Belkin VISION N1 Manuale utente

N1 Wireless Router Quick Installation Guide

Setup OverviewSetup Overview

StepStep

Hardware Connections: Hardware Connections:

Use the instructions in thisUse the instructions in this

Guide to connect your Router,Guide to connect your Router,

computer, and modem.computer, and modem.

StepStep

Automatic Conﬁ guration:Automatic Conﬁ guration:

Insert the CD into yourInsert the CD into your

computer and follow thecomputer and follow the

on-screen instructions.on-screen instructions.

StepStep

Connect other Computers:Connect other Computers:

The CD can assist you in The CD can assist you in

connecting other computersconnecting other computers

to your new network.to your new network.

Step 1 - Hardware Connections







Unplug your modem’s power cord.

Put the Router next to the modem.

Raise the Router’s antennas.

Locate the networking cable that connects your

modem and computer.

Unplug that cable from your modem, and plug it into

any gray port on the back of the Router.

Find your new networking cable (it came in the box

with your Router) and connect it to the yellow port on

the back of the Router.

Connect the other end to your modem, in the port

that’s now free.

(Optional)(Optional)

Belkin provides free technical support via phone and the Web. Belkin provides free technical support via phone and the Web.

However, we encourage you to attempt (or retry) Steps 1 and However, we encourage you to attempt (or retry) Steps 1 and

2 before contacting Support. The Setup Assistant has built-in 2 before contacting Support. The Setup Assistant has built-in

intelligence to help diagnose and ﬁ x common problems.intelligence to help diagnose and ﬁ x common problems.

If you’re still having trouble, contact Belkin Support.If you’re still having trouble, contact Belkin Support.

UKUK

http://www.belkin.com/uk/http://www.belkin.com/uk/

Click on Support Centre > Click on Support Centre >

Networking SupportNetworking Support

0845 607 77870845 607 7787

Step 1 - Hardware Connections (continued)

Plug in your modem’s power cord.

Wait 60 seconds for the modem to start up.

Plug the Router’s power supply into the black port

on the back.

Plug the other end into the wall outlet.

Wait 20 seconds for the Router to start up.

Look at the display on the front of the Router.

Make sure the “Wired” and “Router” icons are lit

up in blue.

If they are not, recheck your connections.

Insert the CD into your computer.

The Setup Assistant will automatically appear on your

computer’s screen.

Follow the instructions there.

Step 2 – Setup Assistant

SupportSupport

P75168ukP75168uk

F5D8231uk4F5D8231uk4

registered trademarks of respective manufacturers listed.registered trademarks of respective manufacturers listed.
