Behringer U-CONTROL UCA202 Manuale utente

Operating Manual

Version 1.1 March 2006

U-CONTROL UCA202

CAUTION: To reduce the risk of electric

shock, do not remove the top

cover (or the rear section). No

user serviceable parts inside;

refer servicing to qualified

personnel.

WARNING: To reduce the risk of fire or

electric shock, do not expose

this appliance to rain and

moisture. The apparatus shall

not be exposed to dripping or

splashing and no objects filled

with liquids, such as vases, shall

be placed on the apparatus.

This symbol, wherever it appears, alerts

you to the presence of uninsulated

dangerous voltage inside the en-

closure—voltage that may be

sufficient to constitute a risk of shock.

This symbol, wherever it appears, alerts

you to important operating and mainte-

nance instructions in the accompanying

literature. Please read the manual.

IMPORTANT SAFETY INSTRUCTIONS

DEUTSCH

U-CONTROL UCA202

DETAILED SAFETY INSTRUCTIONS:

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

8) Only use attachments/accessories specified by the manufacturer.

9) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in

any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

10) CAUTION - These service instructions are for use by qualified service personnel only. To reduce the risk of

electric shock do not perform any servicing other than that contained in the operation instructions unless you are

qualified to do so.

U-CONTROL UCA202

UCA202UCA202

UCA202

VUltra-flexible audio interface connects your instruments, mixer etc. with your computer for recor-

ding and playback

VHigh-resolution 48 kHz converters for high-end audio quality

VWorks with your PC or Mac–no setup or drivers required. Free audio recording and editing softwa-

re downloadable at www.behringer.com

VStereo headphone output with dedicated level control lets you monitor both input and output

VAdditional S/PDIF optical output for direct digital conversion

VPowered via USB bus–no external power supply needed

VHigh-quality components and exceptionally rugged construction ensure long life

VConceived and designed by BEHRINGER Germany

All Trademarks mentioned belong to their respective owners and are not affiliated with BEHRINGER®

Ultra low-latency 2 In/2 Out USB/Audio Interface with Digital Output

U-CONTROL

DEUTSCH

U-CONTROL UCA202

FOREWORD

Dear Customer,

welcome to the team of U-CONTROL users, and thank you very much for

expressing your confidence in us by purchasing the UCA202. It is one of

my most pleasant tasks to write this letter to you, because it is the culmination

of many months of hard work delivered by our engineering team to reach a

very ambitious goal: to develop a first rate unit, which is flexible enough to

be used mobile as well as within studio setups.

The task to design our new UCA202 certainly meant a great deal of

responsibility. You, the discerning user and musician, were the focus of

our entire development efforts. It also meant a lot of work and night shifts

to accomplish this goal. But it was fun, too. Developing a product usually

brings a lot of people together, and what a great feeling it is when every-

body who participated in such a project can be proud of what we’ve

achieved.

It is our philosophy to share our joy with you, because you are the most

important member of the BEHRINGER family. With your highly competent suggestions for new products

you’ve greatly contributed to shaping our company and making it successful. In return, we guarantee

you uncompromising quality as well as excellent technical and audio properties at an extremely favorab-

le price. All of this will enable you to fully unfold your creativity without being hampered by budget

constraints.

We are often asked how we can make it to produce such high-grade devices at such unbelievably low

prices. The answer is quite simple: it’s you, our customers! Many satisfied customers means large sales

volumes enabling us to get better conditions of purchase for components, etc. Isn’t it only fair to pass this

benefit back to you? Because we know that your success is our success, too!

U-CONTROL UCA202

I would like to thank all people whose help on U-CONTROL UCA202 has made it all possible. Everybody

has made very personal contributions, starting from the designers of the unit via the many staff members

in our company to you, the user of BEHRINGER products.

My friends, it’s been worth the trouble!

