2-3. Other component specifications
2-3-1. INDUCTANCE
ELECTRIC PERFORMANCE PARAMETER
Inductance model -
Rated power source -
Loop winding rated current -Rated
current(A) Filter winding rated current -
Loop winding rated inductance -Rated
inductance(mH) Filter winding rated inductance -
Ambient temperature( )℃-
2-3-2. INDUCTANCE (1343046,A)
ELECTRIC PERFORMANCE PARAMETER
Inductance model R1250HSB
Rated power source 220V 50Hz
Rated current(A) 12
Rated inductance(mH) 5
Ambient temperature( )℃-20℃～+70 .℃
2-3-3. FILTER
ELECTRIC PERFORMANCE PARAMETER
Filter model RTLB-12T047-02JF
Rated current(A) 12
Rated power source 220V 50Hz
Filter frequency range 150K—30MHHz
Temperature range( )℃-25℃～+85℃.
2-3-4. STEPPER MOTOR
ELECTRIC PERFORMANCE PARAMETER
Stepper Motor model 24BYJ48
Voltage(DC) 12V
Number of phase 4
Drive mode 1-2phase excitation unipolar drive
Resistance per phase 200Ω±7%
Temperature range( )℃-10℃～+40 .℃
4
