BenQ Joybook 3000 Manuale utente
Joybook 3000 User Manual
Before using your Joybook, please read the Quick Start Guide to get
your computer up and running. Read this manual for more detailed
information that can help you use all of your Joybook's capabilities
more effectively and enjoyably.
Table of Contents
Joybook 3000 Features................................................................... 3
Function Hotkeys ........................................................................... 8
Getting Started with Windows XP ............................................ 10
Using the Q-Media Bar ................................................................ 11
Your Digital Entertainment Center --- BenQ Joybook 3000 ... 12
Sending and Receiving E-mail................................................ 13
Getting Online ........................................................................ 14
Listening to Music and Creating Custom Music Collections 15
Watching Video and Making Your Own Movies.................. 16
Viewing Digital Photographs and Creating Slide Shows .... 18
Burning CDs ............................................................................ 20
Attaching External Display Devices ........................................... 22
Installing Additional Memory...................................................... 24
Recommendations and Troubleshooting................................... 26
Basic Specifications ...................................................................... 28
Information on Safety, Cleaning, and Battery Maintenance.... 29
2 Copyright
Copyright
Copyright © 2003 by BENQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of this company.
Disclaimer
BENQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability or fitness for any particular purpose. Further, BENQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof without obligation of this company to notify any person of such revision
or changes.
*Windows, Internet Explorer and Outlook Express are trademarks of Microsoft Corporation. Others are copyrights of their respective companies or organizations.
Joybook 3000 Features 3
Joybook 3000 Features
Hard Disk Drive Activity Indicator
Lights up in blue when the computer is reading
the data in the hardware.
Four-in-One Card Indicator
Lights up in blue when the computer is reading
the card data.
Caps Lock Indicator
Lights up in blue when the Caps Lock is
engaged.
Num Lock Indicator
Lights up in blue when the Num Lock key is
engaged.
Scroll Lock Indicator
Lights up in blue when Scroll Lock is active.
Left and Right Selection Buttons
Equivalent to the left and right buttons on a
mouse.
Internet Hotkey
Starts up the Internet Explorer Web browser.
E-Mail Hotkey
Starts up the Outlook Express e-mail client.
Customizable Hotkey 1
Can be set by the user to open the same
application as the third icon on the Q-Media bar.
Customizable Hotkey 2
Can be set by the user to open the same
application as the fourth icon on the Q-Media
bar.
Power Button
Turns the computer on or off.
Cover Switch
To u c h P a d
For controlling the on-screen cursor. Can be
activated and deactivated by pressing the Fn +
F6 hotkey combination.
4 Joybook 3000 Features
Power Button/Play/Pause
Music Button
Can play music even when the
computer is turned off.
Stop/ Eject
Stops playback from an audio CD. If
pressed again, ejects the CD.
* Power automatically cuts off if the
SuperDJ stops playing for more than
10 minutes.
Rewind
Allows fast backwards searching on
audio CDs.
Forward
Allows fast forwards searching on
audio CDs.
Select Play Mode
When power on, SuperDJ is set to
play once from the beginning to the
end. When the SuperDJ plays, pauses
or stops, press both and to
select playback once, repeated
playback, repeated single piece
playback or random playback.
LCM Display Screen
Limitations on LCM:
1. LCM displays 199 songs at most,
while the 200th song will be
displayed as the first one.
2. A song list can play at most 999
songs. Each list is categorized as
P1, P2,..., P9, and SuperDJ
supports 9 song lists at most.
3. The file folder in the playback
media runs from F0,F1,F2,...,to
F9. F0 is the root menu, and may
be selected only once, while F1
stands for the first file folder.
SuperDJ supports 99 file folders
at most.
Lower Volume
Decreases the volume of CD playback.
Raise Volume
Increases the volume of CD playback.
Select Playback Media
and Song List/File Folder
When SuperDJ is off, you can press
both and to select another
playback media*. If either button is
pressed, switch to another song list or
file folder.
* Playback media includes hard disk,
CD, Flash Card and USB device.
Infrared Port
The interface for infrared
communications allows the transfer of
data to and from PDAs or mobile
phone or computer with infrared
capabilities.
Joybook 3000 Features 5
Power Jack
For connecting the AC adapter.
