BATHSELECT BST-008-1ORB Manuale utente
Plumbers Tape Tape Measure Adjustable Wrench
Screwdriver
Drill
Hex Wrench
Level
Pencil or Marker
Thread Sealant
*not included
POSSIBLE TOOLS REQUIRED*
BATHSELECT DARK OIL RUBBED BRONZE/MATTE
BLACK SQUARE COLOR CHANGING LED RAIN
SHOWER HEAD INSTALLATION INSTRUCTIONS
Product code: BST-008-1ORB
1
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
PRIOR TO INSTALLATION
Customer Service: 800-500-9895
bathselect.com
Customer Service: 800-500-9895
bathselect.com
2
Shower Head Installations Instruction
Parts:
Step 3:
Step 1:
D
C
E
F F
Mark the 4 drilling positions then
use the Ø6mm drill to drill holes on the
wall according to the marked hole
position.
Inset the plug(D) into the hole, hold the fix base (C) use the tapping screw (D) through
fix base(C) holes, tighten the tapping screw (D) tighten the top shower fixed bar(E) and
the inlet hose (F) with the fix base (C)
Customer Service: 800-500-9895
bathselect.com
3
Fixed the top shower with the top shower fixed bar (E) , then connect with the inlet hose
(F) . 2 Inlets for Rainshower are provided in big shower heads so the water disperses
equally throughout the showerhead.
The installation is completed.
Note: The LED lights are powered by water flow, and will be activated once the water is
turned on.
E
F
Step 5:
Step 6:
Customer Service: 800-500-9895
bathselect.com
4
Acid
Care & Cleaning
General Information
1. The product can be cleaned with warm water, a mild soap and a clean soft cloth.
2. Clean progressively and gently.
3. It is not required to use any abrasive cleaning pads, wire wool or cloths to clean the
product.
4. Avoid a vigorous cleaning action, as this could contribute to denaturing and dulling
5. Abrasive or strong cleaning products containing ammonia, bleaches, alcohol, dyes,
acids (hydrochloric, formic, phosphorus, chlorine or acetic) will be not be affected.
All products manufactured and supplied by BathSelect are safe and comply to legislative
requirements. Providing they are installed correctly and receive regular maintenance in
accordance with these instructions your user experience will not be affected
6. If using a spray cleaner, apply the cleaning agent onto a soft cloth, never directly
spray onto the product as the cleaner may enter gaps and openings and cause
damage. Do not allow the cleaner to remain on the product for a period of time. After
cleaning, rinse thoroughly with clean water.
