Belkin F8E860ukBNDL Manuale utente
Belkin Tech Support
US: 800-223-5546, ext. 2263
310-898-1100, ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 235 546
New Zealand: 0800 235 546
Belkin Corporation
501 West Walnut Street
Compton, CA 90220-5221, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
+44 (0) 1933 35 2000
+44 (0) 1933 31 2000 fax
© 2005 Belkin Corporation. All rights reserved. All trade names are registered trademarks of
respective manufacturers listed. P74834uk
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
+31 (0) 20 654 7300
+31 (0) 20 654 7349 fax
Belkin Ltd.
7 Bowen Crescent, West Gosford
NSW 2250, Australia
+61 (0) 2 4372 8600
+61 (0) 2 4372 8603 fax
Wireless Desktop 280
P74834-A_F8E860-BNDL_man.indd 1 19/5/05 11:28:12 am
Wireless Desktop 280
User Manual
F8E860-BNDL
Discover easy Internet and multimedia
functionality with wireless convenience
Keyboard
Mouse
P74834-A_F8E860-BNDL_man.indd 2 19/5/05 11:28:24 am
Table of Contents
Table of Contents
1. Introduction .........................................................................1
Package Contents ................................................................2
Software Compatibility .........................................................2
2. Quick Setup ..........................................................................3
For PS/2 Connections ..........................................................3
For USB Connections ..........................................................4
3. Software Driver Installation ................................................5
For Windows 98 SE, 2000, Me, and XP ..............................5
4. About your Belkin Software ................................................6
For the Keyboard .................................................................6
Office Hot Key Features .......................................................6
Keyboard Hot Key Features .................................................9
For the Mouse ....................................................................12
5. Troubleshooting .................................................................15
6. Information ........................................................................17
P74834-A_F8E860-BNDL_man.indd 3 19/5/05 11:28:25 am
1
Congratulations and thank you for purchasing the Wireless
Desktop 280 by Belkin. We appreciate your business and we are
sure you will enjoy years of reliable use with these high-quality
input devices.
Although the Wireless Desktop 280 will function out-of-the-box
as a Human Interface Device (HID) or standard PS/2 keyboard
and mouse, for advanced programmability and functionality we
recommend that you use the included software. This will give you
added flexibility and allow you to customize your settings and
reassign keys to fit your preference.
Introduction
P74834-A_F8E860-BNDL_man.indd 1 19/5/05 11:28:25 am
1
2
3
4
5
6
7
8
9
10
2
Section
Package Contents
Software Compatibility
Windows® OS
for USB interface:
Windows XP, Me, 2000, 98 SE
Windows OS
for PS/2 interface:
Windows XP, Me, 2000, 98 SE
Wireless
Keyboard
4 AA Alkaline
Batteries
Wireless 8-Button
Optical Mouse
User Manual
USB and PS/2
Receiver
CD Software
Driver
Introduction | Package Contents
PS/2 Adapter
P74834-A_F8E860-BNDL_man.indd 2 19/5/05 11:28:27 am
Quick Setup | For PS/2 Connections
3
For PS/2 Connections
1. Be sure that your computer is powered off.
2. Connect the receiver to
your computer’s PS/2
ports. The receiver has a
two-headed connector for
the keyboard and mouse
connection (purple is for
the keyboard and the USB
connection, and the green
adapter is for the mouse).
There is also a diagram on
the top connector for identification. Your computer will either
have a matching color scheme or an illustration next to the
port, or both (See Fig. 1).
3. Install the batteries into your keyboard and mouse. Please
make sure you follow the diagram on the inside of the battery
compartment to ensure that you install them correctly.
4. Power on your computer.
5. The receiver automatically scans for and synchronizes the
keyboard and mouse when you power on the computer. Your
keyboard and mouse should now be functioning.
6. If synchronizing does not occur automatically, please refer
to the information on “Synchronizing” in the Troubleshooting
section at the end of this User Manual.
Fig. 1
P74834-A_F8E860-BNDL_man.indd 3 19/5/05 11:28:27 am
Quick Setup | For USB Connections
1
2
3
4
5
6
7
8
9
10
4
Section
For USB Connections
1. Be sure that your computer is powered on. If you are running
Windows 98 SE, Me, or 2000, you will need to have your old
keyboard and mouse connected during the installation.
