Bauhn ATV50UHDG-0521 Manuale utente
Ultra HD
Android TV
™
™
50”
MODEL: ATV50UHDG-0521 PRODUCT CODE: 705744 05/2021
AUS
User Manual
ATV50UHDG-0521
AFTER SALES SUPPORT
1300 002 534
2
Welcome
Congratulations on your purchase!
This manual tells you all you need to know about using your new BAUHN®product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by BAUHN®are manufactured to the highest standards of performance and safety and,
as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty.
Domestic use only: This product is intended for indoor domestic use only. It is not suitable for commercial, industrial
or outdoor use. Do not use this product for anything other that its intended purpose, and only use it as described in
this manual.
We hope you will enjoy using your purchase for many years to come.
3
Contents
Welcome 2
Contents 3
Unpack and Prepare 4
What's in the Box 4
Important Tips 5
Attaching the Stand 6
Wall-Mounting the TV 7
Connect to Power 8
Connect your Antenna 8
Controls and Connections 9
Get to Know your TV 9
Buttons on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Remote Pairing 13
Remote Overview 14
On-Screen Set Up 16
How to access other devices
connected to the TV 17
How to turn on/off subtitles
in live TV mode 17
How to play personal
photos and music 17
How to set up Android TV
Remote Control app 18
Smart TV 19
Download or Delete Apps 20
Stream using Chromecast-enabled
Apps 21
Using Voice Interaction 22
Connect To Google Home 22
TV Setting Menus 23
Picture 25
Sound 27
Channel 28
Network & Internet 29
Accounts and Sign-in 31
Google Assistant 31
Apps 32
Retail Mode 32
About 33
Date & Time 34
Inputs 35
Power 36
Screen Saver 37
Location 37
Accessibility 38
Reset 38
Remote & Accessories 39
High Dynamic Range (HDR) 40
TV Guide 41
Recording 42
Recording Live TV 43
Scheduled Recording 43
Playback 43
Pause Live TV (Time-shift) 44
Troubleshooting 45
Specications 49
Compliance and
Responsible Disposal 50
Warranty lnformation 51
Repair and Refurbished Goods
or Parts Notice 52
4 | UNPACK AND PREPARE
Unpack and Prepare
What's in the Box
See the box flap for how
to handle the TV without
damaging it!
Before installing your new TV, check you have everything
needed.
In the box you will find:
A. 50" 4K Ultra HD Android TV
B. Remote Control
C. AAA Activ Energy Batteries (2)
D. Mini Component Adaptor
E. TV Stands (2)
F. Screws for the TV Stand (6)
G. Warning Sheet
H. TV Toppling Safety Message
I. Quick Start Guide
J. Warranty Certificate
K. General Safety Warnings
L. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install your TV
• Google account
• Internet connection (to access Smart TV apps and
functionality)
• Antenna cable (to watch live TV)
E
F
G
HIJKL
D
UNPACK AND PREPARE | 5
Important Tips
• Place the TV on a level surface.
• Place the TV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from the TV.
• Unplug the TV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing the TV in place.
• Keep liquid, children and pets away from the TV at all times.
6 | UNPACK AND PREPARE
Unless you are wall-mounting the TV, you will need to
attach its stand/legs.
1. Lay the TV face-down on a soft, flat surface (like the
sofa, or a towel on a table) larger than the TV itself.
2. Match the stands to the installation points on the
underside of the TV.
3. Attach the stands to the TV at the installation points
using the screws provided. (Grab a screwdriver for
this bit).
Attaching the Stand
• Unplug the TV from the power outlet before
installing or removing the stand.
• DO NOT place the TV standing upright without
its stand attached; it could damage the remote
sensor at the bottom of the TV.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps for
securing the TV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
UNPACK AND PREPARE | 7
200mm
200mm
Back of the TV
Wall-Mounting the TV
The TV comes with holes on the back panel for use with
wall-mounting brackets (bracket not included).
Use four standard M6*12mm screws (or longer,
depending on the mounting bracket) to wall-mount this
TV (screws are not included).
• Unplug the TV from the power outlet
before wall-mounting.
• Contact a professional for assistance with
wall-mounting the TV.
Required
• VESA Mounting
Bracket
• 4 x M6*12mm
screws (or longer
as required)
The screws in the package are for securing the TV stand
only. If you are wall-mounting the TV, consult a qualified
installer for advice on bracket support and wall support.
8 | UNPACK AND PREPARE
Free-to-air TV in HD (High Denition)
High Definition (HD) channels provide
the best viewing quality and are available
with a digital antenna connection.
TV channels in Ultra HD resolution are not
currently available in Australia. Therefore
when you watch HD broadcast signals on
an Ultra HD TV, the picture can appear
'soft' and lacks the detail you see when
watching the same content on a HD TV.
Connect to Power
Make sure the TV is switched off at the power outlet
until you have finished connecting your cables.
Connect your Antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in the TV
to the power outlet. Leave
the power switched off until
installation is finished.
CONTROLS AND CONNECTIONS | 9
/
Controls and Connections
Get to Know your TV
1. /(Standby/Menu):
• When TV is on standby mode, press to turn on.
• When TV is on, press to enter the menu.
• When navigating around the user interface, press to
enter/select the highlighted item.
• When TV is on, press and hold to turn TV to standby.
2. VOL + : Increase the volume level or move left.
3. VOL - : Decrease the volume level or move right.
4. CH : Select the next channel or move up.
5. CH : Select the previous channel or move down.
Front view
Buttons on the TV
On/Standby indicator and
Remote sensor
45
1
2 3
See next page for more info on the connections.
10 | CONTROLS AND CONNECTIONS
Ports on the TV
12 4 63 5
1LAN
INTERNET
Connect to your broadband modem using a network cable (not included) for
best steaming experience. However, the TV also has built-in WiFi.
2
DIGITAL
AUDIO OUT
(OPTICAL)
SOUND
Connect an external digital audio device. Use an Optical cable (not included)
to connect the unit with an amplifier, soundbar or other audio decoding
device for digital audio signal output.
3
HDMI
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND
COMPUTER
All-digital connection between the TV and any HDMI device. Supports Ultra
HD resolution. Requires a high-speed HDMI cable (not included).
4
(CVBS)
VIDEO IN
You can use this to connect your DVD player. Supports Standard Definition
(SD) picture quality. Requires an AV cable (not included).
5AUDIO IN
SOUND
You can use this to connect Audio to your TV for Composite or Component
video inputs. Requires an RCA Stereo Audio cable (not included).
6
Headphone
Jack
SOUND
Connect to your headphones, amplifier or audio device, using an AUX cable
(not included).
