Installation manual
Agile X IS
10,1" Tablet-PC
Create a bootable USB stick with
Windows 10 IoT Enterprise operating
system (Bartec Version)
Introduction
formatting the USB stick
copy the operating system on the USB stick
install the operating system
Status: December 2021
Reservation: Technical data subject to change without notice. Changes, errors and
misprints may not be used as a basis for any claim for damages.
Table of content
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
Subject to technical changes.
12/2021
II/7
1. Introduction........................................................................................................................................... 3
2. Note for installation .............................................................................................................................. 3
3. Requirements........................................................................................................................................ 4
4. Format USB flash drive ........................................................................................................................ 4
5. Copy the operating system on the USB stick .................................................................................... 6
Installation manual
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
3/7
Subject to technical changes.
09/2020
Subject to technical changes.
12/2021
1. Introduction
This guide will describe how to create a bootable USB Flash Drive to update the Operating System of your
BARTEC tablets.
2. Note for installation
(1) Only install Operating Systems which are provided from BARTEC. Installing an Operating
System that is not designed for a BARTEC device may not work correctly with them.
(2) Using the Format and Rufus utility will delete all data currently on the USB flash drive.
(3) Make sure that PC, Notebook or Tablet (referred to in the following as the “computer”) is running
on AC Power during the preparation process. Do not unplug the AC Adapter, or any other
connected external devices during the process. Do not restart or turn off the computer during the
process as it may cause permanent damage to the file system structure of the USB Flash Drive.
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
Installation manual
Subject to technical changes.
12/2021
4/7
3. Requirements
Computer with a Windows 7/8/10 operating system
USB flash drive (16GB or more) or Bartec Ex-i USB flash drive (P/N: 17-A1Z0-0007)
Rufus utility
4. Format USB flash drive
1. Insert the USB stick to your Computer.
2. Start Windows Explorer and select the USB Flash Drive.
3. Open the drop-down menu with right mouse click on the USB stick.
4. Select “Format…”
5. In the window “Format” select for “File system” NTFS and for “Volume label” RDVD.
6. Activate the check box for “Quick Format”
Installation manual
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
5/7
Subject to technical changes.
09/2020
Subject to technical changes.
12/2021
6. Press “Start” button to begin the process
7. Press “OK” button in the next message to continue the process.
8. When the formatting process is complete, the message "Formatting was successful" (Format
Complete) appears.
9. Press the “OK” button to close this message. The Format partition window closes automatically
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
Installation manual
Subject to technical changes.
12/2021
6/7
5. Copy the operating system on the USB stick
1. Run the Rufus application
2. Make the following settings in the "Drive Properties":
Device: RDVD (D :) [16GB]
Boot selection: XISLTSC19R01 –AgileXIS LTSC OEM.iso
Partition scheme: MBR
Target system: BIOS (or UEFI-CSM)
3. Make the following settings in the "Formatting Options":
Volume label: DVD_ROM
File system: NTFS
Cluster size: 4096 Byte (Standard)
Installation manual
Agile X IS
Installation manual: bootable USB stick for Windows 10 LTSC 1809
7/7
Subject to technical changes.
09/2020
Subject to technical changes.
12/2021
4. In “Status” appears “DONE”. Click on “START” to copy the operating system to the USB stick.
5. The transfer takes about 10-15 minutes.
After a successful transfer, the “Status” switch to green.
6. Close the Rufus application.
The USB stick is now setup for the installation.
