Bernard Shortstub 40B Manuale utente

Electrodes can be used to within one inch of

the high heat, high impact head compared with

the normal three inches of the electrode that is

leftover when using a typical tong-type holder.

Bernard Shortstub greatly improves

productivity because it is designed for quick,

easy installation of electrodes and it is built

to last with a proven high impact, high heat

replaceable head.

Bernard Shortstub models provide long life

because the replaceable head can be ordered

separately and installed quickly, eliminating total

replacement.

Over 2,000 pounds of gripping pressure

enables the electrode to be bent to a desired

shape for access to difﬁcult welds.

40B Shortstub®

Time Tested Performance.

Our Manual Welding Products provide

high quality with a wide range of

styles, sizes and capacities to enhance

your welding applications.

Issued July 2007 • SPEC SS-1.2

Shortstub®

Stick Electrode Holder

USA

Made with

Pride and without

Compromise in the

Bernard's Shortstub® has

maintained its time-tested

design for decades.

Phone: 800-946-2281 (US Only) 708-946-2281 (Outside US)

Fax: 708-946-6726

For more information, visit us at BernardWelds.com

Bernard®

An Illinois Tool Works Company

449 West Corning Road, Box 667

Beecher, Illinois 60401 USA

Speciﬁcations

Capacity Electrode

Size

Weight Length Cable

Connection

Cable

Socket

400 Amps

at 60%

duty cycle

1/16" - 1/4"

(1.6 mm - 6.4 mm)

17oz

(481 g)

8 3/4

(22 cm)

Model “B” large

ball point screw

connection

19/32"

(1.5 cm)

Replacement Parts List

1. Head Assembly K40

2. Coil Spring S5

3. Handle (molded) MH4

4. Connector Body B37

5. Ball Point Set Screw B33

6. Head Insulator (Pair) EL

7. Boot BB4

8. Snap Ring SR4

9. V Jaw Spring V4

10. Jaw J4

11. Jaw Pin JP4

12. Head H4

13. Pressure Pin PP4

40B Shortstub®

2345

11 12 13
