Biamp Vidi 250 Istruzioni operative originali
A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA W: www.biamp.com
PRODUCT DESCRIPTION
The Vidi 250 is a wide angle 4K camera designed for
use with video conferencing systems. Intended for use in
Huddle, small or medium conferencing rooms, the Vidi 250
has a 120° field of view, allowing everyone in the room to be
seen. The Vidi 250 uses auto framing technology to adjust
the focus and zoom to keep participants in view. The Vidi
250 can be either display mounted or wall mounted.
Beamforming
Microphones
Camera ON
Indicator Light
Privacy
Cover
FEATURES
• LED indications for camera activity
• 4K, wide angle 120° field of view
• Pan/Tilt/Zoom with 5x digital zoom
• Auto framing technology keeps participants in frame
• Multi-microphone array
• Privacy cover
• Above and below display mounts included
• Display side and wall mount options
• Optional camera control software for manual control
Kensington
Lock Socket
USB-C
Connection
Mounting
Socket
Vidi 250
Installation & Operation Guide
PRODUCT DETAILS
page 2 Installation and Operation Guide Vidi 250
CAMERA INSTALLATION
Top Mount: (attached to the camera)
1. Pull the lower arm of the mount down.
2. Position the mount onto the top of the display and push
the lower arm against the back of the device to secure.
3. Plug the USB cord into the back of the camera.
4. Remove the privacy cover and aim the camera.
5. Optional - Install Biamp Cameral Control App for
manual control.
USB-C
Connection
Top Mount
2
3
4
1
Vidi 250 Installation and Operation Guide page 3
Under-Display Plate: (included)
You must download the Biamp Cameral Control App to
control the image orientation when mounting the camera
under the display.
1. Adhere the adhesive plate to the underside of the TV or
monitor. To ensure proper adhesion, properly clean the
mounting surface and apply pressure to the mount for
30 seconds. If possible, wait 24 hours before mounting
the camera to ensure maximum bond.
2. Turn the camera and mount upside down and push the
top mount into the under-display plate clips as shown.
The camera/mount will be able to move forward and
backward slightly.
3. Plug the USB cord into the back of the camera.
4. Remove the privacy cover and aim the camera.
5. In the Biamp Cameral Control App you must choose
the "Flip" option to change the view orientation during
setup.
Under-Display Mount
2
3 4
1
page 4 Installation and Operation Guide Vidi 250
Side Mount Accessory (VMA 200-DM) typical installation:
Side Mount
1. Open the side clamps and position on the back or
side of a TV or monitor, so the arm can position
the camera beside the display. To ensure proper
adhesion, properly clean and dry the mounting
surface. Uncover the adhesive strips and attach
mount to the display. Apply pressure to the mounts
for 30 seconds. If possible, wait 24 hours before
attaching the camera to ensure maximum bond.
2. Remove the camera from the top mount and screw it
onto the side mount until tight. Keep the privacy cover
on. Do not push down on the arm while screwing the
camera on the mount.
3. Plug the USB cord into the back of the camera.
4. Remove the privacy cover and carefully move/rotate
the arm and camera to point to the desired location.
5. Optional - Install Biamp Cameral Control App for
manual control.
2
3 4
1
Vidi 250 Installation and Operation Guide page 5
Wall Mount Accessory (VMA 200-WM) installation:
Position the wall mount on a vertical surface (wall or furniture) close to the TV or
monitor and mark the hole locations. Prepare the surface or pre-drill the holes
as necessary.
1. Attach the mount to the surface (shown with screw / anchors).
2. Remove the camera from the top mount and screw the camera onto the
wall mount until tight.
3. Plug the USB cord into the back of the camera.
4. Remove the privacy cover and carefully move the camera to point to the
desired location.
2
34
1
page 6 Installation and Operation Guide Vidi 250
Biamp Camera Controller software (App)
The Biamp Camera Controller provides manual control of Biamp conferencing
cameras. This software, available on both PC and Mac, is available <here> This
software will detect a connected camera and provide a preview window with
additional controls on two tabs. Information about the software and settings is
available in the help file: cameracontroller-help.biamp.com.
IMPORTANT: Do not unplug the camera
during a rmware update!
Video
• Preset saving and recall (x3)
• Manual zoom and panning (ePTZ)
• Enable autoframing
Settings
• Backlight compensation
• Image mirroring
• Image flip for under-display mounting
• Enable the microphone
• Set refresh rate (50 or 60 Hz)
• Profile (options shown below)
• Maximum zoom
• Upgrade the firmware. Firmware is available <here>.
You must download the firmware file from the biamp
website before installing the new version. The current
firmware version is shown (circled) for reference.
Note: Upgrades aren't necessary if the camera is
performing well, but are necessary to take advantage
of all the setting options (profiles, auto update, etc.)
• Enable automatic updates (via Microsoft®Windows®
- Windows PCs only). It is on by defaul when using
the Microsoft Teams®profile, but can be chosen when
using the other profiles.
Vidi 250 Installation and Operation Guide page 7
Maintenance
• Clean the camera lens with a soft non-abrasive cloth
• The mounting ball can be tightened if necessary (top mount only)
Top mount
2
1
1. Remove mount from video display, and pull ring down.
2. Rotate to tighten the ball and place camera back on the display.
A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA W: www.biamp.com
12SEP2023
CONTACT US
Email: [email protected]
Web: support.biamp.com
Warranty: biamp.com/legal/warranty-information
Safety & Compliance: biamp.com/compliance
Microsoft, Microsoft Teams, and Windows are trademarks of
the Microsoft group of companies.
Zoom is a trademark of Zoom Video Communications, Inc.,
registered in the U.S. and other countries.
Google Meet™ and Hangouts are trademarks of Google LLC.
