Vision sensor for high speed

inspection and error-proofing

P4 EDGE

Vision Sensor

• Self-contained vision sensor

– no external controller required

• Easily and accurately repro-

grammable for new product

inspection at the push of a

button

• Convenient, 12-pin digital I/O

terminal block for ensuring

smooth integration into the

customer’s machine control

system

• High-speed measuring

and position monitoring

at speeds of up to 10 000

parts per minute

• Separate video output

allows direct connection

to optional real-time video

display without the need for

a PC

• Two housing options and

multiple mounting brackets

for easy installation

✓

✗

✓

✗

✓

✗

E-A041

03/05

Banner Engineering offers the industry a highly

complete and integrated line of photoelectric

sensors, ultrasonic sensors, machine safety

products, measurement & inspection products

and vision sensors.

Banner Engineering is a US based company

with subsidiaries around the world for global

sales and support.

Banner Engineering Europe

Koning Albert 1 laan, 50

1780 Wemmel • Belgium

Phone: +32 2 456 07 80

Fax: +32 2 456 07 89

e-mail: mail@bannereurope.com

www.bannereurope.com

▲Vial Stopper Alignment and Fill-Level Detection

The P4 EDGE verifies that the stopper is correctly positioned on a non-closed glass vial to ensure proper

sealing, and that the product fill level is correct. If the stopper is incorrectly positioned or if the vial is under

filled, a FAIL output is sent from the vision sensor to the filling machine.

▲Bottle Label Alignment

The P4 EDGE measures the horizontal displacement

between the labels and verifies that each individual

label is applied straight and not skewed.

▲Syringe Assembly Verification

The P4 EDGE checks for the presence of a needle

and verifies that it is straight. It also measures the

epoxy glue for over- or under-fill.