VGA Port
For connecting external display devices,
such as monitors and projectors.
S-Video Out
Outputs S-Video signals to a television
set or a projector.
USB Port
For connecting peripherals such as
mice, digital cameras and MP3 players
that use the USB interface.
Modem Port
Accepts an analog telephone line for
use with the internal modem.
Ethernet Port
Allows the computer to connect to an
Ethernet 10/100BaseT network.
Ventilation Holes
For dissipating heat and keeping the
computer at an optimal temperature.
Parallel Port
For connecting devices such as printers
that use the parallel port interface.
Ventilation Holes
For dissipating heat and keeping the
computer at an optimal temperature.
Kensington Lock
6 Joybook 3000 Features
Ventilation Holes
For dissipating heat and keeping the
computer at an optimal temperature.
Four-in-One Slot
Reads Memory Stick Card, SD Card,
Smart Media Card and MMC Card.
PC Card Expansion Slot
Allows the functionality of the
computer to be extended through
the use of a wide variety of PC Card
modules available—for example,
wireless networking cards and mobile
disks.
PC Card Eject Button
Before ejecting a PC Card:
1. Quit all PC Card applications
and shut down all PC Card
functions.
2. Push in, then release the PC
Card eject button, causing it to
pop out.
3. When the button has popped
out, push it in again to eject the
PC Card.
Wireless Network Card
Power Button (The function is
currently not supported.)
Wireless Network Card
Activity Indicator (The function
is currently not supported.)
Power Indicator
Lights up in blue when the computer
is turned on. When the system enters
sleep mode, turns orange.
Battery Indicator
When the computer is in use, lights up
in blue. When the battery is charging,
turns orange. Flashing blue indicates
that the battery is running low.
Flashing orange indicates that the
battery is malfunctioning, in which case
you should contact service personnel.
Joybook 3000 Features 7
Earphone Jack/S/PDIF
Outputs optical sound. Can be
connected to optical audio-enabled
speakers for high quality music.
Line-in
Inputs sound into the computer.
Mic in
Inputs speech into the computer.
IEEE 1394 Port
For connecting external display devices,
such as monitors and projectors.
USB Port
For connecting peripherals such as
mice, digital cameras and MP3 players
that use the USB interface.
DVD Drive
Supports multi-functional optical
module for music CD, VCD and DVD.
Disks can be inserted/ejected pressing
the small rectangular button at the
center of the Drive.
USB Port
For connecting peripherals such as
mice, digital cameras and MP3 players
that use the USB interface.
PS2 Mouse Port
8 Function Hotkeys
Function Hotkeys
You can use the function hotkeys to access commonly used functions or make quick settings. To use the hotkeys, press and hold the Fn key in the
lower left corner of the keyboard, and then press the desired hotkey.
Fn + F1
Opens online help.
Fn + F2
Puts the computer into sleep mode.
Fn + F3
Switches display between the screen
and an external monitor, or allows
simultaneous display.
Fn + F4
Decreases screen brightness.
Fn + F5
Increases screen brightness.
Fn + F6
Activates or deactivates the touch
pad.
Fn + F7
Activates or deactivates the
speakers.
Fn + F8
Lowers speaker volume.
Fn + F9
Increases speaker volume.
Fn + F10
Turns on or off the Logo backlight.
Function Hotkeys 9
Windows Key
Functionally equivalent to clicking the
Start button on the Windows
desktop.
+ Tab
Makes the next item on the Windows
task bar active.
+ E
Opens the My Computer window for
browsing disks and files.
+ M
Minimizes all windows.
Shift + + M
Cancels minimization of all windows.
+ R
Activates Run dialogue box.
Num Lock
Activates the numeric keypad
integrated in the keyboard.
Caps Lock
Capitalizes all text entered.
Application Key
Provides the same function as the
right touch pad button, bringing up a
contextual pop-up menu.
10 Getting Started with Windows XP
Getting Started with Windows XP
Your Joybook 3000 comes installed with Windows XP Home Edition, Microsoft's latest operating system for consumer PCs. The first time you start
up your computer, Windows XP will ask you a few questions. Answer the questions to ensure that your full rights are protected.
1
2
