Modbus TCP to

Modbus ASCII/RTU

Converters

Models: MES1A/MES1B

Quick Start Guide

LED Color/Status Function

Power Red Power applied

Link

Orange

Green Bootup, 10BaseT

100BaseT

Activity Green (Blinking)

Orange Data on the network

Bootup

Note: The MES1A/B can be reset (rebooted) by pressing the Reset

switch for one second. Reset switch is accessed through a small hole in

the top of the enclosure.

Warning: Do not forget your password if used. There is no easy way to

get into the unit for configuration once you forget your password.

□Connect the MES1A/B to the network using an Ethernet

cable.

□Connect your PC to the network.

□Connect a 12 VDC power supply (not included) to the

MES1A/B and apply power. (10 – 30VDC, 3.6 Watts)

□MES1A or MES1B unit

□Printed version of this MES1A/B Quick Start Guide

□Printed manual

□Software CD

□Open the Device Installer software. It should detect the

MES1A/B and display XPort in the third level of the

Devices Tree.

□Expand the tree and click the device IP Address.

□Select the Telnet Configuration tab, then click Connect.

□Press Enter within five seconds to go into Setup Mode.

□To change the IP Address, Default Gateway or Netmask, type 1.

□To configure Master/Slave and Serial Interface settings, type 2.

□Do not change any configuration settings in section 3.

□To configure Modbus/TCP Settings, type 4.

□To configure Modbus Master settings, type 5.

□To save your settings in the MES1A/B, type S.

□Connect Modbus device to the serial interface on the

MES1A/B using the correct cabling:

- MES1A is a DTE: Use a straight through serial cable if

the Modbus device is a DCE; null modem if device is DTE

- MES1B: Four-wire for RS-422, two-wire for RS-485, Set

RS-422/485 switch.

□Your Modbus device should now be operational on the

network.

□Insert the software CD. It should auto-start into the

installation wizard.

□Follow the on screen installation wizard to install the

Device Installer software.

□Software supports Windows 98, Me, 2K, XP, & NT 4.0

MES1A

RS-232 Model MES1B

RS-422/485 Model
