Behringer Eurolive B205D Manuale utente

Ultra-Compact 150-Watt

PA/Monitor Speaker System

Multi-purpose, 150-Watt,

active speaker for vocal and

keyboard monitoring, multi-media,

press conferences and

home recording studio, etc.

Revolutionary Class-D amplier

technology: enormous power,

incredible sonic performance and

super-light weight

5.25" premium-quality,

full-range neodymium driver

Ultra-low noise 3-channel mixer with

3-band EQ

2 “Invisible” Mic Preamps with

phantom power for condenser

microphones and 1 instrument-

ready input (no DI required)

Dedicated stereo input for

keyboards, MP3, CD, etc.

XLR “through” connector with

mic/line switch for linking

more B205Ds

Mic stand integration system for use

with stand and boom

Integrated limiter for ultimate system

control and speaker protection

Internal switch-mode power supply

for noise-free audio, superior

transient response and very low

power consumption

Super-tough, impact-resistant

enclosure with integrated

top carry handle

High-quality components and

exceptionally rugged construction

ensure long life

Conceived and designed by

BEHRINGER Germany

What if you could mount your

personal monitor on a mic stand and

point it right at your face—and what if it

sounded really good? What if it sounded

so good it could be used as your main

PA system for more intimate gigs and

meetings? Say hello to the new B205D,

an active PA loudspeaker that is small and

light enough to mount on a mic stand.

But don’t let the small size fool you—the

B205D cranks out high-delity sound

and comes loaded with features that will

simply astound you!

The Secret to B205D’s Amazing Sound

Thanks to our revolutionary

Class-D amplier technology and

internal switch-mode power supplies,

not only do B205D loudspeakers sound

great, they weigh considerably less

than most competing active speakers.

They pump out 150 of the cleanest,

punchiest Watts you’ve ever heard from

a compact loudspeaker, and you can link

additional active loudspeaker systems

via the handy THRU socket. A built-in

mixer provides three input channels,

including a switchable instrument-ready

input (no DI required), and also features

a dedicated 3-band EQ (bass/mid/treble)

for simple, yet eective tonal control.

Put the Sound Where You Want It

Space limitations often make it

impossible to place full-sized monitor

wedges where they can do the most

good—and passive monitors require

lots of external ampliers and processing

gear to function properly. All this

adds up to even more gear to move,

and if you don’t know what you’re doing,

you can easily damage passive monitors

by applying too much, or even worse,

too little power to them. With the B205D

we’ve taken all the guesswork out, giving

each loudspeaker its own 150-Watt,

Class-D amplier specically designed

as the perfect mate for the custom-

engineered 5.25"neodymium driver.

Continued on next page

EUROLIVE

B205

Professional Powered Speakers

Page 2 of 4

Say Goodbye to Back-breaking

Floor Wedges

By using an internal switch-mode power

supply, we reduced the weight of the B205D

to a mere 7.0 lbs (3.2 kg). This means that

instead of bringing in your old passive oor

wedges one-at-a-time, you can carry all your

monitors in one trip—without even breaking

a sweat! They are small enough to mount on

mic stands (each speaker includes a special

mic stand integration system), on a tabletop,

or they can be placed directly atop a piano or

electronic keyboard.

Class-D Technology Delivers High Power,

Low Weight

Instead of operating relatively

continuously like Class AB circuits,

Class-D amps switch on and o thousands

of times per second, delivering power

only when needed. In other words, the

amplier is either fully on or fully o, which

signicantly reduces the power losses in the

output devices.

When used in conjunction with

switching-mode power supplies, our Class-D

ampliers provide tremendous dynamic

punch and superior delity. The resulting

speakers systems are much lighter,

making them easy to transport and set up.

Our no-compromise design means your

B205Ds deliver full power with incredible

delity all night long, without the need for

rest cycles.

Custom-Engineered Drivers

Let’s face it; the drivers (otherwise known

as speakers) are the only part of a sound

system you actually hear. So when it comes

to ours, we don’t cut any corners. While

some of our competitors outsource theirs,

we custom-design and build our speakers

from scratch. We wind our own voice coils,

process the paper pulp into cones and even

machine our own speaker back plates and

frames. This enables us to control the quality,

keep production costs down and frankly,

to make better components. The premium-

grade 5.25"neodymium driver was designed

specically and optimized solely for use in

the B205D.

Instant PA System

With just a single B205D loudspeaker

system and a microphone, you can set

up an instant, high-quality sound system.

