BETA 599 DGT-A/20

Electronic torque wrench

Direct torque and angle readout

MAIN FEATURES

– Digital driving torque and angle readout

– +/- 2% and +/- 2° accuracy (90° rotation at a rate of 30°/sec)

– CW and CCW operation

– Peak hold and track mode selectable

– Buzzer and LED indicator for presettable target driving torque or angle

– 5 selectable engineering units (N-m, ft-lb, in-lb, kg-cm, “ ° ”)

– Auto Sleep after about 5 minutes idle

– Rechargeable batteries are compatible

NAMES AND FUNCTIONS OF PARTS

347

810

1. Reversible Ratchet Head

2. Direction Lever

3. LCD Readout

4. Buzzer

5. Calibration Port

6. Buttons

7. Battery Cover

8. Handle

9. 1/2” Square Drive

10. Antislip Handle

11. LED Indicators

12. Driving torque/angle value

13. Read-in number

14. Units (N-m,ft-lb,in-lb,kg-cm,“ ° ”)

14. Peak/Track Mode

16. Power On / Clear Button

17. Read-in selection buttons

18. Unit/Setting Button

19. Up/Down Button

Model

N°.

Operation

Range

(N-m)

Square

Drive

(inches)

Alarm

Setting

Range

(N-m)

Lenght

(mm)

599 DGT-A/20 40-200 1/2” 10-200 519

Beta 599 DGT-A/20

Accuracy CW: ±2% CCW: ±2%

Operation Mode Peak Hold / Track

Unit Selection N-m, ft-lb, in-lb, kg-cm “ ° “

Head Type Reversible ratchet

Gear Teeth 72

Buttons 5

Bright LED 12 LEDs / 4 red + 8 green

Battery AA (R6) x 2

Battery Life (Continuous Operation) ~ 110 hours

Battery Life (Standby) ~ 1 year

Operating Temperature -10°C / 60°C

Storage Temperature -20°C / 70°C

Humidity Up to 90% non-condensingone

SPECIFICATIONS

Battery and cover

POWER ON AND RESETTINGWRENCH

– Press to power on the digital torque wrench.

– In the “torque” mode, the screen will display a preset value.

– In the “angle” mode, the screen will display rst a “zero” value, and then a preset angle value.

BATTERY INSTALLATION

– Remove the battery cover.

– Insert two R6/AA batteries matching the -/+ polarities of the battery to the battery compartment.

– Put on the battery cover and rotate it tightly according to the following figures.

– Usually press to reset the digital torque wrench before using it.

ATTENTION:

If an external force is applied to the torque wrench during the power-on/reset or wake up period, an

initial torque offset will be found in the memory.

IMPORTANT:

When the wrench is used in the “angle” mode, it should be placed horizontally on a plane before any

values are changed. If this instruction is not followed, a set of angle indicators will start blinking on the

dial:

To start the wrench, press

ACTIVATION DURING SLEEP MODE

– The wrench will auto sleep after about 5 minutes idle for power saving.

Press to wake up the wrench during the sleep mode.

RESETTINGWRENCH

– If the wrench does not function normally, press together to reset the wrench.

LOW BATTERY VOLTAGE PROTECTION

– If the battery voltage is under 2.3 volts, the wrench will display a battery symbol and then turn off

after a while.

SETUP

3



1 - Value storage

2 - Set Torque Value

3 - Unit Selection/Setting

4 - Power On/Clear



STEP 2: UNIT SELECTION

Press

Presetting Unit: Nm

Unit Selection: in-lb

Unit Selection: ft-lb

Presetting Torque Value

Nota:

1. If appears, that means more than 110%

torque as stated in the specications has been

applied to this wrench.

The wrench will start working again after a few

seconds; however, it should be checked for

calibration at a Beta authorized centre as soon

as possible.