2. Install the batteries into your keyboard and mouse. Please
make sure you follow the diagram on the inside of the battery
compartment to ensure that you install them correctly.
3. Connect only the receiver to
your computer with the USB
connector. (Do not connect
the purple PS/2 connection as
it is not necessary in a USB
environment) (See Fig. 2).
NOTE: When connecting the USB cable to your computer,
Windows will start a New Hardware Wizard. Windows XP
completes the Wizard automatically. In Windows 98 SE, Me, and
2000, you will need to go through the New Hardware Wizard
setup with your old keyboard and mouse. Windows 98 SE may
require you to insert your Windows 98 SE Installation CD into
your computer’s CD-ROM drive to complete the install.
4. The receiver automatically scans and synchronizes the
keyboard and mouse. Your keyboard and mouse should now
be functioning.
5. If synchronizing does not occur automatically, please refer
to the information on “Synchronizing” in the Troubleshooting
Fig. 2
P74834-A_F8E860-BNDL_man.indd 4 19/5/05 11:28:28 am
Software Driver Installation
5
For Windows 98 SE, Me, 2000, and XP
NOTE: The keyboard and mouse should now be functioning
for basic input. If this is not the case, carefully repeat the Quick
Setup procedures in the previous pages. When the keyboard
and mouse are functioning for basic input, install the software
described in the following section.
NOTE: If you have previously installed any keyboard or mouse
driver on your computer, you must uninstall it/them before
proceeding with this installation procedure.
1. Insert your Wireless Desktop 280 driver installation CD into
your CD-ROM drive. After a few moments, the main menu will
start automatically.
2. Select “Install Driver” and your computer will begin the
installation process.
3. Follow the on-screen instructions to install software.
NOTE: If the main CD does not auto-start, click the “Start”
button and select “Run”. From the run dialog box, enter
“<drive>:\Setup.exe” and click “OK” (“<drive>” being the
letter of the drive that identifies your CD-ROM drive under
“My Computer”. For example, if the CD is in drive D, enter
“D:\Setup.exe”.).
4. When prompted, click “Finish” and restart your computer.
This completes the installation process.
P74834-A_F8E860-BNDL_man.indd 5 19/5/05 11:28:28 am
6
Section
About your Belkin Software | For the Keyboard
1
2
3
4
5
6
7
8
9
10
The Wireless Desktop 280 software provides a suite of tools that
will enhance your experience with the Belkin Wireless Desktop
280. For the keyboard, it allows you to program and customize
your hot keys, and gives you quick access to your media keys, as
well as other short cuts.
For the Keyboard
Power Management keys require no software to get this
feature to work.
Important: Power Management keys are controlled by your
system. If you are experiencing difficulty with their functioning,
please contact your computer manufacturer for information on
compatibility and functionality of Power Management keys on
your system.
NOTE: If your computer supports Power Management hot keys,
we recommend you connect the keyboard directly to your PC’s
PS/2 port. If you choose to use USB, connect to an available
onboard USB port.
Software installation is required to enable functioning of the
following USB-PS/2 keyboard hot keys:
Office Hot Key Features
With your F-lock key on, F1 through F12 turn into office hot keys.
F1 Help F5 Replace F9 Reply
F2 New F6 Spell F10 Reply All
F3 Open F7 Undo F11 Forward
F4 Save F8 Redo F12 Send
P74834-A_F8E860-BNDL_man.indd 6 19/5/05 11:28:29 am
7
To program keyboard hot keys:
1. Click “Start”.
2. Click “Programs”.
3. Click “Belkin Office Keyboard”.
4. Then double-click on “Belkin Office Utility Keyboard”.
5. An on-screen display of the hot keys will appear. Select the
button to program.
6. Then under the “Keys” tab, select “Special Function”.
7. In the drop-down menu, select from:
Copy Paste Open New
Cut Redo Save
8. Then click “Apply”.
9. Next, click “OK”.
10. Repeat steps 5–9 to program other hot keys.
To restore default settings, click “Restore All”.
To program a customized hot key:
1. Follow steps 1–5 in “To program keyboard hot keys”.
2. Select “Custom”.
3. Then click “Set”.
4. Follow on-screen instructions to complete programming.
5. Click “Apply”.
6. Then click “OK”.
About your Belkin Software | Office Hot Keys Features
