BBG IDS701 Manuale utente
IDS701
Weighing Indicator
User manual
Manual usuario BBG ref BULL
IDS701 User Manual
Page 1 of 25
safety instruction
For safety operation pls. follow the safety instruction.
WARNING
set. Calibrate, inspect and fix the the weighing indicator is prohibited by
Non professional staff
WARNING
Pls. make sure the weighing display well earthing
WARNING
The indicator is electrostatic sensitive device, pls.
power off during electrical connections, internal
components touched by hand is prohibited, and please
take the anti-static measure
Manual usuario BBG ref BULL
IDS701 User Manual
Page 2 of 25
LIST
1. Summary--------------------------------------------------------------------------3
1.1 Main function--------------------------------------------------------------------3
1.2 Optional function----------------------------------------------------------------3
1.3 Technical parameter------------------------------------------------------------3
1.4 Outline and installation drawing---------------------------------------------4
1.5 Battery using---------------------------------------------------------------------4
2. Installation------------------------------------------------------------------------5
2.1 Connection between indicator and load cell-----------------------------6
2.2 Connection of interface-------------------------------------------------------6
3. Basic operation-----------------------------------------------------------------6
3.1 Display and key instruction----------------------------------------------------6
3.2 Power on------------------------------------------------------------------------8
3.3 Zero function-------------------------------------------------------------------8
3.4 Tare function-------------------------------------------------------------------8
3.5 Accumulating function-------------------------------------------------------9
3.6 Print function-------------------------------------------------------------------9
3.7 Hold function-------------------------------------------------------------------10
4.Calibration-----------------------------------------------------------------------11
4.1 Enter and exit setting--------------------------------------------------------13
4.2 Calibration steps--------------------------------------------------------------15
4.3 Parameter setting-------------------------------------------------------------17
5. Output data format-----------------------------------------------------------18
6. Maintenance--------------------------------------------------------------------21
Manual usuario BBG ref BULL
IDS701 User Manual
Page 3 of 25
1. Summary
IDS701 is specially designed for platform scale with friendly
interface, simple operation, steady feature. The Basic function
includes Weigh, Peak hold, Print. Communicate, Options are
accumulate, Count and animal weighing.
1.1 Main function
》basic weighing function: zero tare retare
》peak hold
》hold
》low battery remind charge and stop charge controlled
》PC communication
》Automatically power off
1.2 Optional function
》accumulating function
》conversion: kg/lb
》animal weighing
》printing function(with time)
1.3 Technical parameter
》Stimulating voltage：+5VDC
》A/D converting speed：10 times/sec
》load capacity：it can connect 4 pcs 350Ωload cell at most
》weight unit：kg. lb
》Resolution：3000e
》Interval：1/2/5/10/20/50
》Display：6-digits LED，word height: 20.3mm
》key：ON/OFF TOTAL TARE ZERO SET
》Interface：RS232C Baud rate optional 1200/2400/4800/9600
Manual usuario BBG ref BULL
IDS701 User Manual
Page 4 of 25
》Ambient temperature：-10～40℃
》Storage temperature：-20～+60℃
》optional power：6V/4Ah rechargeable battery；9VDC adapter
1.4 Outline and installation picture
1.5 Battery
1. when you use the internal battery first time，you should charge
the battery 10-12 hours, to prevent low voltage resulted from self
leakage of battery.
2. when the red battery light is on and flashes，it means low
battery You should charge battery in time.
3. Charge time: 10-12 hoursAnd it works 45 hours
4. When the battery light turns green, it means fully charged
5. If you don’t use the battery long time, take out the battery to
protect t the indicator from battery leakage
6. In order to keep the battery in best using condition, it is suggest
that you fully discharge the battery every month, the method is that
using the indicator till it is automatically power off.
Manual usuario BBG ref BULL
IDS701 User Manual
Page 5 of 25
2. Installation and Calibration
2.1 connection indicator with loadcell
IDS701 can connect four pcs 350Ωload cell at most, both four and
six wire load cell are ok. To make it simple, we use quick disconnect
Or standard plug. As belows
Quick disconnect connection
2.2Connection of interface
RS232 communication interface use 3 cores quick connector
RS232 communication interface connection
Manual usuario BBG ref BULL
IDS701 User Manual
Page 6 of 25
3. Basic operation
3.1 Key and display
IDS701 Weighing indicator display instruction
LED display
instruction
Weighing data display
Total
accumulating
Manual usuario BBG ref BULL
IDS701 User Manual
Page 7 of 25
Hold
Hold weighing data
Tare
Display tare weight
Net
Display net weight
Gross
Display gross weight
Display data keep still
zero, indicating zero weight
Battery
Using battery
Hi
Over setting weight
OK
Within setting weight
Lo
Below setting weight
。
Decimal point
Key’s function
Key symbol
Key name
Key function
SET
Work together with zero, tare, on/off to
perform all operations.
ZERO
1.Clear weight within zero range
2. Work together with SET to perform
Hold and animal-weighing operation.
Manual usuario BBG ref BULL
IDS701 User Manual
Page 8 of 25
TARE
1.At Gross mode, tare the loaded
weight
2.At Net mode, display gross weight
after deduct tare
TOTAL
Work together with SET perform
accumulating operation
ON/OFF
1.Press it for 2 seconds to power on or
power off
2.Work together with “SET”to enter
calibration and function setting.
3.2 Power on
Power on and indicator perform self-checking and go to weighing
mode.
3.3 Zero setting
Within zero range, press “zero”, indicator weighing is cleared. When
Indicator is not stable, zero is unworkable.
3.4 TARE
Press , take the loaded weight as tare, display net
weight, Net weight is zero. “tare” “ net” status light is on.
At the Tare mode, Press , clear the tare, display gross weight.
3.5 TOTAL
Accumulation operation
Manual usuario BBG ref BULL
IDS701 User Manual
Page 9 of 25
At Zero mode, load weight till stable, Press go to accumulating
Mode,” total” light on, display” n001”, and then display loaded weight;
unload weight , back to zero, load weight again till stable. Press ,
display”n002”
Then display the loaded weight. Repeat it maximum 999 times.
Check the total weight operation:
Press and hold it then press
At the same time, display ”n**”, (accumulating times) then display total
weight.
There are 8 data totally. It shows the first 4 digital. then the last 4 digital
For example, the first 4 digital is”0012”, the last 4 digital is”34,56”
It means the actual weight is “1234.56”
At TOTAL (accumulate)mode, Press display “ clr n”, it means don’t
clear the total Weight, Press exit it; if clear total weight,
Press “clr n” change to “clr y” it means clear total weight
display. Press to clear the the total weight and exit accumulating mode.
3.6 Print function
When the data is stable, connection with printer, it will be printed after
press“set”1 second.
Manual usuario BBG ref BULL
