and at enough area;
• Inspect or repair the tractor on
a wide and at area.
If this instruction is ignored, an
unexpected accident may occur,
such as overturning of the trac-
tor.
WARNING
• Please understand that some
of the figures or contents in
this manual may not match
with your own machine due to
the product variation.
• This tractor is not designed
for road driving. Please use a
truck to move this machine on
the public roads.
NOTE
Beware of exhaust gas;
• Running the engine, repairing
(tightening) any painted part
or grinding any painted area
should be performed only in a
well-ventilated area.
If this instruction is ignored, the
exhaust gas or dust can cause
intoxication and lead to fatal
consequences.
WARNING
BB1022H.indb 2BB1022H.indb 2 2021-06-28 오후 5:53:092021-06-28 오후 5:53:09
1-3
FOR YOUR SAFETY
1
Carry out maintenance in a well-
lit place;
• Make sure work area is prop-
erly lighted.
Use safety work lights with
protective covering when
working inside or under the
machine.
If this instruction is ignored, an
unexpected accident may occur,
possibly re or explosion.
WARNING
Clean and arranged place;
• Do not mess the place by
dust, mud, oil, or parts
If this instruction is ignored, an
unexpected accident may occur.
WARNING
Prepare for emergencies;
• Keep a rst aid kit and re ex-
tinguisher handy at all times
while operating machine.
WARNING
BB1022H.indb 3BB1022H.indb 3 2021-06-28 오후 5:53:092021-06-28 오후 5:53:09
1-4
BRANSON TRACTOR
Do not drive if you are;
• Unable to concentrate be-
cause of fatigue, under treat-
ment of medicine.
• Under the inuence of alcohol
• Pregnant
• Under the age of 18
WARNING
Use only recommended imple-
ments;
• Be sure to use only imple-
ments which are recommend-
ed by manufacturer.
If this instruction is ignored, an
unexpected accident may occur
or tractor may not perform prop-
erly.
WARNING
Wear properly for the job;
• Hair band, loose clothing
is not allowed. Wear tight
clothes, work hat, and work
shoes which have rough bot-
toms against slippery surface.
If this instruction is ignored, you
will be exposed to a risk of be-
ing entangled, slipping, or fall-
ing.
WARNING
BB1022H.indb 4BB1022H.indb 4 2021-06-28 오후 5:53:102021-06-28 오후 5:53:10
