Belkin TuneBase Manuale utente

8820bt01379 Rev. A00 F8J037bt

TuneBase™ AUX with Hands-Free

User Manual

TuneBase™Direct with Hands-Free

SECTIONS 1 2 3 654Table of Contents

TABLE OF CONTENTS

1 Introduction ..................................................1

Features ........................................................1

What’s in the Box ................................................2

2 Set Up Your TuneBase..........................................3

Plug In Your TuneBase ............................................3

Dock Your iPod or iPhone .........................................4

Dock Your iPod or iPhone After Initial Setup ...........................9

3 Use Your TuneBase ...........................................11

Connect Your TuneBase to Your Car Stereo ..........................11

Activate Siri Assistant ............................................12

Play Music .....................................................12

Receive Calls ...................................................13

4 Troubleshooting ..............................................15

5 Safety Warnings ..............................................18

6 Information ..................................................19

TuneBase™Direct with Hands-Free

SECTIONS 2 3 654Table of Contents 1

INTRODUCTION

Features

iPod and iPhone

Play your iPod through your car’s stereo

Keep your iPod in its case

Rotate your iPod to horizontal view

Secure and flexible cradling for any size iPod

iPhone only

Receive calls from your iPhone and talk

hands-free

Listen to calls through your car stereo

Built-in mic for hands-free phone calls

Easily activate and use Siri Assistant

TuneBase™Direct with Hands-Free

SECTIONS 2 3 654Table of Contents 1

INTRODUCTION

What’s in the Box

1. TuneBase AUX with Hands-Free

2. Fit Ring (optional)

3. 3.5mm Audio Cable

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

Plug In Your TuneBase

Follow the steps in this section to set up your TuneBase AUX with Hands-Free (the TuneBase).

These steps coincide with those in the Quick Install Guide but provide more detail.

2. Test the tightness of fit in the power

outlet. The TuneBase should give some

resistance when you try to rotate it inside

the power outlet. It should not rotate or

move on its own.

If the TuneBase is too loose or too tight in

the power outlet, see the troubleshooting

section for instructions on adjusting

the fit.

Warning: Do not rotate the TuneBase in the

power outlet. If you experience resistance,

unplug the TuneBase and reinsert it in

the desired position. Failure to do so may

damage the cigarette lighter adapter or

power outlet.

1. Insert your TuneBase into the power

outlet in your car.

Set Up

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

Dock Your iPod

1. Push the button on the springboard and

slide it to its maximum height.

2. Connect your iPod to the TuneBase dock

connector, making sure it is fully seated.

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

3. Push the front of the iPod back until the

back of the iPod touches the front of

the springboard.

4. Push down on the top of the springboard

until it holds your iPod securely in place.

Note: After you have adjusted the height of

the springboard, there is no need to adjust

the TuneBase to insert and remove your iPod.

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

5. Connect the audio cable to the

headphone jack on your iPod.

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

Landscape

6. Bend the flexible neck to position your iPod.

no no no

Warning: Do not remove the TuneBase from

the cigarette lighter adapter when an iPod is

in the cradle.

Do not position your TuneBase as follows:

TuneBase™Direct with Hands-Free

SECTIONS 1 3 654Table of Contents 2

SET UP YOUR TUNEBASE

Remove your Device from your TuneBase

1. Disconnect the audio cable from your iPod.

2. Push back on the front of the springboard and tilt your iPod forward until it clears the

lip of the springboard.

3. Lift your iPod out of the cradle.

Removal

1 2 3