Thanks to the built-in preamp section,

you just connect a dynamic mic and

raise and lower the volume with the

LEVEL control. Plug in your sound source

(CD or MP3 player), place the speaker

on a tabletop or mic stand and power

up. It’s just that easy. And if you need

more coverage, you can chain together

as many as you like via the convenient

LINK OUTPUT XLR connector.

Stereo Music System

You can even use two B205Ds

for stereo playback of your MP3,

CD or cassette deck without any

additional hardware—pretty cool for

playing background music or making

announcements. Just plug the

appropriate stereo “breakout” adapter

(not included) into your deck’s output

jack, run one cable to each loudspeaker

and set the Level and EQ controls the

same on both B205Ds. Voilà, instant party!

Continued on next page

XM8500 mic

Guitar

MP3 Player

B205D

XM8500

mic

Guitar

B205D

MP3 Player

EUROLIVE

B205

Page 3 of 4

5.25" premium-

quality, full-range

neodymium driver

HIGH EQ –

12 kHz / ±15 dB

MID EQ –

2.5 kHz / ±15 dB

LOW EQ –

100 Hz / ±15 dB

Channels 1–3 LEVEL

controls

MAIN LEVEL

control

+48 V PHANTOM

POWER switch with

LED

CHANNEL 1

INSTRUMENT switch

Stereo CD

INPUTS

MIC/LINE inputs

accept ¼"or

XLR connections

Power LED

Impact resistant,

molded enclosure can

stand up to years of

rugged abuse

Ergonomic

carry handle Mic stand boom

integration socket

IEC power socket

POWER switch

LINK OUTPUT

XLR jack lets you

connect additional

B205A or other

BEHRINGER active

loudspeaker systems

MIC/LINE LEVEL switch

for MAIN IN combo jack

MAIN IN combo

jack

Mic stand socket

Marvelous Monitoring

When it comes to live monitoring,

it just doesn’t get any more personal than

this. With the B205D, you can literally put

the sound where you want it—and the

sound quality will simply astound you!

It is small and light enough to mount on

a mic stand (it comes with an integration

kit that even works with boom stands),

yet powerful enough to be used as a

small, high-quality PA system. The built-in

3-channel mixer provides tremendous

versatility and even allows additional

systems to be linked as slaves.

Value

The EUROLIVE B205D provides

high-quality sound, tremendous

functionality and versatility for very little

dough. Best of all, since the B205D is

so compact and lightweight, making it

easy for you to load in or out at the gig.

Compare the B205D to the competition

and you’ll own BEHRINGER with money

to spare!

Front View

Rear View

EUROLIVE

B205

Page 4 of 4

For service, support or more information contact the BEHRINGER location nearest you:

Technical speciﬁcations and appearances are subject to change without notice and accuracy is not guaranteed. BEHRINGER is part of the MUSIC Group (music-group.com). All trademarks are the property of their respective owners. MUSIC Group accepts no liability for any loss

which may be suﬀered by any person who relies either wholly or in part upon any description, photograph or statement contained herein. Colors and speciﬁcations may vary from actual product. MUSIC Group products are sold through authorized fullﬁllers and resellers only.

Fullﬁllers and resellers are not agents of MUSIC Group and have absolutely no authority to bind MUSIC Group by any express or implied undertaking or representation.This manual is copyrighted. No part of this manual may be reproduced or transmitted in any form or by any

means, electronic or mechanical, including photocopying and recording of any kind, for any purpose, without the express written permission of MUSIC Group IP Ltd. ALL RIGHTS RESERVED. © 2012 MUSIC Group IP Ltd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,

Tortola, BritishVirgin Islands. 985-10000-00440

Europe

MUSIC Group Services UK

Tel: +44 156 273 2290

Email: [email protected]om

USA/Canada

MUSIC Group Services NV Inc.

Tel: +1 702 800 8290

Email: [email protected]om

Japan

MUSIC Group Services JP K.K.

