Ballard Designs Peyton LL331 Manuale utente

PRODUCT NAME: Peyton Floor Lamp

ITEM NUMBER: LL331

ASSEMBLED DIMENSIONS: 55”H x 10” Diameter

PRODUCTS ARE NOT INTENDED

FOR COMMERCIAL USE.

Page 1 of 3

MADE IN INDIA

IMPORTANT SAFETY INSTRUCTIONS:

-This Lamp has a polarized plug (one blade is wider than the other) as a feature to reduce the risk

of electric shock. This plug will fit in a polarized outlet only one way. If the plug does not fully fit in

the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Never use with an

extension cord unless plug can be fully inserted. Do not alter the plug.

-For your safety, please read instructions carefully and completely before beginning assembly

or installation.

-Product must be installed according to applicable code(s) by a person familiar with its construction

and operation.

-This Lamp socket rated up to 100 Watt MAX Type A Bulb (not included). LED recommended.

WARNING:

-Deviation from assembly instructions may cause risk of fire or electric shock.

-To reduce risk of personal injury, always turn off fixture and allow bulb to cool prior to

replacement.

-Do not touch or look directly at illuminated bulb.

-Keep flammable material away from illuminated bulb.

UPDATED:

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

3-1-2023

Approved Location for Use: Dry Indoor Environment

Assembly Time: 10 Minutes

HARDWARE AND COMPONENTS

INCLUDED:

Page 2 of 3

NOT INCLUDED:

(1) - 100 Watt Max

Type A Bulb

*LED recommended.

Unplug lamp prior to installation or removal.

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

100

WATT

MAX

Remove all parts, hardware and protective packaging from

carton and carefully arrange on a clean, level surface.

Prevent accidentally discarding small parts or

hardware. Retain all carton contents until assembly

and installation are complete.

1 - Socket Assembly (A)

1 - Upper Stem (B)

1 - Base (D)

Cleaning and Care

Periodically wipe Lamp with a soft, dry cloth.

Avoid harsh or abrasive chemicals as

finish damage may result.

1 - Finial (F)

1 - Harp (E)

1 - Lower Stem (C)

UL Standard requires shade to be open

on both top and bottom.

Critical Radius is distance between

bulb center and side of shade. For this

lamp it should NOT be less than *3 1/2”

WARNING

FIRE HAZARD

Side

of Shade

Critical

Radius

*Based on a 100W Incandescent Bulb

Shade

Sold Separately

Page 3 of 3

Unplug lamp prior to installation or removal.

Customer Service: 800-367-2810

Online: www.ballarddesigns.com

STEP 3: INSTALL BULB AND SHADE

STEP 1: Carefully arrange, turn and tighten Lower Stem (C) to Base (D). Next, insert, turn and tighten

Upper Stem (B)/ Finally, turn Socket Assembly (A) onto Upper Stem. Pull excess cord through Base.

STEP 2: Add Harp (E) to Saddle.

100

WATT

MAX

Do not twist lamp cord while

turning these pieces together.



Scan this QR Code

to learn more

regarding

LED BULBS

and how to best use them

with your new lamp!

(F)

(E)

Saddle

Add Shade (Sold Separately) followed by Finial (F).

Turn and tighten Finial until Shade is secured.

Shade

Sold Separately

SOCKET RATING: 100W MAX Type A Bulb

*LED bulbs permit a brighter bulb without exceeding

socket rating. (Scan QR Code below for details)

LUMENS (lm): Light output (brightness)

KELVIN (K): Light color. (orange/golden/white/blue)

Kelvin Range: 1800K (orange) to 6000K (white)

To mimic the color of an incandescent bulb, choose

2700K (Soft White).
