Beyerdynamic Opus 69 Guida all'installazione

APPLICATIONS

The Opus 69 is a high quality dynamic vocal microphone

recommended for hand-held or stand-mounted use by

gigging vocalists. It features extremely high gain-before-

feedback characteristics, and its ability to withstand high

sound pressure levels make is suitable for close miking of

musical instruments or speaker cabinets.

FEATURES

• Supercardioid polar pattern

• Excellent isolation from unwanted sound

• Flat, wide range frequency response for uncoloured

sound reproduction

• Rugged construction

Opus 69

Dynamic Microphone

Germany

Theresienstr. 8

D-74072 Heilbronn

Tel. +49 (0 )71 31 / 6 17-0

Fax +49 (0 )71 31 / 617-224

E-mail: [email protected]

Internet: www.beyerdynamic.de

United States

56 Central Ave.

Farmingdale, NY 11735

Tel. +1 (631) 293-3200

Fax +1 (631) 293-3288

E-mail: [email protected]

Internet: www.beyerdynamic.com

Great Britain

17 Albert Drive

Burgess Hill RH15 9TN

Tel. +44 (0)1444 / 258 258

Fax +44 (0)1444 / 258 444

E-mail: [email protected]

Internet: www.beyerdynamic.co.uk

SUPPLIED ACCESSORIES

MKV 108 Microphone clamp for stands with 3/8" or 5/8" thread . . . . . . . . . . . . . . . . . . . . . . Order # 465.429

OPTIONAL ACCESSORIES

BMC 05 FM BLK Microphone cable XLR-XLR, 5 m long. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.787

BMC 10 FM BLK Microphone cable XLR-XLR, 10 m long. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.795

SMC 05 FJ BLK Microphone cable XLR-Jack, 5 m long . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.809

SMC 10 FJ BLK Microphone cable XLR-Jack, 10 m long . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.817

GST 400 Microphone stand, 3/8", height 0.90 - 1.65 m, with G 400 boom. . . . . . . . . . . . . . . Order # 421.294

GST 500 Microphone stand, 3/8", height 0.85 - 1.60 m, with telescopic G 500 boom . . . . . . Order # 406.252

PS 20/40 Pop screen, charcoal-grey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 437.972

VERSIONS

Opus 69 Dynamic microphone, supercardioid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 455.350

Opus 69 S same as above, but with ON/OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 457.205

FREQUENCY RESPONSE & POLAR PATTERN

This polar pattern and frequency response curve (measuring distance ± 2.5 dB) correspond to a typical production

sample for this microphone.

WIRING DIAGRAM

Positive pressure produces positive voltage on red

lead / pin 2 (+).

Photos are non-contractual. Contents subject to change without notice.

Frequency response ± 2.5 dB 0 dB 2.5 mV/Pa OPUS 69

beyerdynamic)))) Opus 69

TECHNICAL SPECIFICATIONS

Transducer type . . . . . . . . . . . . . . . . Dynamic

Operating principle . . . . . . . . . . . . . Pressure gradient

Frequency response

Close miking. . . . . . . . . . . . . . . . . . . 35 - 16,000 Hz

Distant miking . . . . . . . . . . . . . . . . . 95 - 14,000 Hz (measured at 1 metre)

Polar pattern . . . . . . . . . . . . . . . . . . Supercardioid

Rear attenuation at 1 kHz . . . . . . . > 22 dB at 140°

Open circuit voltage

at 1 kHz (0 dB = 1V/Pa) . . . . . . . . . . 2.5 mV/Pa ± 1,5 dB = -52 dBV

Magnetic field suppression. . . . . . . > 20 dB at 50 Hz

Nominal output impedance . . . . . . 290 Ω

Load impedance . . . . . . . . . . . . . . . ≥1000 Ω

Diaphragm . . . . . . . . . . . . . . . . . . . . Hostaphan®

Connection . . . . . . . . . . . . . . . . . . . . 3-pin XLR male

Dimensions . . . . . . . . . . . . . . . . . . . . Length: 180 mm

Shaft diameter: 25/31mm

Head diameter: 45 mm

Weight without cable . . . . . . . . . . . 320 g
