Beok Controls BOT-R315 Manuale utente

RF GasBolier

Programmable Therm

BOT-R315

ostat

Specification

•LCD Size: Diameter 55mm

•

Power Supply: R315 3V DC （2 x AAA 1.5 V）

Accuracy/Tolerance : +/ -

RCV31522Vac, 50/60Hz

Current Load:10A (Resistive)

Ambient Temp. Range: 0~99.5 ℃

Setpoint Range: 5~35 ℃

0.5℃

Timing Tolerance : <1%

Thermistor : 10KΩ@25 ℃

Storage Conditions Temp.: -10~60 ℃

Humidity:< 90% r.h.

Battery Life: 6 months

RF Module: Single Way Module

Frequency: 433 Hz(defaulted

Display & Buttons

1.Week day: from Monday to Sunday

2. Programmable Time Zone

3. Room Temperature

4. Buons Lock

5. Setpoint,or Floor Temperature(It displays when

external sensor acvated)

6. Time of day(00:00..23:59)

7. Heang is on

8. Automac Programmable Mode: 7 days, 6 me zones

9. Comfort Mode

10. Energy Saving Mode

11. Holiday Mode

12. Baeries Comsumpon Indicator

14.Manual Mode(overriden)

•15. Working Modes selecting .

1)Press shortly to select Comfort Mode, Energy

Saving Mod, Holiday Mode, Automatic Mode, and Manual

Mode(Overridden Mode)

2) Synchronizing Clock

Press button to switch off thermostat, and then press

hol

and hold Mbutton for 3 secs,adjust clock from Minute,

Second and Weekday via .

3) There are 4 Time Zones in total, user is able to customize

Time Zones from 1 to 4 according to their demand. Press and

d buon for 3 seconds , it will display 4 and Monday,

adjust the numbers(1 to 4) of Time Zones via . Press

Period and relave Setpoint. Sequence is from Hour (1 st me

zone), Minute(1st me zone) and Setpoint(1 st me zone)

shortly to enter into Automac Mode Sengs of each Time

Hour (4 thme zone), Minute(4th me zone) and Setpoint(4

me zone).

Aer Sengs of Monday is done, press shortly and

switchover from Tuesday to Sunday, follow the same seng

steps as above.

Daily Setting

1st Time Zone

Hour Minute Setpoint

……

4th Time Zone

Hour Minute Setpoint

Decreasing or Increasing value by 10 mins via

buttons.

Mon. Tue. Wed. Thur. Fri. Sat. Sun.

3 4

•18.

Temperature down, or other parameters seng

•

19.

On/oﬀbuon

Parameters Setting

Press button to switch off the and then press and hold

button for 3 second.

•D1 Diff. Temp of Switch On/ Switch off :

•from 0.2 ℃~ 2.0℃, select by

buttons

•D2

Temperature Calibrition

•

℃

+ 4 ℃

select by buttons

•D3

Frost Protection

•5℃to 15 ℃

select by buttons

•D4 ~D7 RF Code

•16.

Temperature up, or other parameters setting

In case of internal and external sensors are selected,press

button for 3 sec, Setpoint is displaying external

sensor’s temperature; after 3 sec, it returns to setpoint.

•17.

•Ex

factory Setting

Week day

Time Zone

Mon. Tue. Wed. Thur. Fri. Sat. Sun.

00:00~06:00

19℃19℃19℃19℃19℃19℃19℃

06:00~11:30

22℃22℃22℃22℃22℃22℃22℃

11:30~16:30

20℃20℃20℃20℃20℃20℃20℃

16:30~00:00

23℃23℃23℃23℃23℃23℃23℃

Sengs

RF IP Learning:Transmier and Receiver is well paired ex-

factory.

If newlearningis required.Pleasefollowthe stepsas below:

1. Pressand hold the RF Conneconbuonon receiverunl LED

2(referto belowphoto) is ﬂashingin greenrapidly

2. Switch oﬀthe thermostat, and press and hold the

thermostat'sON /OFF buon for 3 secondsunl the menu

seng appears

3. Switchto the d6 sengsvia ON/OFFbuon,and then press

on thermostat to conﬁrm the connecon

.Switch on the

thermostat, and the green LED 2 (refer to below photo) on

receiverwill turn oﬀcompletely.

LED 1 (Red)LED 2 (Green)

RF Connecon

Dimension

Unit:mm

Replacement of Baeries

If the baery symbol appears, the baeries are almost

exhausted and must be replaced

Warranty

We oﬀer warranty of 12 month, from the sales date. If it is not

the quality problems, or beyond the warranty period, we will

charge for the aer

-sales services

Push and hold and buonssimultaneously

for 5 sec to LOCK all buons

Push and hold and buons simultaneously for

5sec to UNLOCK all buons

•

Child Lock/Unlock:

Wiring Diagram
