Belifu FDES115 Manuale utente
HEAT TENS & EMS
& MASSAGE UNIT
Model ：FDES115
Instruction Manual
The illustrations in this Manual book are effect
drawings,
please refer to the real object.
Thanks for using our product.
Take good care of this instruction.
Precaution:
Please read the instructions carefully before use.
If you have any questions, please refer to the
salesman, or ask your doctor.
Table of ContentsTable of Contents
1. Product Profile .............................................. 4
2. Intended use ...................................................... 5
3. Contraindications ..................................... 5
4. Product structure description .............. 5
5. Product description .................................. 8
6. Treatment procedures .............................. 11
7. Operation ........................................................... 12
8. After the treatment is completed .......... 16
9. Troubleshooting ............................................. 20
10. Product specifications ......................... 21
11. Final disposal ...................................... 22
12. Standardized symbolic description ..22
13. Electromagnetic compatibility
information .................................................... 23
14. Guarantee ........................................................ 31
4
1. Product Profile1. Product Profile
Working principleWorking principle
It acts on the human body through the electricity pulse
wave, the electric energy is sucked by the human body
and the energy form is changed, which causes a series of
physical and chemical changes, produces local or systemic
physiological reactions, and finally affects the pathological
process and plays a corresponding role.
Customer serviceCustomer service
Please download the manual on below link:
https://belifu.com/downloads/
AccessoriesAccessories
• Please use a 5V/1A adapter (input: AC100V~240V,
50Hz~60Hz, 0. 2A). Adapters that do not meet the
requirements may reduce the safety of the product. Please
make sure that the selected adapters meet the relevant
safety medical level safety certification requirements
5
(example: IEC60601-1).
• After the connection, it will be charged automatically.
Note:Note:
• This product does not come with an adapter, please
purchase separately.
• If you have any problems with the adapters, consult the
• Please charge the unit for 8 hours after the battery is used
up at the first time. Moreover, please charge it about 3
hours in the later use, it will show 3 bars which means full
charged.
2. Intended use2. Intended use
For TENS mode: To be used for temporary relief of pain
associated with sore and aching muscles due to strain from
exercise or normal household work activities.
For EMS mode: To be used to stimulate healthy muscles in
order to improve and facilitate muscle performance.
For MASSAGE mode: To be used for recovery of fatigue,
improves blood circulation neuralgia.
3. Contraindications3. Contraindications
• Acute disease, especially in patients suspected or suffering
from hypertension, thrombosis or malignant mass.
• Patients with various skin diseases.
• Patients with chronic pain disorders (e. g. metabolic
disorders) with reduced pain.
• Patients undergoing medication.
4. Product structure description4. Product structure description
4.1 Low frequency therapeutic apparatus4.1 Low frequency therapeutic apparatus
1 AB channel electrode
connection port
2 CD channel electrode
connection port
6
3 Type-C charging interface 4 Power
5 AB channel intensity
adjustment button /
B- unlock button
6 CD channel intensity
adjustment button/
-C unlock button
7 Time key/Pause key 8 Program selection/Heat key
4. 2 Display4. 2 Display
4. 34. 3 WaWarnrnings and Notesings and Notes
WaWarnrninging
We recommend not to use this therapeutic apparatus in
the following cases:
1) Do not use this device if the patient has any
implantable electronic or metal equipment. (e. g.
pacemaker).
2) Has epilepsy.
3) Severe lower extremity arterial circulation problems.
4) Abdominal or inguinal hernia site.
5) Do not use this device if you have a heart disease
without consulting a doctor.
6) Do not use this device on pregnant women.
7) Do not use this device over, or in proximity to,
cancerous lesions.
8) Be Fever.
9) Has cancer.
10) Do not use therapeutic instruments in high humidity
environments, such as bathing or showering in a
bathroom bathtub.
11) Can not be used after drinking.
7
12) Low-frequency therapeutic instruments can not be
used when using high-frequency surgical instruments.
13) Near the genitals.
14) Recommendation: do not use low-frequency
therapeutic instruments near shortwave or microwave
therapeutic equipment, (e. g. 1 M), where the output
of the low frequency therapeutic instrument used is
unstable.
15) The high frequency surgical equipment and
stimulatorr. When connected to a patient, burns may
occur at the stimulator electrode and may damage the
stimulator.
16) Patients undergoing medical treatment and feeling
abnormal.
17) Heart patients with neurological abnormalities in the
brain.
18) Patients whose body temperature exceeds 38℃ .
19) Infectious diseases Patients.
20) Patients who can not express their will.
21) Do not use this product while charging.
Note:Note:
1) Electrode pad is too long may cause suffocation. Keep the
product and keep away from children.
2) Make sure you are always aware of all warning items.
3) Stimulators should not be used in the throat and mouth.
This may result in severe throat muscle spasms and
muscle contraction, which is sufficient to block the airway
and cause dyspnea.
