Biddle DF S-100-W-F Manuale utente

Manual

Comfort Air Curtain

Model DF

Version 3.0

Original Manual English

COMFORT AIR CURTAIN

en-2 B

. . . Contents

1 Introduction 3

1.1 About this manual 3

1.2 How to read this manual 3

1.3 About the unit 4

1.4 Restrictions on use 7

1.5 Safety instructions 8

2 Installation 10

2.1 Inspection on delivery 10

2.2 General working method 10

2.3 Hanging the unit up 12

2.4 Connecting the unit to the central heating system 14

2.5 Connecting the unit to the mains supply 15

2.6 Installing the control panel and external controls 19

2.7 Finishing the unit 26

2.8 Switching on and checking operation 28

3Operation 29

3.1 General 29

3.2 Starting and stopping 29

3.3 Adjusting the strength of the air curtain 30

3.4 Adjusting heating 30

4 Maintenance 32

4.1 Cleaning the unit 32

4.2 Scheduled maintenance 32

5Errors 33

5.1 Resolving simple problems 33

5.2 Remedying faults 34

6Service 38

6.1 Access 38

6.2 Fuses 41

6.3 High-limit thermostat 42

6.4 Biddle control cable composition 42

7Dismantling 43

8Addresses 45

Keywords 46

Manual version 3.0 (21-11-2017) en-3

1. . Introduction

1.1 About this manual

This manual describes the installation, operation and mainte-

nance of the comfort air curtain model DF. The manual also

provides instructions and information about servicing.

1.2 How to read this manual

1.2.1 Designations used in the manual

The following symbols are used in the manual:

Note:

nRefers to an important section in the text.

Caution:

cIf you do not carry out the procedure or action

correctly, you may cause damage to the unit.

Follow the instructions precisely.

Warning:

wIf you do not carry out the procedure or

action correctly, you may cause physical injury

and/or damage.

Follow the instructions precisely.

Danger:

dIs used to designate actions that are not

permitted.

Ignoring this prohibition may lead to serious

damage or to accidents resulting in physical

injury.

INTRODUCTION COMFORT AIR CURTAIN

en-4

1.2.2 Symbols used on the unit and in the manual

The following symbols indicate possible risks or hazards. The

same symbols will also be found on the unit.

1.2.3 Related documentation

In addition to this manual, the following documentation is also

supplied with the unit:

• wiring diagram for installation and servicing.

1.3 About the unit

1.3.1 Application and operation of the air curtain

The air curtain is designed to separate indoor and outdoor cli-

mates. The unit draws air from the room and discharges it,

either heated or not, across the width of the doorway. The air

curtain removes the undesired effects of an open door by

either reducing the exchange of indoor and outside air, by

heating the entering air, or a combination of the two.

Mounting types

The free-hanging model (type F) is designed for free, visible

installation above the door.

SYMBOL DESCRIPTION

wYou have accessed a section of the unit containing components which carry

a voltage.

Access restricted to qualified maintenance staff only.

Caution is required.

wThis surface or component may be hot. Risk of burns on contact.

DF MANUAL INTRODUCTION

Manual version 3.0 (21-11-2017) en-5

The recessed model (type R) is designed for integration into a

false ceiling or into a cove, with the inlet opening possibly at

some distance from the unit.

The cassette model (type C) is designed for installation above

a false ceiling, with the inlet opening close to the unit and with

easy access to the unit.

Other versions and intended use

Upon request, we can supply versions for non-standard appli-

cations.

Warning:

wApplications other than those described

above are deemed to be ‘usage other than for

the intended purpose’. Biddle is not liable for

damage or loss resulting from usage other

than for the intended purpose. Usage for the

intended purpose also entails observance of

the instructions in this manual.

1.3.2 Type designation

Type designations, when combined, form a unit type code, e.g.:

Different combinations may arise.

DF S-100-W-F

DF M-150-E-C

DF L-200-A-R

INTRODUCTION COMFORT AIR CURTAIN

en-6

Explanation of the type code

1.3.3 Type plate

The type plate is located on the top of the unit.

