ABOUT THE MCLIM

Part Numbers: 855-12622-RX, 855-12622-TX

The above part numbers must be installed in pairs. As a pair,

the units provide secure data to be passed in one direction

only.

McLIM TP-TX/FX is an Auto Negotiating, switching media converter

which offers plug-and-play operation to convert 10 Mbps or 100 Mbps,

Half- or Full-Duplex twisted pair to 100Base-FX, Full-Duplex fiber.

McLIM TP-TX/FX protects against Broadcast storms, and allows jumbo

packets of up to 1916 bytes. The modules deployed as a pair, allow

transmission of data in one direction only.

McLIMs include one RJ-45 connector for the twisted pair port and

single-strand fiber over multi-mode with SC convertors.

INSTALLING THE MCLIM

You can install media conversion modules in any available slot in a

MediaConverter chassis. Media conversion modules are hot-

swappable.

Media conversion modules ship from the factory with brackets for

securing them to the MediaConverter chassis. To install a module,

simply unscrew the blank bracket covering the slot where you will

install the module. Slide the module into the chassis, via the card

guides, until the module is seated securely in the connector, screw in

the bracket supplied with the module, then connect the cables.

The modular MediaConverter series includes modules which can

convert copper to single-mode or multi-mode fiber at Fast Ethernet.

Modular MediaConverter chassis provide power to media converter

modules, and are available with one, four, eight or 12 slots for

installing the 10/100 McLIM, TP-TX/FX.

•

MediaConverter/1 and /4 are standalone chassis which include one

or four media conversion module slots, respectively, and a fixed,

internal 100/240 VAC power supply.

•

MediaConverter/8 is a 1U high, rack-mountable chassis that

includes eight media module slots and a fixed 100/240 VAC power

supply.

•

MediaConverter/12x is a rack-mountable chassis and includes 12

media conversion module slots and either a 100/240 VAC or -48

VDC power supply. MediaConverter/12x is 1U high and has the

power on the rear of the chassis with media conversion module

slots on the front.

LED OPERATION

Each McLIM includes two LEDs, located on the RJ-45 connector.

LED functions are as follows for the TX Unit:

FX TX

FX LNK/ACT Glows green when a link is established on the FX (fiber)

port; blinks green when activity is detected on the fiber

port.

Although the copper and fiber ports may not be

physically connected, the FX (fiber) port will always

show a green LED, as the link is forced ON, to ensure

the connection.

TX LNK/ACT Glows green when a link is established on the TX

(copper) port; blinks green when activity is detected on

the copper port.

Each McLIM includes two LEDs, located on the RJ-45 connector.

LED functions are as follows for the RX Unit:

FX TX

FX LNK/ACT Glows green when a link is established on the FX (fiber)

port; blinks green when activity is detected on the fiber

port.

TX LNK/ACT Glows green when a link is established on the

TX(copper) port; blinks green when activity is detected

on the copper port.

SPECIFICATIONS

Ethernet Connections

•10/100 BaseT

•Auto Negotiation

•AutoCross

•Flow Control

•1916 MTU

•Full Line-Rate Forwarding

Operating Temperature

32° to 122°F (0° to +50°C); 5% to 90% (non-condensing), 0 to

10,000 ft. altitude

Storage Temperature

-13° to +158°F (-25° to +70°C); 5 to 90% (non-condensing)

