Becen BC-410D Manuale utente
USER’S MANUAL
Model: BC-410D
18x6in1 Led Waterproof Par Light
Package Includes:
1 x led waterproof par light
1 x handle
1 x knot
1 x power cable
1x DMX cable
Please read this manual before use
1
www.szbecen.com
Features
Voltage:AC 110-260V，50/60Hz
Power: 18pcs*6in1 LED
Lamp:18pcs*6in1 LED
Packing Size: 29*29*35cm
Gross weight:8.5kg
Colorful color , automatic
Strobe mode, multi-channel mode, DMX512 Console
Safety precautions
To ensure that the local voltage and the required voltage for product is
consistent.
If a product's power cord is damaged, please do not try to use the product.
Do not try to unplug the power cord from the ground plug. Plug is used to
reduce short-circuit electric shocks and fire prevention.
Before making any connections disconnect the main power supply.
In any case, please do not remove the lid, which is not part of the user can
use. If the product of the shell is missing, please do not run product.
Do not stuff the products to the dimmer package.Guarantee that the product
in the ventilate place ,and maintained between the product and the wall 6
feet (15cm) distance.
If damaged, please do not run product.
If the long-term non-use products, please disconnect the power.
Make sure the product located in a safe and stable place.
2
www.szbecen.com
Special attention to the power cord from being pinched or out of product.
Cleaning :In accordance with the manufacturer's recommendation to clean
products’ fixed position. Please read the "cleaning" in detail.
Heat output
Devices should be away from heat sources such as radiator, heater, warm
furnace or other devices generate heat.
In the following circumstances, the fixed installations are required to
qualified service personnel overhaul:
A. When the power cord or plug is damaged.
B. The product fall or when the liquid outflow the device.
C. When the device does not work correctly, or have some change in the
exhibition.
Installation of power:
At the time of switching in power, make sure that the voltage in your area is
consistent with the the led spot light’s voltage. This for AC110-240V. Since
different parts of the voltage is different, so products in operation, make sure
your wall outlet voltage consistent with the product.
DMX combination
In order to ensure a fixed DMX data transmission, when using several DMX
device to the fullest extent possible use the shortest cables. Fixtures connected
to the DMX channel order does not affect the choice of DMX.
For example:when the allocation of fixed installations DMX 1 channel, DMX
will be located in any location, in the front, back or middle of anywhere. When
3
www.szbecen.com
the fixed installations assigned to DMX 1 channel,whether it is located in which
of the DMX channels, DMX controller is aware that the data sent on the
channel one.
Usage mode
You can use the following four ways:
Automatic -- This section will automatically operate through a variety of colors .
RGBW Mode -- select a color or a different color in order to maintain the same
state.
DMX control mode -- This function will be under the standard of DMX512
controller, let you control each device separately.
LED display
The digital display like below:
A: Menu
B: Up
C:Down
D:Enter
A B C D
No
LED display
function
1
A001
DMX address
2
CP00
Color change
3
CC00
Color Jump change
4
DE00
Mixed color change gradually
5
R255
Red
6
G255
Green
7
B255
Blue
8
W255
White
4
www.szbecen.com
9
Y255
Amber
10
I255
Purple
8CHANNEL TABLE(4in1 is 8CH, 5in1 is 9CH, 6in1 is 10CH, sound
activate just for no waterproof par )
CHANNEL
VALUE
FUNCTION
CH1
0~255
Dimmer
CH2
0~255
Strobe slow--fast
CH3
0-255
0-50：DMX control
51-100：Color jump change
101-150: Color change gradually
151-200：color pulse change
201-255：sound activate
CH4
0-255
Speed slow-fast
CH5
0~255
Red
CH6
0~255
Green
CH7
0-255
Blue
CH8
0-255
White
CH9
0-255
Amber
CH10
0-255
Purple
Cleaning
As the smoke and dust corrosion, internal and external vision lens must be
cleaned out to make the light output power optimization.
1. Use the glass cleaner and soft cloth to clen the package.
2. Every 20 days, use the glass cleaner and soft cloth to clean the external lens.
3. When you insert the power is always to ensure that every part of the product
dry. When Fixtures run, require regular cleaning according to the different
environments.
5
www.szbecen.com
Troubleshooting
The following are some common problems encountered and the solutions when
the customers use it:
For there is no response to DMX
Check the DMX cable is properly connected (pin3 as follows: "hot", in
other DMX devices, pin2 are also as follows: "hot" means.
For the voice made no reply
Sound is too small or too high-profile voice can not make it up and running.
If this problem persists, please contact your vendor for help.
Description:
This item is a model of the control of several kinds of audience spot light. This
light widely used in mobile DJ and clubs. This aspect can be used alone or as
part of a voice-activated to run through several kinds of mode control.
Maintenance
1. Please keep the light in dryness and avoiding use in wet place.
2. Using intermittenlly can be extended the life.
3. Attention to clean the fan and lens usually in order to get the ventilating
effects and lighting effects better.
4. Please do not wipe the crust using organic menstruum avoiding to damage
the product.
Statement
The product has well capability and intact packing when leave factory. All of
the user should comply with above warning item and manual,any misuse
6
www.szbecen.com
cause of the damages are not included in our guarantee,and also can’t be
responsible for any malfunction & problem owing to ignore the manual.
Please forgive that we will not be notice for technical change.
ShenZhen BECEN Stage Equipment Co., Ltd
Add: Room 501,5th floor,Yishenrong industrial park,Xihuan road,
ShaJing,BaoAn,Shenzhen,GuangDong,China
Website: www.szbecen.com
www.becenstage.com
Tel: 86-13410588234
Email: sales01@szbecen.com
sales02@szbecen.com
