Baumatic BWE41BL Manuale utente

BWE41BL 40 Bottle

electronic wine cooler

USER MANUAL FOR YOUR BAUMATIC

BWE41BL

40 Bottle electronic wine cooler

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

DD 17/12/08

Contents

Environmentalnote 4

Important safety information 5 – 6

Specifications of your wine cooler 7

Descriptionoftheappliance 8

Controlpanel 9

Description of the product features 9-10

Using your Baumatic wine cooler 11-13

Beforeswitchingon 11

Duringfirstuse 11

Switching on the appliance and setting the temperature 12

Changing between Fahrenheit and Celsius 12

Interiorlight 13

Loading the wine cooler 13

Storingyourwines 13-14

Winestorageproblems 15

Cleaning and maintenance 16

Defrosting 17

Installation 17-19

Electrical connection 17-18

Positioning 18-19

Troubleshooting 19-20

Contactdetails 21

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Advice Line.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing and chilling wine.

NO food stuffs must be stored in the appliance. If it

is used for any other purpose or it is not used

correctly, then Baumatic Ltd. will accept no liability

for any damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipework

does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ensure that the appliance has been

disconnected from your mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated,

so that there is proper air flow between the

bottom of the unit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

Service

You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious

malfunction. If you require a service call then please

contact the Baumatic Service Department.

Specifications of your wine cooler

Congratulations on purchasing a Baumatic wine cooler

oGross capacity: 132 litres

oNet capacity: 126 litres

oBottle capacity: 40 x 0.75 litre wine bottles

oElectronic control with LED display

oTempered door glass

oAdjustable temperature

oDrain hose and auto-evaporated water tray

oInterior light

o6 waved chrome shelves + 2 chrome racks

oAdjustable feet

oReversible door

oBlack door frame

oBlack interior and exterior

oSmoke glass door

oDesigned to store wine at its optimum temperature between +

7°C - 18°C

Optional extra: BW40KIT- Wooden wine rack kit.

Dimensions of appliance

Height: 842 mm

Width: 494 mm

Depth: 545 mm

* Please refer to the installation instructions for more specific

information on the size of aperture that you will require.

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located on the rear of the

appliance. The rating plate will indicate the ambient temperature range

that your appliance will function correctly within.

It is also advisable to make a note of the model number and the serial

number of the appliance before installing it.

Model number ………………………………………………

Serial number ………………………………………………

Date of purchase ……………………………………………..

Description of the appliance

1) Control panel and LED display

2) Cabinet

3) Temperature sensor

4) Adjustable feet

5) Chrome racks

6) Door seal

7) Chrome shelves

8) Door

9) Interior light

Please note that the above image shows the correct

configuration of the shelving inside of the wine cooler.

The image earlier in this manual does not show the correct

configuration of the chrome racks.

Control panel

The control panel is located at the top of the appliance, behind the

glass door.

A) Temperature increase button

B) Temperature decrease button

C) Light ON/OFF button

D) Wine type indicator neons

E) Temperature LED display

F) Celsius/Fahrenheit indicator neons

Description of the product features

1) Control panel

oThe control panel is located at the top of the appliance, behind

the glass door. This means it is easy to set the temperature of

the appliance and see what temperature the appliance is set to.

2) One cooling zone

oThere is one cooling zone inside of your wine cooler.

oThe cooling zone has a temperature control and temperature

LED display.

oThe cooling zone can hold up to 40 x 0.75 litre wine bottles.

oIMPORTANT: The temperature of the appliance will be warmer

at the top of the cooling zone and cooler at the bottom.

oIf you are trying to store a mixture of wine types in the

appliance, we would recommend that red wines are stored at the

top of the cooling zone, white wines in the middle of the cooling

zone and sparkling wines at the bottom of the cooling zone.

3) Interior light

oThe cooling zone has an interior light. The light can be switched

on and off by using the light ON/OFF button (C).

4) The wine cooler shelves

oAll of the full depth shelves have tabs that lock into both sides of

the cabinet of the wine cooler.

oAny of the shelves can be removed, to accommodate larger

bottles of wine.

Removing a shelf

oRemove all of the bottles from the shelf that you want to

remove.

oLift the shelf upwards and then gently pull the shelf away from

the wine cooler.

Replacing a shelf

oPlace the shelf back into a supporting guide slot and push it back

until the shelf tabs slide into place.

oIMPORTANT: You must not store any bottles on a shelf until the

tabs are fully engaged.

5) Wine racks

oThere are additional wine racks at the bottom of the wine cooler.

oThe wine racks are removable for cleaning purposes.