2. The function “Unit Selection” is sequential

Press

STEP 3:

SET TORQUE VALUE

Decrease Max. Torque Value

Increase Max. Torque Value

Press

Unit Selection: kg-cm

STEP 4:

PEAK HOLD / TRACK MODE SELECTION

Track Mode

Long Press

Set Peak/Track Mode

Press for Selection

Press

STEP 1: VALUE STORAGE

NB: Up to 9 stored values can be set

Value storage: M1

Press

Value storage: M2

Press

Value storage: M3

Value storage:M9



*Notes 1, 2

Note:

1. If appears, that means more than 110% of torque as stated in the specications has

been applied to this wrench.

The wrench will start working again after a few seconds; however, it should be checked for

calibration at a Beta authorized centre as soon as possible.

2. If you apply torque over 5 N-m, the LCD display will start to display the torque value. If the

applied torque is less than 5 N-m, the LCD display does not show any changes in value.

3. The green LED will be on for 90% of maximum setting torque.

4. The red LED will be on for 100% of maximum setting torque.

TRACK MODE OPERATION

START

(Sistem initial)

* Note 1

Appliy Torque Over 5 N-m

* Note 2

Reach 90% od Max. Target Value

Max. Target Value

Current Target Value

Current Torque Value

Buzzer

Reach Max.Target Value

Green LED

Over 90% of Set Torque

Red LED

Reach Max. Set Torque

* Note 4

* Note 3

PEAK HOLD MODE OPERATION

START

(System initial)

* Note 1

Apply Torque

Over 90% of Max. Target Value

Max. Target Value

Current Max. Value

(Peak Hold)

Buzzer

Reach Max. Target Value

Green LED

Reach 90% of Set Torque

Red LED

Reach Max. Set Torque

* Note 3

* Note 2

Released

Apply Torque Flashing

Note:

1. If appears, that means more than 110% of torque as stated in the specications has been

applied to this wrench.

The wrench will start working again after a few seconds; however, it should be checked for

calibration at a Beta authorized centre as soon as possible.

2. The green LED will be on for 90% of maximum setting torque.

3. The red LED will be on for 100% of maximum setting torque.

VALUE STORAGE IN PEAK HOLD MODE

Peak/track mode

*Note 2

Keep pressed

Peak/track mode selection

Press

(Delete)

Automatic

change

Press

Storage value

Delete stored value

*Note 1

*Note 3

Storage n°.

Press

(Quit)

Yes

Deleted

Automatic

change

Communication

Press

Communication

Press

(Exit)

Note:

1. The value storage system, “peak

mode”, can be used for the “track

mode” as well.

2. If the peak mode is being used, the

screen might display .

.Move on to the next step.

3. If no values are stored,

will be displayed.

4. The communication mode is used

to upload data stored on the PC.

5. The communication mode is also

used to calibrate the torque

wrench.

*Notes 4-5

Peak/track mode

ANGLE READOUT MODE OPERATON

Angle mode

*Note 2

Blinking

Release

Over 80% of set value

Apply force and turn

wrench

Current torque

80% of set value reached

*Note 1

*Note 3

Current angle

Set value reached

Release

Current angle

Press

* Nota 4

*Note 5

((…((… …)) …))

Current torque

((…((… …)) …))

*Note 6

Note:

1. When the angle measurement is set, the unit of measurement will become ° (Deg.) .

2. Hold the torque wrench fast, in the horizontal position, when the “angle mode” is entered.

3. After a few seconds the “angle mode” will start, and will blink.

4. When the wrench is released, in the “angle mode”, the display will show the corresponding torque

value with blinking LEDs.

5. When 80% of the set value is reached, the green LEDs will start blinking and an intermittent sound

will be heard.

6. When 99.5% of the set value is reached, a continuous sound will be heard, and the green LEDs

will stop blinking and will remain on together with the red LEDs.

SELECTING TORQUE UNIT OF MEASUREMENT IN ANGLE MODE

Angle mode

Peak/track mode

Selecting unit of measurement: in-lb

Keep pressed

*Note 1

Note:

1. The unit of measurement can also be selected in the “torque” mode.

Press

Selecting unit of measurement: N-m

Press

Selecting unit of measurement: ft-lb

Selecting unit of measurement: kg-cm

Press
