Billion 7025 Manuale utente
ISDN PCI Card
Quick Start Guide
This product is designed for the ISDN with Basic Rate Interface.
Quick Start Guide
1
For more detailed instructions on configuring and
using the ISDN card, please refer to the on-line
manual.
Package Contents
• One ISDN card
• One ISDN card installation CD with drivers, utility and bundled
application software programs
• One RJ-45 ISDN cable
• This Quick Start Guide
Installing the ISDN card
Connect your ISDN line to the ISDN S0RJ-45 jack.
ISDN PCI card
2
For Windows 95, OEM Service Release 2 (OSR2)
or Windows 98:
1. Start Windows. After the opening banner, Windows
will tell you that your ISDN card has been detected.
You will then see the following screen for Windows 95:
Or you will see the following screen for OSR2:
Or you will see the following screen for Windows 98:
Quick Start Guide
3
2. Insert the installation CD into the CD-ROM drive (D:
or E: , etc.).
3. For Windows95, select “Driver from disk provided by
hardware manufacturer”. For OSR2, click “Next >” to go
on. For Windows 98, click “Next >”. Then, check
“Specify a location:” and browse for “D:\Driver\Win98” (D:
represents your CD-ROM drive).
4. Follow the instructions on the screen. Windows will
copy the driver files to Windows sub-directories.
5. Then, Windows will start copying system files and you
might see the following screen prompting for the path
of the Windows source files. Please specify the location
of your Windows source files and click “OK”.
6. For Windows 95 or OSR2, if the Microsoft ISDN
Accelerator Pack 1.1 or Dial-Up Networking 1.3 has
been installed before, Windows will detect some files
with newer version. Press “Yes” to keep the newer files.
7. For Windows 95 or OSR2, if the Microsoft ISDN
Accelerator Pack 1.1 or Dial-Up Networking 1.3 is not
installed before, you should see the following screen.
ISDN PCI card
4
8. After complete installing the ISDN card driver, you will
be prompted to restart the computer. Press “Yes” to
restart your computer.
For Windows NT 4.0:
1. Start Windows. Insert the installation CD into the CD-
ROM drive (D: or E: , etc.).
2. Run “Setup.exe” in the root directory of installation CD.
3. Press “Windows NT Driver” button. Then, the following
window appears.
4. Click “OK” to begin copying files. After that, the
“Setup Program” will start.
Quick Start Guide
5
5. If your PC has PnP BIOS, you can choose “Auto setting”.
Then the IRQ and I/O Port of the ISDN card will be
configured by the system.
6. After setting the properties of the ISDN card, you might
see the following screen prompting for the path of the
Windows NT source files to installing the Remote
Access Service (RAS).
7. When the RAS is installed, you will see the following
screen for configuring ISDN ports as RAS devices.
ISDN PCI card
6
8. Press “OK” to select “ISDN1-NTWANMP” as one of the
“RAS Capable Devices”, you should then see the
following screen.
9. Click “Add...” for adding “ISDN2-NTWANMP” to the
list of RAS communication ports. The “ISDN1” and
“ISDN2” ports make the ISDN card be capable of
dialing or receiving multilink calls. For more details
about configuring the multilink support in Windows NT
4.0, please refer to the on-line help of RAS.
10. Click “Continue” to complete RAS setup, and you
should see the ISDN card has been installed as a
network adapter.
Quick Start Guide
7
11. Click “Close”. Then, you will be prompted to restart the
computer.
12. Press “Yes” to restart your computer and finish the
driver installation.
For Windows ME:
1. Start Windows. After the opening banner, Windows
will tell you that your ISDN card has been detected.
2. Insert the installation CD into the CD-ROM drive (D:,
or E:, etc.). Select “Specify a location:” and browse for
“D:\Driver\WinME” (D: represents your CD-ROM drive).
Click “Next >”.
ISDN PCI card
8
3. After pressing “Next >” button for the next screen, then
press “Finish”.
4. If the next screen appears when Windows finishes
installing the drivers, press “Yes” to restart the
computer.
For Windows 2000:
1. Start Windows. After the opening banner, Windows
will tell you that your ISDN card has been detected.
Press “Next>”
Quick Start Guide
9
2. Insert the installation CD into the CD-ROM drive (D:,
or E:, etc.). Select “Specify a location” and browse for
“D:\Driver\Win2000” (D: represents your CD-ROM
drive). Click “OK”.
3. After pressing “Next >” for the next screen, click
“Yes” if windows titled “Digital Signature Not Found”
appear. Then, press “Finish” to end the installation.
For Windows XP:
1. Start Windows. After the opening banner, Windows
will tell you that your ISDN card has been detected.
Press “Next>”
