ILite 6 BK

Enhanced contrast and visual performance

Introducing the newest member of Barco

s already impressive ILite series: the

revolutionary ILite 6 BK, with 3,000:1 contrast ratio, 2,000 NIT brightness, and 14-

bit color processing.

Black LEDs, redesigned shaders, and extra gray scale processing deliver three times

the contrast ratio of ILite 6 XP even in low light settings. Extreme Fill Factor

produces uniform images mere steps away, while 2,000 NIT brightness delivers

suitable light levels for indoor applications, such as:

Corporate branding and retail

Out-of-home Media networks

Crowd management systems

Product showrooms

Barco

s System Color Signature, True Color/Motion Reproduction, and 14-bit

processing ensure vibrant images and flicker-free video, with a color gamut that

exceeds PAL/NTSC. Powered by Barco

s DX-700, ILite 6 BK is fully compatible with

all ILite series peripherals, and installs neatly and discreetly where space re-

quirements are limited.

6mm indoor black LED display

ILite 6 BK features:

3-in-1 SMD black LED

3,000:1 contrast ratio

New shader design

2,000 NIT brightness

14-bit color processing

System Color Signature

ILite series compatible

145 viewing angles

UL, CE, TUV, CEBEC

448mm (17.6 )

127mm (5 )448mm (17.6 )

ILite 6 BK

Pixel pitch 6mm

Brightness (display callibrated at 6500 K) 2,000 NIT

LED configuration 3-in-1 SMD

Pixel density 5,184/tile (72 x 72)

Viewing angle

horizontal >145

vertical >145

Contrast ratio 3,000:1

Lifetime (full white - half brightness) 45,000 hrs

Power consumption/tile

maximum 355 W

average 156 W

Weight/tile 10.8 kg (23.8 lbs)

Color processing 14-bit/color

Colors 4.4 trillion

Refresh rate (PAL/NTSC) minimum 400 Hz

Temperature

operating 0 to 40

(32 Fto 104 F)

storage -20 to 60

(-4 Fto 140 F)

Humidity

operating 35% to 85%

storage 10% to 90%

D320 input compatibility (modules) S-Video, Composite, YUV, RGB, SDI, HDSDI, Data DVI up to UXGA

Certification CE, CB, CEBEC, TUV, ETL

Order information R9010251

Dimensions (W x H x D) 448 x 448 x 127 mm

ILite 6 BK specifications

Ref. No.: R599303 - March 2008

While the information and data given are typical for the

equipment described, product specifications are subject to

change without notice. The latest version of this product

sheet can be found at www.barco.com.

APAC

No.16 Changsheng Road

Changping Dist., Beijing, PRC,102200

Tel: +86 10 8010 1166

Fax: +86 10 8970 9812

Email: [email protected]

www.barco.com

United States

11101 Trade Center Drive

Rancho Cordova, CA

95670

Tel: +1 888 414-7226

Email: [email protected]

Belgium

Noordlaan 5

8520 Kuurne

Tel: +32 56 36 80 22

Fax: +32 56 36 88 62

Email: [email protected]
