P6525ASS16P6818ASS16
Skimmer
Body Screw Basket Float Adjustable
Pole Frame Hook Hook
P6521ASS16 P6522ASS16 P6523ASS16
Cover Rim
P6817ASS16 P6526ASS16 P6527ASS16 P6528ASS16
Arm
P03868
Hose Adapter
P6531ASS16
Hose
Parts Reference
Overview
2
POOL SURFACE SKIMMER
OWNER’S MANUAL
WARNING
IMPORTANT SAFETY INSTRUCTIONS. READ AND FOLLOW ALL INSTRUCTIONS.
WARNING:To reduce the risk of injury, do not permit children to use this product.
WARNING:Assembly and disassembly of this product should only be performed by adult.
WARNING: Do not remove or obstruct the float opening while the filter pump/sand filter is operating.
WARNING: Keep hands and hair away from the Skimmer while the filter pump/sand filter is operating.
WARNING: Do not use the filter pump/sand filter while the pool is occupied.
WARNING: Ensure the filter pump/sand filter is unplugged before preforming any maintenance or there
will be a severe risk of injury or death.
NOTE: Remove the product from the pool before placing a cover over the pool.
NOTE: Please examine and verify all components are present before use. Notify Bestway at the customer
service address listed on this manual for any damaged or missing parts at the time of purchase.
NOTE: Drawings are for illustration purposes only and may not reflect actual product. Drawings are not to
scale.
SAVE THESE INSTRUCTIONS
Specification
Filter Pump/Sand Filter Compatibility：
Pool Compatibility：For use with all above ground pools
except steel wall pools
2,006 L/h (530 gal./h) flow rate and above
NOTE:
1. Assemble the hook: put the adjustable pole (P6525) through the adjustable fastener on the hook (P6527 or
P6526). Attach the assembled hook to the skimmer body and tighten it with the provided screw (P6521).
(See Fig.2)
2. FOR FAST SET
TM
AND OVAL FAST SET
TM
POOLS (See Fig. 3(a)) Place the assembled hook onto the
pool’s inflatable ring near the outlet valve, and attach the arm (P6528). You can adjust the opening of the hook
by pressing and sliding the arm at the same time.
3. FOR STEEL PRO
TM
FRAME AND RECTANGULAR FRAME POOLS (See Fig. 3(b)) Place the assembled frame
hook onto the pool’s top rail near the outlet valve. Adjust the hook if necessary and tighten the nut on the
frame hook (P6526).
NOTE:
We supply Hose Adapter, use it for your pool. (See Step 4a1)
If there are two outlet valves on your pool, please block one of them. (See Step 4a2)
Operation
1. The float should be floating off the skimmer body by 5 cm to 10.1 cm (2 in. to 4 in.). To adjust the float height,
loosen the screw (P6521), slide the skimmer body (P6818) up or down, and tighten the screw. (See Fig.6)
IMPORTANT: The skimmer must be perpendicular to the water surface at all times.
2. Plug in the filter pump/sand filter to activate the skimmer.
Storage
1. Disassemble the product.
2. Clean and dry all the parts thoroughly.
3. Store in a warm dry place.
