B&C Speakers 12PS76 Manuale utente

12PS76 Subwoofer

LF Drivers LF Nd Drivers Coaxials HF Drivers Horns

900 W continuous program power capacity

76 mm (3 in) copper voice coil

40 – 1000 Hz response

95 dB sensitivity

Specification

Nominal Diameter 320 (12) mm (in)

Nominal Impedance (1) 8 Ohm

Minimum Impedence 7.5 Ohm

Nominal Power Handling (2) 450 W

Continuous Power Handling (3) 900 W

Sensitivity (1W/1m) (4) 95 dB

Frequency Range 40 - 1000 Hz

Voice Coil Diameter 76 (3) mm (in)

Winding Material Copper

Former Material Glass Fibre

Winding Depth 22 (0.9) mm (in)

Magnetic Gap Depth 10.5 (0.4) mm (in)

Flux Density 1.15 T

Thiele & Small Parameters

Fs 42 Hz

Re 6.1 Ohm

Qes 0.22

Qms 3.8

Qts 0.2

Vas 75 (2.6) dm3 (ft3)

Sd 522 (80.9) cm2 (in2)

Eta Zero 2.4 %

Xmax +/- 7 mm

Xvar +/- 9 mm

Mms 74 g

Bl 23.5 Txm

Le 2 mH

Mounting and Shipping Info

Overall Diameter 316 mm (12.4 in)

Bolt Circle Diameter 296 mm (11.6 in)

Baffle Cutout Diameter 282 mm (11.1 in)

Depth 140 mm (5.5 in)

Flange and Gasket Thickness 16 mm (5/8 in)

Net Weight 7.6 kg (16.7 lb)

Shipping Weight 8.4 kg (18.5 lb)

Shipping Box 340x340x170 mm

(13.4x13.4x6.7 in)

1For different impedances, please ask.

22 hours test made with continuous pink noise signal (6 dB crest factor).

Power calculated on rated minimum impedance.

3Power on Continuous Program is defined as 3 dB greater than the

Nominal rating.

4Applied RMS Voltage is set to 2.83V for 8 ohms Nominal Impedance.