4) The application of electrodes near the thorax may increase
the risk of cardiac fibrillation
5) This stimulator should not treat unattended patients,
or suffer from emotional distress, dementia, and low IQ
people.
6) Use guidance has been detailed; any improper use may
lead to danger.
7) Do not use this device for any undiagnosed pain
symptoms, consult a doctor for diagnosis before use.
8) Electrodes can not be placed in arteries, head and pubic
area.
9) Patients suffering from heart disease, cancer or other
health-threatening conditions should consult a doctor
before using this device.
10) If the intensity of stimulation makes you feel
8
uncomfortable, reduce the intensity of stimulation to a
comfortable level. If the problem remains, please contact
your doctor.
11) Do not use this equipment in rooms where aerosol
(spray) and pure oxygen are used.
12) Please do not use this equipment near any highly
flammable substances, gases or explosives.
13) Please check that the cable and related connections are
in good condition before each use.
14) Turn off the device before using or removing the
electrode pad.
15) Electronic stimulators can only use electrode wires and
electrodes recommended by manufacturers.
Consult your doctor before using the device especiallyConsult your doctor before using the device especially
in the following cases:in the following cases:
• Acute disease, especially patients suspected or suffering
from hypertension, thrombosis or malignant mass.
• Patients with various skin diseases.
• Patients with chronic pain disorders (e. g. metabolic
disorders) with reduced pain.
• Patients undergoing medication.
Adverse reactionAdverse reaction
• Skin allergies caused by electrode sheetpad gels and
electrode irritation burns are potential adverse reactions.
If the skin appears sensitive response, should be
discontinued and consult your doctor.
• If the intensity of stimulation makes you feel
uncomfortable, reduce the intensity of stimulation to
a comfortable level, and if the problem persists, please
contact your doctor.
5. Product description5. Product description
5. 1 Instructions5. 1 Instructions
Please make sure the battery is sufficient before use, if the
battery is insufficient, please charge it in time.
Do not use this product while charging.
1) Paste the gel on the electrode pad.
2) Insert the electrode plug into the treatment instrument.
3) Attach electrodes pad to the site to be treated.
4) Press the Power button and select the program (Refer to
7).
9
Attention about electrodeAttention about electrode
• Do not use it by overlapping.
• Do not bend the electrode pad.
• Please try not to touch the adhesive surface with your
fingers.
• After bathing or sweating after exercise, please wipe the
parts to be treated before use.
• Do not pull the electrode wire. This will damage the wires
and electrode pad.
• Do not apply to damaged skin.
• If the electrode pad is not sticky, please replace it in time.
• The electrode pad is only for one patient.
• If you're allergic, stop using immediately and consult your
doctor.
• Please read the instruction of self-adhesive electrode
before use.
• When the electrode pad is stuck to the clothes, don't tear
it off heavily. As long as the inside of the side with the
electrode pad is covered with water, it can be removed
easily.
5. 2 TENS5. 2 TENS/MASS/EMS/MASS/EMS
Percutaneous nerve electrical stimulation, meaning electrical
stimulation of the nerve through the skin.It's a non-
drug method of treating pain. TENS electrical stimulation
produced by electrical pulses is sent to the nerve to modify
your perception of pain. Electrical stimulation can't cure
physical problems, it just help control pain. Electrical
stimulation doesn't work for everyone, but for most patients
it's reducing or eliminating in addition to pain is effective, so
that patients can return to normal activity.
Suitable for relaxing body, relieving fatigue, reducing stress
and improving sleep.
10
Muscle electrical stimulation has been widely used in sports
and rehabilitation for many years and is widely used as
approved methods. The uses of EMS in sports and fitness
are to complement traditional muscle training, increase the
effectiveness of muscle groups and adapt them to the body
ratio to achieve the desired aesthetic effect. EMS applications
two aspects of the effect. On the one hand to achieve the
effect of muscle tissue enhancement (activation application);
on the other hand to achieve the effect of relaxation and rest
(relaxation application).
5. 3 Paste the electrode pad to the area requiring5. 3 Paste the electrode pad to the area requiring
treatmenttreatment
1) Shoulder: The shoulder may be stiff and painful due to
long-term of movement and weight bearing.
Stick the electrodes to the cervical spine.
Stick the electrodes to the shoulder.
2) Lower back: there are many possible causes of lower back
pain. Lower back pain, which is suitable for low frequency
therapy, mainly includes lumbar acid or muscle pain, nerve
pain and so on.
Take the spine as the center, paste on one side of the
pain or left and right.
3) Joint: excessive movement leads to increased load and
joint pain.
Please paste two places in the pain joint.
4) Arm: arm pain may be due to muscle congestion and
fatigue and poor blood circulation.
Please paste the upper and lower parts of the
arm.
5) Foot: cold feet may be caused by the destruction of the
balance of the nervous system and poor blood circulation
in the hands and feet. The swelling or tiredness of the feet
may be due to the deterioration of blood and fluid reflux.
Indice
Altri manuali Belifu Massaggiatore
