Barbie SWITCHBOARD 77211 Manuale utente
Instructions
Please keep these instructions for future reference,
as they contain important information
No assembly is required.
Adult assistance is required to adjust the handle up or down.
Ages 5 years and up.
Weight limit: 100 lbs (45 kg).
™
Model Numbers: 77559, 77211, 77212, 77213
w
w
w.
fi
s
he
r
-p
r
i
c
e
.
c
o
m
77559pr-0920.qrk 8/13/01 3:21 PM Page 1
To prevent injury:
• Keep away from cars and streets.
• Always wear protective equipment including helmet, wrist
guards, knee pads and elbow pads.
IMPORTANT! Please take a few moments to review the following
safety tips with your rider.
•Be sure an adult adjusts the handle up for scooter use and down for
skateboard use.
•Your rider should wear shoes or sneakers that provide good support.
•Your rider should not wear open-toe shoes.
•Your rider should wear a helmet, knee pads, wrist guards and elbow pads
to guard against bumps and bruises.
•Keep loose laces and pant legs away from the wheels.
•Supervise beginners. Hold the beginner’s hand and guide the new rider
along a smooth, level surface.
•Choose areas for riding that are free of obstacles, and avoid wet or
uneven surfaces.
•Make sure your rider never rides on streets, roadways and driveways
which enter vehicle traffic routes.
•Towing riders with bicycles or cars is unsafe.
2
WARNING
77559pr-0920.qrk 8/13/01 3:21 PM Page 2
The Switch Board™trucks are adjusted at the factory to the stiffest
setting (for beginner use). The stiff setting provides the greatest stability.
As your child becomes more comfortable and is better able to balance on
Switch Board™, you can adjust the trucks (to a loose setting) to allow
greater steering control.
Counter-Clockwise
for Loose Setting
•Turn Switch Board™upside-down
on a flat surface. Locate both trucks
(on each end).
Hint: Be sure to place a sheet or
towel on the surface to protect it.
•Using an adjustable wrench:
- Turn each nut clockwise for a
stiff setting.
- Turn each nut counter-clockwise
for a loose setting.
Hint: You should not need to loosen
the nut more than a few turns for a
loose setting.
IMPORTANT! Check to be sure you
have not loosened the trucks too
much! Pull on both trucks. The trucks
should remain on Switch Board™.If
you can remove either of them, you
have loosened the truck(s) too much.
Replace the truck(s) and tighten
the nut(s) clockwise with an adjust-
able wrench.
3
Adjusting the Trucks
Tr u c k
Clockwise for
Stiff Setting
77559pr-0920.qrk 8/13/01 3:21 PM Page 3
•Place Switch Board™on its side with the handle facing up.
•Squeeze the sides of the adult latch and pull it out completely . While
holding the adult latch out with one hand, pull the handle outward slightly
(about two inches) with the other hand. Release the adult latch .
•Continue to rotate the handle to the upright position.
•Push the adult latch until the tabs “snap”into place and . Make
sure you hear a “snap”. The end of the adult latch should align with
the lock line .
•Position Switch Board™upright. Push the handle back to be sure it
is secure.
Hint: To balance, your rider needs to stand on the center area of the
Switch Board™!
Scooter
Note: Protective equipment in
this illustration is not included
with this toy.
Handle Up
Handle
Adult Latch
4
Tabs
Adult Latch
Adult Latch
Lock Line
Handle Up
1
2
3
1
2 3
PUSH
77559pr-0920.qrk 8/13/01 3:21 PM Page 4
•Place Switch Board™on its side with the handle facing up.
•Squeeze the sides of the adult latch and pull it out completely . While
holding the adult latch out with one hand, pull the handle down slightly
(about two inches) with the other hand. Release the adult latch .
•Continue to rotate the handle completely down.
•Push the adult latch until the tabs “snap”into place and . Make
sure you hear a “snap”. The end of the adult latch should align with
the lock line .
•Position Switch Board™upright. Pull the handle up to be sure it is secure.
Hint: To balance, your rider needs to stand on the center area of the
Switch Board™!
Handle
Adult Latch
5
Skateboard
Handle Down
Note: Protective equipment in
this illustration is not included
with this toy.
Handle Down
1
1
23
Tabs
Adult Latch
Adult Latch
2
3
PUSH
Lock Line
77559pr-0920.qrk 8/13/01 3:21 PM Page 5
Call Consumer Relations, toll-free at 1-800-432-KIDS, 8 AM - 6 PM EST
Monday through Friday. Hearing-impaired consumers using TTY/TDD
equipment, please call 1-800-382-7470. Or, write to: Consumer Relations,
636 Girard Avenue, East Aurora, New York 14052.
•Periodically inspect Switch Board™for wear or damage. Check all nuts and
bolts and tighten as required.
•To clean, use a mild soap and water solution and clean cloth. Rinse clean
with water to remove soap residue.
•This product has no consumer serviceable parts. Please do not take this
product apart.
Care
Consumer Information
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A.
©2001 Mattel, Inc. All Rights Reserved. Fisher-Price and Barbie are U.S. trademarks of Mattel, Inc.
Printed in China 77559a-0920
For other countries, outside the United States:
Canada: Call 1-800-567-7724, or write to: Mattel Canada Inc., 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2.
Great Britain:telephone 01628 500303.
Australia: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond, Victoria 3121 Australia.
Consumer Advisory Service 1300 135 312.
New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland.
77559pr-0920.qrk 8/13/01 3:21 PM Page 6