Humidity

5% to 95% (non-condensing), 0 – 10,000 ft. altitude

Electrical

MediaConverter/1

AC Input Load: 100/240 100-240VAC ±10% , 50/60Hz, 0.1/0.05A

0.3A

Maximum Heat Generated: 51 BTU/hour

MediaConverter/4

AC Input Load: 100/240 100-240VAC ±10% , 50/60Hz, 0.1/0.05A

1.2A

Maximum Heat Generated: 67 BTU/hour

MediaConverter/8

AC Input Load: 100/240 100-240VAC ±10% , 50/60Hz, 0.5/0.2A 1.2A

Maximum Heat Generated: 137 BTU/hour

MediaConverter/12

AC Input Load: 100/240 100-240VAC ±10% , 50/60Hz, 0.5/0.2A 1.2A

DC Input Load: -48 ±10% VDC, 1A

Maximum Heat Generated: 137 BTU/hour for AC unit, 171 BTU/hour

for DC unit

Dimensions

MediaConverter/1 H=1.6” x W=4.8” x D=4.5” (4 x

12.1 x 11.5 cm)

MediaConverter/4 H=1.7” x W=9.1” x D=5” (4.4 x 23.1 x

12.6 cm)

MediaConverter/8 H=1.7” x W=17.4”x D=5” (4.4 x 44.2 x

12.8 cm)

MediaConverter/12 H=1.7” x W=19” x D=9” (4.4 x 48.3 x

22.9 cm)

FIBER OPTIC CLEANING GUIDELINES

Fiber Optic transmitters and receivers are extremely susceptible

to contamination by particles of dirt or dust, which can obstruct

the optic path and cause performance degradation. Good

system performance requires clean optics and connector

ferrules.

1. Use fiber patch cords (or connectors, if you terminate your

own fiber) only from a reputable supplier; low-quality

components can cause many hard-to-diagnose problems in

an installation.

2. Dust caps are installed at B&B Electronics to ensure factory-

clean optical devices. These protective caps should not be

removed until the moment of connecting the fiber cable to

the device. Should it be necessary to disconnect the fiber

device, reinstall the protective dust caps.

3. Store spare caps in a dust-free environment such as a

sealed plastic bag or box so that when reinstalled they do

not introduce any contamination to the optics.

4. If you suspect that the optics have been contaminated,

alternate between blasting with clean, dry, compressed air

and flushing with methanol to remove particles of dirt.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali B&B Electronics Convertitore multimediale

B&B Electronics

B&B Electronics RS-232 Baud Rate Converter CE 232BRC Manuale utente

B&B Electronics

B&B Electronics McPC-Gigabit Manuale utente

B&B Electronics

B&B Electronics U-linx USR602 Manuale utente

B&B Electronics

B&B Electronics ILinx FOSTCDRI-PH Series Manuale utente

B&B Electronics

B&B Electronics 422LP9R Manuale utente

B&B Electronics

B&B Electronics USR604 Manuale utente

B&B Electronics

B&B Electronics PES1A Manuale utente

B&B Electronics

B&B Electronics Industrial Media Converter EIR102 Manuale utente

B&B Electronics

B&B Electronics MES1A Manuale utente

B&B Electronics

B&B Electronics IE-MiniMc Manuale utente

B&B Electronics

B&B Electronics 2IQEC2 Manuale utente

B&B Electronics

B&B Electronics EIS Series Manuale utente

B&B Electronics

B&B Electronics 232SPS2 Manuale utente

B&B Electronics

B&B Electronics Command Response Protocol HVD100A3 Manuale utente

B&B Electronics

B&B Electronics RS-232 to Ethernet Converter ES1A Manuale utente

B&B Electronics

B&B Electronics 4WSD9R Manuale utente

B&B Electronics

B&B Electronics BB-USR604 Manuale utente

B&B Electronics

B&B Electronics McPC MediaLinX Manuale utente

B&B Electronics

B&B Electronics PESV1A Manuale utente

B&B Electronics

B&B Electronics iMcV-LIM 10/100 Manuale utente

B&B Electronics

B&B Electronics McBasic TP/FO Manuale utente

B&B Electronics

B&B Electronics High Speed Asynchronous to Synchronous Converter... Manuale utente

B&B Electronics

B&B Electronics EIR*-S series Manuale utente

B&B Electronics

B&B Electronics Parallel Port Input/Output Converter PPIO Manuale utente

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