Thank you very much,

Uli Behringer

DEUTSCH

U-CONTROL UCA202

TABLE OF CONTENTS

1. INTRODUCTION ........................................................................................... 8

1.1 Before you started .............................................................................................................. 9

1.1.1 Shipment ..................................................................................................................... 9

1.1.2 Initial operation ............................................................................................................ 9

1.1.3 Online registration .................................................................................................... 10

2. SYSTEM REQUIREMENTS ......................................................................... 11

2.1 Hardware connection .........................................................................................................11

3. OPERATING ELEMENTS AND CONNECTIONS ......................................... 12

3.1 Front panel .......................................................................................................................... 12

3.2 Rear panel .......................................................................................................................... 13

4. WORKING WITH THE UCA202 .................................................................. 14

4.1 Application example ............................................................................................................ 14

5. AUDIO CONNECTIONS .............................................................................. 16

5.1 Wiring .................................................................................................................................. 16

5.2 Headphones connection .................................................................................................... 17

6. SPECIFICATIONS ...................................................................................... 18

7. WARRANTY ............................................................................................... 20

U-CONTROL UCA202

1. INTRODUCTION

Welcome to the family of U-CONTROL users and thank you for expressing your confidence in BEHRIN-

GER products by purchasing the UCA202. With the UCA202 you have purchased a high-performance

audio interface that includes a USB connector. It is thus an ideal sound card for your laptop computer or

an essential recording/playback component for studio environments that involve desktop computers.

The UCA202 is PC and Mac-compatible. Therefore, no separate installation procedure is required, while

the operating system drivers ensure an extremely short latency. Thanks to its robust construction and

compact dimensions, the UCA202 is also ideal for traveling. The separate headphones output allows you

to play back your recordings at any time, even if you don’t happen to have any loudspeakers available.

2 inputs and outputs as well as the digital stereo output give you total connecting flexibility to mixing

consoles, loudspeakers or headphones. Power is supplied to the unit via the USB interface. The LED

gives you a quick check that the UCA202 is properly connected to the computer. The UCA202 is the ideal

extra for every computer musician.

1. INTRODUCTION

DEUTSCH

U-CONTROL UCA202

1. INTRODUCTION

1.1 Before you started

1.1.1 Shipment

Your UCA202 was carefully packed at the assembly plant to assure secure transport. Should the

condition of the cardboard box suggest that damage may have taken place, please inspect the unit

immediately and look for physical indications of damage.

Damaged equipment should NEVER be sent directly to us. Please inform the dealer

from whom you acquired the unit immediately as well as the transportation com-

pany from which you took delivery. Otherwise, all claims for replacement/repair may

be rendered invalid.

Please always use the original packaging to avoid damage due to storage or ship-

ping.

Never let unsupervised children play with the equipment or with its packaging.

Please dispose of all packaging materials in an environmentally friendly fashion.

1.1.2 Initial operation

Please make sure the unit is provided with sufficient ventilation, and never place the UCA202 on top of

an amplifier or in the vicinity of a heater to avoid the risk of overheating.

The current supply is made via the USB connecting cable, so that there is no external power supply unit

required. All required safety precautions have been adhered to.

U-CONTROL UCA202

1. INTRODUCTION

1.1.3 Online registration

Please do remember to register your new BEHRINGER equipment right after your purchase by visiting

www.behringer.com (alternatively www.behringer.de) and kindly read the terms and conditions of our

warranty carefully.

Should your BEHRINGER product malfunction, our goal is to have it repaired as quickly as possible. To

arrange for warranty service, please contact the retailer from whom the equipment was purchased.

Should your BEHRINGER dealer not be located in your vicinity, you may directly contact one of our

subsidiaries. Corresponding contact information is included in the original equipment packaging (Global

Contact Information/European Contact Information). Should your country not be listed, please contact the

distributor nearest you. A list of distributors can be found in the support area of our website

(www.behringer.com/support).

Registering your purchase and equipment with us helps us process your repair claims quicker and more

efficiently.

Thank you for your cooperation!