Tel.: +81 3 6231 0454

Email: [email protected]om

Specications

System Data

Ampliﬁer Power Output

RMS Power 125 Watts @ 6 Ω

Peak power 150 Watts @ 6 Ω

Speaker

Size 5.25" / 133.5 mm

Audio Inputs

Channel 1: RCA jacks

Sensitivity -10 dBu to +4 dBu

Input impedance 10 kΩ

Channel 2: XLR / ¼" TRS combo jacks

Sensitivity -40 dBu to +4 dBu

Input impedance 20 kΩ

Channel 3: XLR / ¼" TRS combo jacks

Sensitivity -40 dBu to +4 dBu

Input impedance 20 kΩ / 1 MΩ switchable

Phantom power

Channels 2 and 3 +48 Volts, switchable

Channel level controls

Input Trim -∞ to + 30 dB

Max. input level +22 dBu

Link

Thru XLR connector, mic/line switchable

Main in XLR / ¼"TRS combo jack

Loudspeaker system data

Frequency response 105 Hz to 10 kHz

Sound pressure level max. 112 dB SPL @ 1 m

Limiter Optical

Dynamic equalizer Processor-controlled

Equalizer

HIGH > 12 kHz / ±15 dB

MID 2.5 kHz / ±15 dB

LOW < 100 Hz / ±15 dB

Power Supply

Voltage (Fuses)

USA / Canada 120 V~, 60 Hz (T 3.15 A H 250 V)

UK / Australia 240 V~, 50 Hz (T 3.15 A H 250 V)

Europe 230 V~, 50 Hz (T 3.15 A H 250 V)

Japan 100 V~, 50/60 Hz (T 3.15 A H 250 V)

Dimensions/Weight

Dimensions (H x W x D) 7.30 x 11.42 x 8.70"/185 x 290 x 220 mm

Weight 7.0 lbs / 3.20 kg

Please note these specifications are preliminary and conceptual in nature, and as such are subject

to change as product development progresses. This information is supplied for market research

purposes only and is not to be made public in any manner. This document is solely the property of

The MUSIC Group, or one of its subsidiaries, and must be surrendered upon request of the owner.

EUROLIVE

B205

Altri manuali per Eurolive B205D

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Behringer Sistema di altoparlanti

Behringer

Behringer EUROLIVE B212XL-WH Manuale utente

Behringer

Behringer Eurolive B207 MP3 Manuale utente

Behringer

Behringer CL3596 Manuale utente

Behringer

Behringer EUROLIVE B215XL Manuale utente

Behringer

Behringer Eurolive B812NEO Manuale utente

Behringer

Behringer EUROLIVE B615D Manuale utente

Behringer

Behringer Ultrabass BX300 Manuale utente

Behringer

Behringer EUROPORT EPS500MP3 Manuale utente

Behringer

Behringer EUROLIVE B115MP3 Manuale utente

Behringer

Behringer Eurolive B212 Manuale utente

Behringer

Behringer eurolive b512dsp Manuale utente

Behringer

Behringer EUROLIVE B315D Manuale utente

Behringer

Behringer Eurolive B205D Manuale utente

Behringer

Behringer Eurolive B212 Manuale utente

Behringer

Behringer Eurolive B912NEO Manuale utente

Behringer

Behringer Eurolive B205D Manuale utente

Behringer

Behringer eurolive b512dsp Manuale utente

Behringer

Behringer Eurolive B1020 Manuale utente

Behringer

Behringer TRUTH B1030A Istruzioni per il montaggio

Behringer

Behringer DR112DSP Manuale utente

Behringer

Behringer Eurolive B212A Manuale utente

Behringer

Behringer EUROLIVE B215XL Manuale utente

Behringer

Behringer EUROLIVE B212XL Manuale utente

Behringer

Behringer EUROLIVE B315D Manuale utente

Manuali Sistema di altoparlanti popolari di altre marche

JVC

JVC CA-MXK5R Manuale utente

LG NB4532B Manuale utente

JVC

JVC CA-FSH100 Manuale utente

5Core

5Core Pro Series Manuale utente

EAW

EAW MQV1394e Manuale utente

Lynx

Lynx GXR-LA10A Manuale utente

iLive

iLive ITB066B Manuale utente

RDX

RDX QuickStation 4 Manuale utente

Electro-Voice

Electro-Voice S-122 Manuale utente

Sven

Sven SPS-619 GOLD Manuale utente

Pioneer

Pioneer CS-7070 Manuale utente

EAW

EAW UB82e Manuale utente

Sondpex

Sondpex Active Speaker System and Digital Music... Manuale utente

JVC

JVC NX-PN7 Manuale utente

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuale utente

Yamaha

Yamaha NX-A01 - Speaker Sys Manuale utente

SE Audiotechnik

SE Audiotechnik I-LINE Manuale utente

Gemini

Gemini WRX-843 Series Manuale utente