Designations on the type plate

1.3.4 CE declaration

The unit is compliant with the applicable CE standards. The

complete CE Declaration of Conformity can be found at:

www.biddle.info.

YPE CODE

ELEMENT DESIGNATION MEANING

product series DF air curtain

capacity S small

Mmedium

L large

length 100, 150, 200, 250 discharge length (cm)

battery type W hot water

E electrical

A zonder verwarming

(Ambient)

model F free-hanging model

C cassette model

R recessed model

DESIGNATION MEANING

Type complete type code of the unit

Noserial number, production week and

year

Mweightofunit

Medium medium

pmax maximum permissible operating pres-

sure

U power supply voltage

Imax max. current

Pmotor max. power consumption by fans

Pheating For electrically heated models:

max. power consumption by heating

element

DF MANUAL INTRODUCTION

Manual version 3.0 (21-11-2017) en-7

1.3.5 Modifications and changes

Without the approval of Biddle, no changes or modifications

may be made to the unit that could adversely affect safety. The

CE declaration is no longer valid if the unit has been modified

or changed in any way.

1.3.6 Components and accessories

For all models:

• control panel (supplied separately – can be used for multi-

ple units)

• control cable – Type RJ4 (supplied separately)

•optional:

door contact switch (supplied separately)

For water-heated models (Type W):

•optional:

double-sided valve for water-side control (sold separately)

Note:

nThe unit is fitted with a three-way valve as standard.

For recessed models (Type R):

• telescopic discharge duct (supplied)

•optional:

inlet grille for installation in alcove (supplied separately)

1.4 Restrictions on use

1.4.1 Field of application

• The unit may only be used indoors.

• The unit is suitable only for dry and non-dusty environ-

ments.

• The unit may not be used in an environment in which cor-

rosive or chemically aggressive gases or vapours are pre-

sent.

• The unit is suitable for ambient temperatures from 0°C to

40°C.

These restrictions also apply to the control unit and/or the

control panel.

INTRODUCTION COMFORT AIR CURTAIN

en-8

1.4.2 Required skills

• You must be technically qualified to install, maintain or ser-

vice the unit in accordance with local legislation, regula-

tions and standards.

• For operation in daily use, no special skills are required.

• The unit is not intended for use by children or people with

an intellectual disability.

Danger:

dDo NOT attempt to install, maintain or

service the unit unless you are adequately

qualified to do so.

1.4.3 Application limitations with water heating

Application limitations for units with water heating

1.5 Safety instructions

1.5.1 Safety in use

Warning:

wDo not put any objects into the inlets and

outlets.

Warning:

wDo not obstruct the unit’s inlets or outlets.

Warning:

wThe upper surface of the unit becomes hot

during operation.

Heating medium water with

max. 20% glycol

Maximum water

flow-path

W2 90/70 °C

W4 70/50 °C

Max. discharge

temperature

types S/M 55 °C

type L 45 °C

Maximum operating pressure 8 bar

DF MANUAL INTRODUCTION

Manual version 3.0 (21-11-2017) en-9

Caution:

cIn exceptional situations, water may run out of the

unit. Therefore, do not place anything under the unit

that could be damaged as a result.

1.5.2 Safety issues relating to installation, mainte-

nance and servicing

Danger:

dThe unit may only be opened by qualified

technical staff.

Warning:

wPerform the following actions before opening

the unit:

1. Switch the unit off,using the control panel.

2. Wait until the fans have stopped.

Danger:

dThe fans may continue rotating for a while.

3. Allow the unit to cool down.

Caution:

cThe heat exchanger or, as the case may be, the

heating elements, can get very hot.

4. Disconnect the mains supply (remove plug from the power

socket orswitch off the isolation switch).

5. For water-heated models:

shut off the central heating feed (if possible).

Warning:

wThe fins of the heat exchanger are sharp.

en-10

2. . Installation

Warning:

wInstallation activities may only be performed

by technical staff qualified for this purpose.

Warning:

wBefore starting installation: read the safety

instructions.
